Paxton 010-522-US Paxton10 Single Door Controller, 12/24V 2A PSU
Image of 1
Key Features
- Simplifies door-level security with a reliable single-door Paxton10 controller that enforces access policies in real time
- Flexible power options (PoE or 12/24V 2A PSU) for easy integration into existing low-voltage infrastructures and reduced installation complexity
- Local stored programming keeps doors operating during network outages for uninterrupted physical security and monitoring
- Gigabit TCP/IP connectivity and RJ-45 network interface enable fast, scalable deployment across sites and easy integration with surveillance and security systems
- Compact indoor enclosure with tamper detection and multiple inputs (door contact, RTE, alarm) for robust control of locks, barriers, and alarm integration
Quick Specifications
- Product Model
- 010-522-US
- Brand Name
- Paxton
- Product Line
- Paxton10
- Product Name
- Paxton10 Door Controller
Frequently Bought Together
Paxton 010-522-US Paxton10 Single Door Controller, 12/24V 2A PSU
$585.56
9 items selected
Total: $2,719.77
Explore the details
Product information
010-522-US
Overview
Secure and scalable access control starts at the door. The Paxton Paxton10 Single Door Controller (010-522-US) delivers a dependable, enterprise-ready access control solution for offices, data centers, healthcare and education facilities. Designed as a networked access control panel, this Paxton10 controller supports TCP/IP Gigabit Ethernet connectivity and can be deployed as a PoE device or powered via the included 12/24V 2A PSU for installation flexibility.
Built to reduce downtime, the controller stores programming locally so door operation continues even if the server connection is lost. It manages one door and provides multiple inputs (door contact, RTE, tamper and alarm) plus a powered lock output—streamlining integration with locks, barriers and third-party surveillance or monitoring systems. Paxton’s scalable architecture supports up to 1,000 door controllers, making it ideal for multi-site security deployments.
For integrators and security managers looking to strengthen perimeter control and simplify commissioning, the 010-522-US offers clear wiring labels, diagnostic LEDs and proven reliability. Add this Paxton10 door controller to your next access control or security monitoring project—contact sales or order today to deploy secure, networked access.
Features
- Simplifies door-level security with a reliable single-door Paxton10 controller that enforces access policies in real time
- Flexible power options (PoE or 12/24V 2A PSU) for easy integration into existing low-voltage infrastructures and reduced installation complexity
- Local stored programming keeps doors operating during network outages for uninterrupted physical security and monitoring
- Gigabit TCP/IP connectivity and RJ-45 network interface enable fast, scalable deployment across sites and easy integration with surveillance and security systems
- Compact indoor enclosure with tamper detection and multiple inputs (door contact, RTE, alarm) for robust control of locks, barriers, and alarm integration
| General Information | |
|---|---|
| Brand Name | Paxton |
| Manufacturer | Paxton Access Ltd. |
| Product Line | Paxton10 |
| Product Name | Paxton10 Door Controller |
| Product Type | Door Access Control Panel |
| Product Model | 010-522-US |
| Manufacturer Part Number | 010-522-US |
| Technical Information | |
| Host Interface | IP, TCP |
| Number of Doors | 1 |
| Application/Usage | Door |
| Identification Method | Key Code, Proximity |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Physical Characteristics | |
| Depth | 3" |
| Width | 12.7" |
| Height | 12.7" |
| Power Description | |
| Input Voltage | 24V DC |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Indoor/Outdoor | Indoor |
| Country of Origin | GB |
| Environmentally Friendly | Yes |
| Environmental Certification | WEEE |
