AXIS M3077-PLVE M39 Series 6MP Outdoor Vandal Resistant 360° Panoramic Fixed Dome IR WDR IP Camera, 1.56mm Lens, White
Image of 4
Key Features
- Full 360° panoramic coverage with a 6 MP sensor: eliminate blind spots and reduce the number of cameras needed for large outdoor areas.
- Dewarped multi-view and digital PTZ: deliver panorama, quad, corner and corridor views directly from the camera for flexible, actionable monitoring.
- Superior low-light and IR performance: Axis Lightfinder, Forensic WDR and OptimizedIR preserve color and detail for reliable 24/7 surveillance.
- Hardened for outdoor use: IK08 vandal resistance and IP66/IP67-rated housing ensures continuous operation in harsh environments.
- Simplified deployment and edge storage: PoE installation, built-in SD support and ONVIF compatibility speed up integration with VMS and network systems.
- Audio and tamper detection: dual built-in microphones, motion/audio detection and tamper alarms provide incident context and faster investigations.
Quick Specifications
- Brand Name
- AXIS Communications
- Manufacturer
- Axis Communications
- Product Line
- M
- Product Name
- AXIS M3077-PLVE
Frequently Bought Together
AXIS M3077-PLVE M39 Series 6MP Outdoor Vandal Resistant 360° Panoramic Fixed Dome IR WDR IP Camera, 1.56mm Lens, White
$812.35
6 items selected
Total: $2,006.61
Product Information Tabs
Overview
Deliver uninterrupted, full-area outdoor security with the AXIS M3077-PLVE panoramic fixed dome from Axis Communications. Designed for perimeter and wide-area surveillance, this compact 6 MP network camera captures high-resolution 360° or 180° overviews using its 1.56 mm lens and produces dewarped panorama, quad, corner and corridor views straight from the camera — reducing the need for multiple cameras and streamlining monitoring workflows. Advanced imaging features like Axis Lightfinder, Forensic WDR and OptimizedIR maintain color fidelity and reveal detail in challenging light and complete darkness, while built-in microphones and audio detection add another layer of incident verification. Ruggedized for outdoor deployment, the M3077-PLVE meets IK08 impact and IP66 ingress ratings and supports PoE for fast, cost-effective installations. With H.264/H.265 compression, edge SD recording and ONVIF compatibility, it integrates easily with existing VMS and network infrastructure. Ideal for campuses, transportation hubs, retail exteriors and critical infrastructure, this Axis panoramic camera improves situational awareness and reduces total cost of ownership. Contact us to specify, order, or integrate this camera into your security and monitoring solution.
Features
- Full 360° panoramic coverage with a 6 MP sensor: eliminate blind spots and reduce the number of cameras needed for large outdoor areas.
- Dewarped multi-view and digital PTZ: deliver panorama, quad, corner and corridor views directly from the camera for flexible, actionable monitoring.
- Superior low-light and IR performance: Axis Lightfinder, Forensic WDR and OptimizedIR preserve color and detail for reliable 24/7 surveillance.
- Hardened for outdoor use: IK08 vandal resistance and IP66/IP67-rated housing ensures continuous operation in harsh environments.
- Simplified deployment and edge storage: PoE installation, built-in SD support and ONVIF compatibility speed up integration with VMS and network systems.
- Audio and tamper detection: dual built-in microphones, motion/audio detection and tamper alarms provide incident context and faster investigations.
| General Information | |
|---|---|
| Brand Name | AXIS Communications |
| Manufacturer | Axis Communications |
| Product Line | M |
| Product Name | AXIS M3077-PLVE |
| Product Type | Fixed dome cameras |
| Product Model | M3077 |
| Product Series | M30 |
| Manufacturer Part Number | 02018-001 |
| Supported Network Protocols | IPv6 USGv6, NIST SP500-267 |
| Technical Information | |
| Aperture | f/2.0 |
| Lens Type | Fixed |
| Night Vision | Yes |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264, H.265, MJPEG, MPEG-4 |
| Maximum Aperture | f/2 |
| Night Vision Type | Infrared |
| Maximum Frame Rate | 60fps |
| Built-in Microphone | Yes |
| Minimum Focal Length | 1.56mm |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 6MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 65.62 ft |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Image Sensor Size | 1/1.8" |
| Maximum Video Resolution | 2016 x 2016 |
| Environmental Conditions | |
| Operating Humidity | 1 |
| Maximum Operating Temperature | 122°F (50°C) |
| Minimum Operating Temperature | -40°F (-40°C) |
| Exposure | |
| Minimum Illumination | 0 lux |
| Longest Shutter Speed | 1 Second |
| Shortest Shutter Speed | 1/16000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 1.56mm |
| Lens Included | Yes |
| Maximum Focal Length | 1.56mm |
| Memory | |
| Memory Card Supported | Yes |
| Network & Communication | |
| Remote Management | Yes |
| Others | |
| Model Number Replaces | 0548-001 |
| Physical Characteristics | |
| Color | White |
| Height | 2.6" |
| Weight | 1.54lb |
| Durability | Vandal Resistant |
| Form Factor | Dome |
| Power Description | |
| Maximum Power Consumption | 12W |
| Power over Ethernet (PoE) | Yes |
| Product Information | |
| Diameter | 5.9" |
| Mount Type | Ceiling Mount, Conduit Mount, Corner Mount, Pendant Mount, Pole Mount, Surface Mount, Wall Mount |
| Storage | |
| Storage Type | Memory Card |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Features | Audio Detection, Auto Gain Control, Automatic White Balance, Built-in IR LED, Built-in Microphone, Day/Night, Motion Detection, Multi-view Stream, Noise Reduction, Privacy Masking, PTZ, Removable IR Cut-off Filter, SD Card Local Storage, Tampering Alarm, Video Management System, Wide Dynamic Range |
| Certifications | CISPR 35, EAC, EN 55024, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), KC KN32 Class A, KC KN35, RCM AS/NZS CISPR 32 Class A, VCCI Class A |
| Indoor/Outdoor | Outdoor |
| Country of Origin | TH |
| Impact Protection Rating | IK08 |
| Certifications & Standards | ONVIF G, ONVIF M, ONVIF S, ONVIF T |
| Environmental Certification | IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC 60721-3-5 Class 5M3, IEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA 250 Type 4X, NEMA TS 2 (2.2.7-2.2.9) |
