AXIS M4308-PLE M43 Series 12MP Outdoor 360° Panoramic IR WDR IP Camera, 1.3mm Lens, White
Image of 2
Key Features
- Full 360° panoramic coverage to eliminate blind spots and reduce the number of cameras needed for wide-area surveillance
- 12MP resolution with Axis Lightfinder and WDR for crisp, actionable images in day, backlit and low-light conditions
- Integrated IR illumination and four built-in microphones for reliable night monitoring with audio context
- Rugged outdoor design (IP66, IK09/IK10) and PoE support for simplified, weatherproof deployments and lower installation costs
- On-board deep learning analytics and ONVIF compatibility for seamless integration with VMS, edge detection and proactive security workflows
Quick Specifications
- Product Model
- M4308-PLE
- Brand Name
- AXIS Communications
- Product Line
- M
- Product Name
- AXIS M4308-PLE
Frequently Bought Together
AXIS M4308-PLE M43 Series 12MP Outdoor 360° Panoramic IR WDR IP Camera, 1.3mm Lens, White
$1,141.82
5 items selected
Total: $2,598.62
Product Information Tabs
Overview
Protect large outdoor spaces with a single, high-performance device: the AXIS M4308-PLE panoramic IP camera from Axis Communications. Built for security teams and integrators, this fixed-dome panoramic camera delivers a full 360° overview in 12MP clarity, reducing blind spots and lowering overall system cost. Advanced Axis Lightfinder and WDR ensure color-accurate, usable footage in challenging lighting, while built-in IR illumination reaches roughly 49 ft for dependable night monitoring. The ultra-wide 1.3 mm lens captures detailed situational context and four integrated microphones add audio awareness to video events.
Designed for real-world installations, the M4308-PLE supports Power over Ethernet (PoE) for streamlined cabling and is rated IP66 with IK09/IK10 impact resistance for reliable outdoor performance. On-board deep learning analytics and ONVIF support enable edge detection, object classification and smooth integration with leading VMS platforms. Ideal for campuses, transportation hubs, retail plazas and public spaces, the AXIS M4308-PLE simplifies surveillance architecture while improving incident visibility. Contact your Axis reseller or add to cart to start upgrading your outdoor monitoring strategy.
Features
- Full 360° panoramic coverage to eliminate blind spots and reduce the number of cameras needed for wide-area surveillance
- 12MP resolution with Axis Lightfinder and WDR for crisp, actionable images in day, backlit and low-light conditions
- Integrated IR illumination and four built-in microphones for reliable night monitoring with audio context
- Rugged outdoor design (IP66, IK09/IK10) and PoE support for simplified, weatherproof deployments and lower installation costs
- On-board deep learning analytics and ONVIF compatibility for seamless integration with VMS, edge detection and proactive security workflows
| General Information | |
|---|---|
| Brand Name | AXIS Communications |
| Manufacturer | Axis Communications |
| Product Line | M |
| Product Name | AXIS M4308-PLE |
| Product Type | Fixed dome cameras |
| Product Model | M4308-PLE |
| Product Series | M43 |
| Country of Origin | TH |
| Manufacturer Part Number | 02100-001 |
| Supported Network Protocols | IPv6 |
| Technical Information | |
| PoE | Yes |
| Aperture | f/2.4 |
| Lens Type | Fixed |
| Night Vision | Yes |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264 / AVC, H.265 / HEVC, MJPEG, MPEG-4 Visual |
| Maximum Aperture | f/2.4 |
| Night Vision Type | Infrared (IR) |
| Maximum Frame Rate | 30fps |
| Wide Dynamic Range | Yes |
| Built-in Microphone | Yes |
| Minimum Focal Length | 1.30mm |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 12MP |
| Camera | |
| Image Sensor Type | CMOS |
| Night Vision Distance | 49.21' |
| Certifications | |
| Certifications | EAC, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A, VCCI Class A |
| Ingress Protection Rating | IP66 |
| Certifications & Standards | ONVIF G, ONVIF M, ONVIF S, ONVIF T |
| Display & Graphics | |
| Image Sensor Size | 1/1.7" |
| Maximum Video Resolution | 2880 x 2880 |
| Environmental Conditions | |
| Operating Humidity | 100% |
| Operating Temperature (T-T) | -40-50°C |
| Maximum Operating Temperature | 122°F |
| Minimum Operating Temperature | -40°F |
| Exposure | |
| Minimum Illumination | 0.0400lux |
| Longest Shutter Speed | 1 Second |
| Shortest Shutter Speed | 1/22000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 1.3mm |
| Lens Included | Yes |
| Maximum Focal Length | 1.30mm |
| Memory | |
| SD Card Slot | Yes |
| Memory Card Supported | Yes |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | White |
| Height | 2.70" |
| Durability | Dustproof, Impact Resistant, Vandal Resistant, Waterproof |
| Form Factor | Dome |
| Power Description | |
| Maximum Power Consumption | 15.50W |
| Power over Ethernet (PoE) | Yes |
| Product Information | |
| Diameter | 5.90" |
| Mount Type | Bracket Mount |
| Storage | |
| Storage Type | SD Card |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Features | Audio Detection, Built-in Infrared Illuminator, Built-in Microphone, Day/Night, HTTPS Encryption, Motion Detection, Password Protection, SD Card Local Storage, White Balance, Wide Dynamic Range |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK09, IK10 |
| Environmental Certification | IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, NEMA TS 2 (2.2.7-2.2.9) |
