AXIS TU1001-VE Outdoor Microphone for Network Devices
Image of 1
Key Features
- Rugged outdoor audio capture: IP66 weatherproofing and IK10 vandal resistance ensure reliable sound in harsh environments for continuous security monitoring.
- Clear voice pickup: 20 Hz–20 kHz frequency response and high sensitivity deliver intelligible speech and forensic-quality audio for surveillance and incident review.
- Simple integration with network devices: Standard 3.5 mm audio-in (mini-phone) fits cameras, audio modules or bridges for fast deployment on existing systems.
- Flexible mounting and conduit options: Wall or ceiling mountable with AXIS ACI Conduit Adapter support to suit perimeter, entryway, or facility-wide installations.
- Procurement-ready: TAA compliance and a 3-year limited warranty give confidence for enterprise and government security projects.
Quick Specifications
- Product Model
- TU1001-VE
- Brand Name
- AXIS Communications
- Product Line
- T
- Product Name
- AXIS TU1001-VE Microphone
Frequently Bought Together
AXIS TU1001-VE Outdoor Microphone for Network Devices
$174.00
8 items selected
Total: $1,127.87
Explore the details
Product information
02269-001
Overview
Designed for dependable outdoor audio in security and surveillance systems, the AXIS TU1001-VE outdoor microphone from Axis Communications delivers clear, tamper-resistant sound where it matters most. Built to withstand vandalism and extreme weather, this pro microphone carries IK10 impact protection and IP66 weatherproofing so you can monitor exterior perimeters, loading docks, and public areas without frequent maintenance. The TU1001-VE captures a wide 20 Hz–20 kHz frequency range with sensitive pickup for natural speech and critical ambient sounds, and connects easily to network devices via a standard 3.5 mm audio-in jack. Installation is straightforward — wall or ceiling mounting is supported and conduit can be attached using the AXIS ACI Conduit Adapter for neat, secure cabling. TAA compliance and a 3-year limited warranty make it a practical choice for enterprise and government procurement. Ideal for security monitoring, retail loss prevention, and transport hubs, the AXIS TU1001-VE brings reliable outdoor audio to your surveillance ecosystem — add it to your next deployment for better situational awareness.
Features
- Rugged outdoor audio capture: IP66 weatherproofing and IK10 vandal resistance ensure reliable sound in harsh environments for continuous security monitoring.
- Clear voice pickup: 20 Hz–20 kHz frequency response and high sensitivity deliver intelligible speech and forensic-quality audio for surveillance and incident review.
- Simple integration with network devices: Standard 3.5 mm audio-in (mini-phone) fits cameras, audio modules or bridges for fast deployment on existing systems.
- Flexible mounting and conduit options: Wall or ceiling mountable with AXIS ACI Conduit Adapter support to suit perimeter, entryway, or facility-wide installations.
- Procurement-ready: TAA compliance and a 3-year limited warranty give confidence for enterprise and government security projects.
| General Information | |
|---|---|
| Brand Name | AXIS Communications |
| Manufacturer | Axis Communications |
| Product Line | T |
| Product Name | AXIS TU1001-VE Microphone |
| Product Type | Audio and I/O; Microphones |
| Product Model | TU1001-VE |
| Product Series | TU10 |
| Manufacturer Part Number | 02269-001 |
| Technical Information | |
| Sensitivity | -32.1dB, 3dB |
| Host Interface | Mini-phone |
| Connectivity Technology | Wired |
| Audio | |
| Maximum Frequency Response | 20 kHz |
| Minimum Frequency Response | 20Hz |
| Certifications | |
| TAA Compliant | Yes |
| Environmental Conditions | |
| Operating Temperature (T-T) | -4-140°F |
| Physical Characteristics | |
| Color | White |
| Depth | 4.7" |
| Width | 3" |
| Height | 4.7" |
| Form Factor | Ceiling Mount, Wall Mount |
| Product Information | |
| Length | 2" |
| Mount Type | Ceiling Mount, Wall Mount |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Certifications | EN 55032 Class B, EN 55035, FCC Part 15 Subpart B Class B |
| Indoor/Outdoor | Outdoor |
| Country of Origin | JP |
| Environmental Certification | IEC/EN 60529 IP66, IEC/EN 62262 IK10 |
No matching specifications
Try a different term, such as a connector type or resolution.
Plan your purchase
Is this right for your project?
Confirm the model, required accessories and delivery needs before ordering.
- SKU:
- 02269-001
- Manufacturer part:
- 02269-001
How do I confirm compatibility?
Check the specifications and manufacturer documents for your existing system. Send us your model numbers and project requirements if you need help selecting equipment or accessories.
Ask a product specialistWhen will this item ship?
Availability is shown above. Special-order items and project quantities may need additional lead time. Contact us to confirm a delivery date before scheduling installation.
Shipping, freight and delivery detailsWhat should I know about returns?
Returns require an approved RMA. Consult the linked return policy for deadlines and eligibility. For standard non-defective returns, eligible factory-sealed items carry a 15% restocking fee and customer-paid return shipping; open-box and used items are refused. Defective and DOA claims follow the policy's separate terms. Special orders and other exclusions are final sale.
Read return eligibility and exclusionsAXIS TU1001-VE Outdoor Microphone for Network Devices
02269-001
