AXIS F7225-RE Extremely Discreet Pinhole Sensor

SKU: 02363-021 Axis Communications

Special Order: typically 2–6 weeks

Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.

Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.

A member of our team will check with the manufacturer and personally reply by email.

Image of Z4-02363021
Product images for AXIS F7225-RE Extremely Discreet Pinhole Sensor. 1 image(s) available. Click on image to view full size.

Key Features

  • Ultra-discreet pinhole design for concealed installation in ATMs, kiosks and tight enclosures, minimizing visual impact and tampering risk
  • HD forensic-quality video with up to 1080p at 60 fps (with AXIS F9111) and up to 180 fps at 720p for clear evidence capture
  • Wide 97° field of view that covers large areas from a compact sensor, reducing the number of devices required
  • IP66/IP67-rated and wide operating temperature range for reliable outdoor and industrial surveillance
  • Low-light performance (0.3 lux) and Forensic WDR for improved image clarity in varied lighting conditions

Quick Specifications

Product Model
F7225-RE
Brand Name
AXIS Communications
Product Line
F
Product Name
AXIS F7225-RE Pinhole BULK 8 PCS
View Full Technical Specifications

Frequently Bought Together

This Item
AXIS F7225-RE Extremely Discreet Pinhole Sensor

AXIS F7225-RE Extremely Discreet Pinhole Sensor

$2,459.71

Frequently Bought Together (4 items)

5 items selected

Total: $2,976.57

Explore the details

Product information

02363-021

Overview

Designed for discreet surveillance and secure integration, the AXIS F7225-RE Extremely Discreet Pinhole Sensor from Axis Communications delivers professional-grade imaging where space is limited. Ideal for ATM, kiosk and machine monitoring, this sensor connects to AXIS F91/F9111 main units to reduce installation and configuration time and cost while providing forensic-quality video. Capture fast events with up to 1080p at 60 fps (with AXIS F9111) or ultra-smooth 720p at up to 180 fps, and cover wide areas with a 97° field of view from a 3.7 mm pinhole lens. Built for real-world security deployments, the sensor is IP66/IP67-rated and operates across a broad temperature range for dependable outdoor and indoor monitoring. Low-light sensitivity (0.3 lux) and Forensic WDR enhance image detail in challenging lighting—crucial for evidence capture and incident analysis. Small, rugged and purpose-built for covert camera systems, the AXIS F7225-RE is a robust choice for integrators and security professionals seeking discreet, reliable surveillance and monitoring. Specify this sensor for ATM protection, retail loss prevention, or industrial security deployments.

Features

  • Ultra-discreet pinhole design for concealed installation in ATMs, kiosks and tight enclosures, minimizing visual impact and tampering risk
  • HD forensic-quality video with up to 1080p at 60 fps (with AXIS F9111) and up to 180 fps at 720p for clear evidence capture
  • Wide 97° field of view that covers large areas from a compact sensor, reducing the number of devices required
  • IP66/IP67-rated and wide operating temperature range for reliable outdoor and industrial surveillance
  • Low-light performance (0.3 lux) and Forensic WDR for improved image clarity in varied lighting conditions
31 of 31 specifications
Technical specifications for AXIS F7225-RE Extremely Discreet Pinhole Sensor
General Information
Brand Name AXIS Communications
Manufacturer Axis Communications
Product Line F
Product Name AXIS F7225-RE Pinhole BULK 8 PCS
Product Type Sensor units
Product Model F7225-RE
Product Series F72
Packaged Quantity 8
Manufacturer Part Number 02363021
Technical Information
Aperture f/2.5
Field of View Horizontal, Vertical
Lens Mount Type M12
Application/Usage ATM Machine, Indoor, Outdoor, Surveillance
Maximum Frame Rate 60fps
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Certifications
Ingress Protection Rating IP66, IP67
Display & Graphics
Image Sensor Size 1/2.8"
Maximum Video Resolution 1920 x 1200
Environmental Conditions
Operating Temperature (T-T) -22-131°F
Exposure
Minimum Illumination 0.3 lux
Lens
Focal Length 3.7mm
Physical Characteristics
Depth 0.8"
Width 1"
Height 1.8"
Weight 0.92oz
Package Type Bulk
Warranty
Limited Warranty 5-Year
Miscellaneous
Certifications ECE R10 rev.06, EN 50121-3-2, EN 50121-4, EN 50498, EN 55032 Class B, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-3(B)/NMB-3(B), IEC 62236-4, KS C 9832 Class B, KS C 9835, VCCI Class B
Indoor/Outdoor Outdoor
Environmental Certification EN 50155 Class OT2/ST2 (2007: Class TX), IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-64, IEC 60721-3-5 Class 5M3 (Vibration, Shock), IEC/EN 60529 IP66, IEC/EN 60529 IP67, IEC/EN 61373 Category 1 Class B, NEMA 250 Type 4X

No matching specifications

Try a different term, such as a connector type or resolution.

Plan your purchase

Is this right for your project?

Confirm the model, required accessories and delivery needs before ordering.

SKU:
02363-021
Manufacturer part:
02363-021
How do I confirm compatibility?

Check the specifications and manufacturer documents for your existing system. Send us your model numbers and project requirements if you need help selecting equipment or accessories.

Ask a product specialist
When will this item ship?

Availability is shown above. Special-order items and project quantities may need additional lead time. Contact us to confirm a delivery date before scheduling installation.

Shipping, freight and delivery details
What should I know about returns?

Returns require an approved RMA. Consult the linked return policy for deadlines and eligibility. For standard non-defective returns, eligible factory-sealed items carry a 15% restocking fee and customer-paid return shipping; open-box and used items are refused. Defective and DOA claims follow the policy's separate terms. Special orders and other exclusions are final sale.

Read return eligibility and exclusions

AXIS F7225-RE Extremely Discreet Pinhole Sensor

02363-021

Price & options
