AXIS M5526-E 4MP Indoor Outdoor PTZ Camera with 10x Zoom and Focus Recall
Image of 3
Key Features
- High-resolution 4 MP imaging with 10x optical zoom for clear identification at distance
- Continuous 360° pan and autofocus for seamless area coverage and fast incident response
- Built-in ARTPEC‑8 DLPU and support for AXIS Object Analytics for accurate human and vehicle classification
- Rugged IP66 and IK09-rated dome for dependable outdoor surveillance in harsh environments
- Flexible power and connectivity options (PoE, 24 V) plus onboard storage for simplified deployments
Quick Specifications
- Product Model
- M5526-E
- Brand Name
- AXIS Communications
- Product Line
- M
- Product Name
- AXIS M5526-E 60 Hz
Frequently Bought Together
AXIS M5526-E 4MP Indoor Outdoor PTZ Camera with 10x Zoom and Focus Recall
$1,172.71
4 items selected
Total: $2,932.87
Explore the details
Product information
02769-001
Overview
Designed for reliable perimeter security and active site monitoring, the AXIS M5526-E PTZ camera from Axis Communications delivers high-quality, actionable video where it matters. This PTZ security camera combines 4 MP resolution and 10x optical zoom with continuous 360° pan and fast autofocus so operators and VMS systems capture sharp detail across wide areas without missing critical moments. Built on Axis' ARTPEC-8 platform with an integrated deep learning processing unit (DLPU), the camera supports on-device analytics like AXIS Object Analytics to classify humans and vehicles, reducing false alarms and streamlining event triage. With IP66 and IK09 ratings plus PoE power options and onboard memory support, the compact dome is optimized for outdoor and indoor surveillance installations that demand durability and flexible mounting. Advanced security features such as Axis Edge Vault and HTTPS protect video streams and device integrity, making it suitable for enterprise, transport, and campus monitoring. For resilient, analytics-ready security and efficient operational workflows, specify the AXIS M5526-E for your next surveillance deployment or contact us for mounting and integration guidance.
Features
- High-resolution 4 MP imaging with 10x optical zoom for clear identification at distance
- Continuous 360° pan and autofocus for seamless area coverage and fast incident response
- Built-in ARTPEC‑8 DLPU and support for AXIS Object Analytics for accurate human and vehicle classification
- Rugged IP66 and IK09-rated dome for dependable outdoor surveillance in harsh environments
- Flexible power and connectivity options (PoE, 24 V) plus onboard storage for simplified deployments
| General Information | |
|---|---|
| Brand Name | AXIS Communications |
| Manufacturer | Axis Communications |
| Product Line | M |
| Product Name | AXIS M5526-E 60 Hz |
| Product Type | PTZ cameras |
| Product Model | M5526-E |
| Product Series | M55 |
| Manufacturer Part Number | 02769-001 |
| Supported Network Protocols | IPv6 USGv6, NIST SP500-267 |
| Technical Information | |
| Aperture | f/1.6-3.0 |
| Lens Type | Varifocal |
| Night Vision | Yes |
| Optical Zoom | 10x |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264, H.265, MJPEG, MPEG-4 |
| Maximum Aperture | f/1.6 |
| Video Resolution | Yes |
| Night Vision Type | Infrared (IR) |
| Maximum Frame Rate | 60fps |
| Minimum Focal Length | 4.7mm |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 4MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Certifications | |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Image Sensor Size | 1/3" |
| Maximum Video Resolution | 2688 x 1512 |
| Environmental Conditions | |
| Operating Humidity | 1 |
| Maximum Operating Temperature | 122°F (50°C) |
| Minimum Operating Temperature | -4°F (-20°C) |
| Exposure | |
| Minimum Illumination | 0.01 lux |
| Longest Shutter Speed | 0.2 Second |
| Shortest Shutter Speed | 1/27000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 4.7-47mm |
| Lens Included | Yes |
| Minimum Aperture | f/3 |
| Maximum Focal Length | 47mm |
| Memory | |
| Memory Card Supported | Yes |
| Network & Communication | |
| Remote Management | Yes |
| Others | |
| Model Number Replaces | 01146-001, M5525-E |
| Physical Characteristics | |
| Color | White |
| Height | 5.91" |
| Weight | 2.20lb |
| Durability | Dustproof, Impact Resistant, Waterproof |
| Form Factor | Dome |
| Package Type | Box |
| Power Description | |
| Input Voltage | 20V DC, 28V DC |
| Maximum Power Consumption | 12W |
| Power over Ethernet (PoE) | Yes |
| Product Information | |
| Diameter | 6.5" |
| Mount Type | Recessed Mount |
| Storage | |
| Storage Type | Memory Card |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Features | Day/Night, HTTPS Encryption, Human Detection, Motion Detection, Password Protection, Privacy Masking, Vehicle Detection, White Balance, Wide Dynamic Range |
| Certifications | CISPR 32 Class A, CISPR 35, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A, VCCI Class A |
| Indoor/Outdoor | Outdoor |
| Country of Origin | TH |
| Environmentally Friendly | Yes |
| Impact Protection Rating | IK09 |
| Certifications & Standards | ONVIF G, ONVIF M, ONVIF S, ONVIF T |
| Environmental Certification | EU RoHS, REACH |
