AXIS 02857-001 HDTV 1080p Mk II Modular Standard IP Camera, 111° Field of View, 2.8mm Lens
Image of 1
Key Features
- Discreet, modular design: thumb-sized sensor can be recessed or hidden to blend into indoor environments for covert surveillance.
- Flexible placement: detachable cable up to 15 m lets you separate sensor and main unit to cover blind spots and tight spaces.
- Wide coverage with clarity: HDTV 1080p image quality and a 2.8mm lens with 111° field of view capture broad scenes with detail for effective monitoring.
- Smarter detection on-device: preinstalled AXIS Object Analytics and a deep-learning processing unit reduce false alarms and improve incident verification.
- Easy, low-power deployment: PoE support and 4W maximum consumption simplify installation and lower infrastructure costs.
- Long-term reliability: robust Axis Communications build and a 5-year limited warranty protect your investment in security infrastructure.
Quick Specifications
- Brand Name
- AXIS Communications
- Product Name
- AXIS P1245 Mk II
- Product Type
- Fixed cameras
- Manufacturer Part Number
- 02857-001
Frequently Bought Together
AXIS 02857-001 HDTV 1080p Mk II Modular Standard IP Camera, 111° Field of View, 2.8mm Lens
$419.30
9 items selected
Total: $2,867.67
Product Information Tabs
Overview
Optimize discreet indoor surveillance with the AXIS P1245 Mk II modular covert IP camera from Axis Communications. Designed for loss prevention, sensitive-area monitoring, and unobtrusive security, the thumb-sized sensor can be recessed or hidden while the main unit sits remotely up to 15 m away, enabling flexible installations in retail, hospitality, healthcare, and corporate environments. Capture crisp HDTV 1080p video using the 2.8mm fixed lens with a 111° field of view, and rely on Wide Dynamic Range and a 0.2 lux sensitivity for usable images in varied lighting. Built-in AXIS Object Analytics and a deep learning processing unit run advanced analytics at the edge to reduce false alarms and speed incident response. Power over Ethernet (PoE) support and a compact modular form factor make deployment fast and cost-efficient. Backed by Axis Communications’ quality and a 5-year limited warranty, the P1245 Mk II delivers reliable, scalable surveillance and monitoring where discretion matters. Ideal for covert security installations—contact sales or add to your system design to enhance situational awareness today.
Features
- Discreet, modular design: thumb-sized sensor can be recessed or hidden to blend into indoor environments for covert surveillance.
- Flexible placement: detachable cable up to 15 m lets you separate sensor and main unit to cover blind spots and tight spaces.
- Wide coverage with clarity: HDTV 1080p image quality and a 2.8mm lens with 111° field of view capture broad scenes with detail for effective monitoring.
- Smarter detection on-device: preinstalled AXIS Object Analytics and a deep-learning processing unit reduce false alarms and improve incident verification.
- Easy, low-power deployment: PoE support and 4W maximum consumption simplify installation and lower infrastructure costs.
- Long-term reliability: robust Axis Communications build and a 5-year limited warranty protect your investment in security infrastructure.
| General Information | |
|---|---|
| Brand Name | AXIS Communications |
| Product Name | AXIS P1245 Mk II |
| Product Type | Fixed cameras |
| Manufacturer Part Number | 02857-001 |
| Supported Network Protocols | IPv6 USGv6, NIST SP500-267 |
| Technical Information | |
| Aperture | f/2.0 |
| Lens Type | Fixed |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264 (MPEG-4 Part 10/AVC), H.265 (MPEG-H Part 2/HEVC), MJPEG |
| Lens Mount Type | M12 |
| Maximum Aperture | f/2 |
| Maximum Frame Rate | 30fps |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Certifications | |
| Ingress Protection Rating | IP3X |
| Display & Graphics | |
| Image Sensor Size | 1/2.9" |
| Maximum Video Resolution | 1920 x 1080 |
| Environmental Conditions | |
| Operating Humidity | 10-85% |
| Maximum Operating Temperature | 113°F |
| Minimum Operating Temperature | -4°F |
| Exposure | |
| Minimum Illumination | 0.2 lux |
| Longest Shutter Speed | 1/5 Second |
| Shortest Shutter Speed | 1/16500 Second |
| Lens | |
| Focal Length | 2.8mm |
| Lens Included | Yes |
| Maximum Focal Length | 2.8mm |
| Memory | |
| Memory Card Supported | Yes |
| Others | |
| Model Number Replaces | 0926-001, P1245 |
| Physical Characteristics | |
| Color | White |
| Depth | 0.63" |
| Width | 1.79" |
| Height | 4.66" |
| Form Factor | Modular |
| Package Type | Box |
| Power Description | |
| Maximum Power Consumption | 4W |
| Power over Ethernet (PoE) | Yes |
| Product Information | |
| Mount Type | Recessed Mount |
| Storage | |
| Storage Type | Memory Card |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Features | AXIS Object Analytics pre-installed, Detachable cable up to 15 m, HDTV 1080p with 111° field of view, Small, thumb-sized sensor unit, Support for analytics with deep learning |
| Certifications | CISPR 32 Class A, CISPR 35, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES(A)/NMB(A), KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A, VCCI Class A |
| Indoor/Outdoor | Indoor |
| Package Contents | 2 locking nuts, 8 m (26 ') black cable, Installation Guide, Owner authentication key Main unit, Sensor unit |
| Environmentally Friendly | Yes |
| Certifications & Standards | ONVIF G, ONVIF M, ONVIF S, ONVIF T |
| Environmental Certification | EU RoHS, REACH, RoHS |
