Edwards Signaling 1076W-M Recessed Steel Door Magnetic Contact with Wire Leads, 1" Diameter, SPDT, Wide Gap, 1" Gap Size, Single Pole-Double Throw, White
Image of 1
Key Features
- Reliable steel-door protection with a recessed design that minimizes tampering and preserves door aesthetics
- Wide 1" gap and isolated rare-earth magnet for dependable make/break performance, reducing false alarms
- SPDT (single pole-double throw) wiring for flexible NO/NC configurations to fit most alarm and access control panels
- Quick, tool-friendly installation with ribbed sides and wire-lead connectivity to save labor time on commercial jobs
- Rugged ABS unibody construction and a 5-year limited warranty for long-term durability in high-traffic installations
- Optimized for security, surveillance and monitoring systems in commercial and institutional environments
Quick Specifications
- Product Model
- 1076W-M
- Brand Name
- Edwards Signaling
- Product Name
- 1076W-M Magnetic Contact
- Product Type
- Magnetic Contact
Frequently Bought Together
Edwards Signaling 1076W-M Recessed Steel Door Magnetic Contact with Wire Leads, 1" Diameter, SPDT, Wide Gap, 1" Gap Size, Single Pole-Double Throw, White
$34.37
6 items selected
Total: $188.27
Explore the details
Product information
1076W-M
Overview
Built for commercial steel doors, the Edwards Signaling 1076W-M recessed magnetic contact delivers dependable intrusion detection and seamless integration with security and access control systems. This magnetic contact combines a recessed, low-profile ABS unibody for vandal resistance with an isolated magnet design that achieves a wide 1" gap for reliable make/break performance. The SPDT contact offers flexible wiring options (NO/NC) and the wire-lead termination streamlines connection to alarm panels, monitoring systems, or building management solutions. Contractors and security integrators will appreciate the ribbed-side housing that enables fast, secure mounting without adhesives, reducing install time and service callbacks. Rated for AC/DC operation and finished in white to blend with commercial trim, the 1076W-M is engineered for high-traffic doors where consistent detection and minimal visual impact matter. Backed by a 5-year limited warranty, it’s an ideal choice for access control, surveillance perimeter monitoring, and centralized alarm systems. Order the Edwards 1076W-M for reliable steel-door protection or contact our sales team to specify for your next commercial security project.
Features
- Reliable steel-door protection with a recessed design that minimizes tampering and preserves door aesthetics
- Wide 1" gap and isolated rare-earth magnet for dependable make/break performance, reducing false alarms
- SPDT (single pole-double throw) wiring for flexible NO/NC configurations to fit most alarm and access control panels
- Quick, tool-friendly installation with ribbed sides and wire-lead connectivity to save labor time on commercial jobs
- Rugged ABS unibody construction and a 5-year limited warranty for long-term durability in high-traffic installations
- Optimized for security, surveillance and monitoring systems in commercial and institutional environments
| General Information | |
|---|---|
| Brand Name | Edwards Signaling |
| Manufacturer | Carrier |
| Product Name | 1076W-M Magnetic Contact |
| Product Type | Magnetic Contact |
| Product Model | 1076W-M |
| Product Series | 1076 |
| Manufacturer Part Number | 1076W-M |
| Technical Information | |
| Standard Gap | 1.00" |
| Connectivity Technology | Wired |
| Physical Characteristics | |
| Color | White |
| Depth | 1.10" |
| Width | 1.10" |
| Height | 1.00" |
| Material | ABS |
| Power Description | |
| Power Source | AC Power, DC Power |
| Product Information | |
| Contact Type | Closed Loop, Open Loop, SPDT (Single Pole Double Throw) |
| Installation Type | Commercial |
| Warranty | |
| Limited Warranty | 5-Year |
