GeoVision GV-FER5702 5MP Outdoor WDR Pro IR Fisheye Rugged IP Camera, 1.4mm Lens, White, (Replaces GV-FER5701)

SKU: 125-FER5702-000 GeoVision
GeoVision
Product images for GeoVision GV-FER5702 5MP Outdoor WDR Pro IR Fisheye Rugged IP Camera, 1.4mm Lens, White, (Replaces GV-FER5701). 1 image(s) available. Click on image to view full size.
NDAA Compliant TAA Compliant

Key Features

  • Capture full 180° coverage with a single device to reduce blind spots and lower total camera count
  • Maintain clear, usable footage in challenging lighting using WDR Pro and 5MP resolution for faster incident review
  • Rugged IP66 and IK10-rated housing protects outdoor installations from weather and vandalism, minimizing maintenance
  • PoE connectivity and multiple mount options simplify installation and reduce labor and cabling costs
  • Onboard microSD recording and smart stream H.265 support flexible storage and efficient network bandwidth use

Quick Specifications

Product Model
GV-FER5702
Brand Name
GeoVision
Product Name
5MP H.265 Super Low Lux WDR Pro IR Fisheye Rugged IP Camera
Product Type
Network Camera
View Full Technical Specifications

Frequently Bought Together

This Item
GeoVision GV-FER5702 5MP Outdoor WDR Pro IR Fisheye Rugged IP Camera, 1.4mm Lens, White, (Replaces GV-FER5701)

GeoVision GV-FER5702 5MP Outdoor WDR Pro IR Fisheye Rugged IP Camera, 1.4mm Lens, White, (Replaces GV-FER5701)

$464.36

Frequently Bought Together (6 items)

7 items selected

Total: $1,745.24

Explore the details

Product information

125-FER5702-000

Overview

Secure wider areas with one reliable panoramic camera. The GeoVision GV-FER5702 5MP Outdoor WDR Pro IR Fisheye Rugged IP Camera delivers full 180° surveillance in crisp 5MP detail, making it ideal for retail floors, lobbies, parking areas and campus monitoring. Advanced WDR Pro preserves clarity in backlit or high-contrast scenes while infrared night vision extends monitoring to approximately 65.6 ft for round-the-clock security. Built for demanding outdoor environments, the IP66 and IK10-rated enclosure resists dust, water and impact—reducing downtime and maintenance costs. Power over Ethernet (PoE) and flexible ceiling, wall, pendant or junction box mounts speed deployment and cut installation expense. Integrated microSD storage and H.265 smart stream reduce bandwidth and provide local failover recording for critical evidence retention. As a GeoVision panoramic camera, the GV-FER5702 blends high-resolution imaging, rugged durability and streamlined installation so security teams can monitor more with less. Add this fisheye IP camera to your surveillance system to expand coverage and simplify operations today.

Features

  • Capture full 180° coverage with a single device to reduce blind spots and lower total camera count
  • Maintain clear, usable footage in challenging lighting using WDR Pro and 5MP resolution for faster incident review
  • Rugged IP66 and IK10-rated housing protects outdoor installations from weather and vandalism, minimizing maintenance
  • PoE connectivity and multiple mount options simplify installation and reduce labor and cabling costs
  • Onboard microSD recording and smart stream H.265 support flexible storage and efficient network bandwidth use
51 of 51 specifications
Technical specifications for GeoVision GV-FER5702 5MP Outdoor WDR Pro IR Fisheye Rugged IP Camera, 1.4mm Lens, White, (Replaces GV-FER5701)
General Information
Brand Name GeoVision
Manufacturer GeoVision, Inc
Product Name 5MP H.265 Super Low Lux WDR Pro IR Fisheye Rugged IP Camera
Product Type Network Camera
Product Model GV-FER5702
Product Series GeoVision
Country of Origin TW
Manufacturer Part Number 125-FER5702-000
Technical Information
Lens Type Fixed
Night Vision Yes
Field of View Diagonal, Horizontal, Vertical
Video Formats H.264 / AVC, H.265 / HEVC, MJPEG
Lens Mount Type M12
Night Vision Type Infrared (IR)
Number of IR LEDs 3
Maximum Frame Rate 30fps
Wide Dynamic Range Yes
Minimum Focal Length 1.40mm
Connectivity Technology Wired
Effective Camera Resolution 5MP
Camera
Image Sensor Type CMOS
Night Vision Distance 65.62'
Certifications
TAA Compliant Yes
NDAA Compliant Yes
Ingress Protection Rating IP66
Display & Graphics
Maximum Video Resolution 2592 x 1944
Environmental Conditions
Operating Humidity 95%
Maximum Operating Temperature 140°F
Minimum Operating Temperature -22°F
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 1.4mm
Lens Included Yes
Maximum Focal Length 1.40mm
Network & Communication
Remote Management Yes
Physical Characteristics
Color White
Weight 12.70oz
Durability Rugged
Form Factor Fisheye
Power Description
Input Voltage 12V DC
Product Information
Diameter 4.90"
Mount Type Ceiling Mount, Junction Box Mount, Pendant Mount, Wall Mount
Product Replacements & Other Alternatives
Model Number Replaces 125-FER5701-000GV-FER5701, GV-FER5701
Model Number Alternative DS-2CD3956G2-ISU
Storage
Storage Type SD Card
Video
Maximum Resolution 1280 x 720
Warranty
Limited Warranty 24-Month
Miscellaneous
Features 2D Noise Reduction, 3D Noise Reduction, Automatic White Balance, Built-in Microphone, Day/Night, Privacy Masking, PTZ, Rugged Design, SD Card Local Storage, Smart Stream, Tampering Alarm, Wide Dynamic Range
Indoor/Outdoor Outdoor
Environmentally Friendly Yes
Impact Protection Rating IK10
Environmental Certification RoHS
