GeoVision GV-FER5702 5MP Outdoor WDR Pro IR Fisheye Rugged IP Camera, 1.4mm Lens, White, (Replaces GV-FER5701)
Key Features
- Capture full 180° coverage with a single device to reduce blind spots and lower total camera count
- Maintain clear, usable footage in challenging lighting using WDR Pro and 5MP resolution for faster incident review
- Rugged IP66 and IK10-rated housing protects outdoor installations from weather and vandalism, minimizing maintenance
- PoE connectivity and multiple mount options simplify installation and reduce labor and cabling costs
- Onboard microSD recording and smart stream H.265 support flexible storage and efficient network bandwidth use
Quick Specifications
- Product Model
- GV-FER5702
- Brand Name
- GeoVision
- Product Name
- 5MP H.265 Super Low Lux WDR Pro IR Fisheye Rugged IP Camera
- Product Type
- Network Camera
Frequently Bought Together
GeoVision GV-FER5702 5MP Outdoor WDR Pro IR Fisheye Rugged IP Camera, 1.4mm Lens, White, (Replaces GV-FER5701)
$464.36
7 items selected
Total: $1,745.24
Explore the details
Product information
125-FER5702-000
Overview
Secure wider areas with one reliable panoramic camera. The GeoVision GV-FER5702 5MP Outdoor WDR Pro IR Fisheye Rugged IP Camera delivers full 180° surveillance in crisp 5MP detail, making it ideal for retail floors, lobbies, parking areas and campus monitoring. Advanced WDR Pro preserves clarity in backlit or high-contrast scenes while infrared night vision extends monitoring to approximately 65.6 ft for round-the-clock security. Built for demanding outdoor environments, the IP66 and IK10-rated enclosure resists dust, water and impact—reducing downtime and maintenance costs. Power over Ethernet (PoE) and flexible ceiling, wall, pendant or junction box mounts speed deployment and cut installation expense. Integrated microSD storage and H.265 smart stream reduce bandwidth and provide local failover recording for critical evidence retention. As a GeoVision panoramic camera, the GV-FER5702 blends high-resolution imaging, rugged durability and streamlined installation so security teams can monitor more with less. Add this fisheye IP camera to your surveillance system to expand coverage and simplify operations today.
Features
- Capture full 180° coverage with a single device to reduce blind spots and lower total camera count
- Maintain clear, usable footage in challenging lighting using WDR Pro and 5MP resolution for faster incident review
- Rugged IP66 and IK10-rated housing protects outdoor installations from weather and vandalism, minimizing maintenance
- PoE connectivity and multiple mount options simplify installation and reduce labor and cabling costs
- Onboard microSD recording and smart stream H.265 support flexible storage and efficient network bandwidth use
| General Information | |
|---|---|
| Brand Name | GeoVision |
| Manufacturer | GeoVision, Inc |
| Product Name | 5MP H.265 Super Low Lux WDR Pro IR Fisheye Rugged IP Camera |
| Product Type | Network Camera |
| Product Model | GV-FER5702 |
| Product Series | GeoVision |
| Country of Origin | TW |
| Manufacturer Part Number | 125-FER5702-000 |
| Technical Information | |
| Lens Type | Fixed |
| Night Vision | Yes |
| Field of View | Diagonal, Horizontal, Vertical |
| Video Formats | H.264 / AVC, H.265 / HEVC, MJPEG |
| Lens Mount Type | M12 |
| Night Vision Type | Infrared (IR) |
| Number of IR LEDs | 3 |
| Maximum Frame Rate | 30fps |
| Wide Dynamic Range | Yes |
| Minimum Focal Length | 1.40mm |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 5MP |
| Camera | |
| Image Sensor Type | CMOS |
| Night Vision Distance | 65.62' |
| Certifications | |
| TAA Compliant | Yes |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Maximum Video Resolution | 2592 x 1944 |
| Environmental Conditions | |
| Operating Humidity | 95% |
| Maximum Operating Temperature | 140°F |
| Minimum Operating Temperature | -22°F |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 1.4mm |
| Lens Included | Yes |
| Maximum Focal Length | 1.40mm |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | White |
| Weight | 12.70oz |
| Durability | Rugged |
| Form Factor | Fisheye |
| Power Description | |
| Input Voltage | 12V DC |
| Product Information | |
| Diameter | 4.90" |
| Mount Type | Ceiling Mount, Junction Box Mount, Pendant Mount, Wall Mount |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | 125-FER5701-000GV-FER5701, GV-FER5701 |
| Model Number Alternative | DS-2CD3956G2-ISU |
| Storage | |
| Storage Type | SD Card |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 24-Month |
| Miscellaneous | |
| Features | 2D Noise Reduction, 3D Noise Reduction, Automatic White Balance, Built-in Microphone, Day/Night, Privacy Masking, PTZ, Rugged Design, SD Card Local Storage, Smart Stream, Tampering Alarm, Wide Dynamic Range |
| Indoor/Outdoor | Outdoor |
| Environmentally Friendly | Yes |
| Impact Protection Rating | IK10 |
| Environmental Certification | RoHS |
