GeoVision GV-TDR8805 8MP H.265 Super Low Lux WDR Pro IR Mini Rugged Dome IP Camera, 2.8mm Fixed Lens, White
Image of 1
Key Features
- 8MP 4K clarity with H.265 compression — delivers identifiable video while lowering bandwidth and storage costs
- AI perimeter protection that classifies human and vehicle targets to reduce false alarms and improve response
- IP67 weatherproof and IK10 vandal-resistant housing with PoE for reliable outdoor operation and simplified installs
- Intelligent IR up to 30m and WDR Pro for consistent 24/7 monitoring in low light and high-contrast scenes
- Flexible 2.8mm wide-angle lens, 3-axis adjustment and local SD storage for easy deployment and scalable surveillance
Quick Specifications
- Product Model
- GV-TDR8805
- Brand Name
- GeoVision
- Product Name
- 8MP H.265 Super Low Lux WDR Pro IR Mini Fixed Rugged IP Dome
- Product Type
- Network Camera
Frequently Bought Together
GeoVision GV-TDR8805 8MP H.265 Super Low Lux WDR Pro IR Mini Rugged Dome IP Camera, 2.8mm Fixed Lens, White
$205.83
11 items selected
Total: $2,138.86
Product Information Tabs
Overview
Secure critical outdoor perimeters with the GeoVision GV-TDR8805 8MP dome IP camera — a rugged surveillance solution built for commercial security and continuous monitoring. Delivering true 8MP (3840 x 2160) resolution with H.265 compression and WDR Pro, this GeoVision dome camera produces crisp, actionable video while reducing network bandwidth and storage requirements. Advanced AI deep-learning analytics classify humans and vehicles for precision perimeter protection, enabling real-time alerts and fewer false alarms when integrated with GeoVision VMS.
Designed for demanding environments, the GV-TDR8805 meets IP67 and IK10 standards and supports PoE for faster, lower-cost installations. A 2.8mm fixed lens provides a wide 112.9° field of view and intelligent IR illumination extends night visibility up to 30m (100') for reliable 24/7 monitoring. Practical features like 3-axis adjustment, SD card local storage, and triple-stream H.265/H.264/MJPEG make deployment and system scaling straightforward.
Ideal for parking lots, campuses, retail exteriors and industrial sites, this GeoVision dome camera delivers high-resolution security monitoring with smarter alarm handling. Contact us to specify the GV-TDR8805 for your next surveillance project.
Features
- 8MP 4K clarity with H.265 compression — delivers identifiable video while lowering bandwidth and storage costs
- AI perimeter protection that classifies human and vehicle targets to reduce false alarms and improve response
- IP67 weatherproof and IK10 vandal-resistant housing with PoE for reliable outdoor operation and simplified installs
- Intelligent IR up to 30m and WDR Pro for consistent 24/7 monitoring in low light and high-contrast scenes
- Flexible 2.8mm wide-angle lens, 3-axis adjustment and local SD storage for easy deployment and scalable surveillance
| General Information | |
|---|---|
| Brand Name | GeoVision |
| Manufacturer | GeoVision, Inc |
| Product Name | 8MP H.265 Super Low Lux WDR Pro IR Mini Fixed Rugged IP Dome |
| Product Type | Network Camera |
| Product Model | GV-TDR8805 |
| Product Series | GeoVision |
| Manufacturer Part Number | 125-TDR885W-2F10 |
| Technical Information | |
| Lens Type | Fixed |
| Night Vision | Yes |
| Field of View | 112.9° |
| Video Formats | H.264, H.265, MJPEG |
| Lens Mount Type | M12 |
| Maximum Aperture | f/1.6 |
| Night Vision Type | Infrared |
| Number of IR LEDs | 1 |
| Maximum Frame Rate | 30fps |
| Minimum Focal Length | 2.8mm |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 8MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 98.43 ft |
| Certifications | |
| TAA Compliant | No |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP67 |
| Display & Graphics | |
| Maximum Video Resolution | 3840 x 2160 |
| Environmental Conditions | |
| Operating Humidity | 0.95 |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Operating Temperature | -22°F (-30°C) |
| Exposure | |
| Longest Shutter Speed | 1 Second |
| Shortest Shutter Speed | 1/100000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 2.8mm |
| Lens Included | Yes |
| Maximum Focal Length | 2.8mm |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | White |
| Weight | 15.17oz |
| Durability | Dustproof, Impact Resistant, Vandal Resistant, Waterproof |
| Form Factor | Dome |
| Power Description | |
| Input Voltage | 12V DC |
| Product Information | |
| Diameter | 4.3" |
| Mount Type | Box Mount, Bracket Mount, Ceiling Mount, Corner Mount, Junction Box Mount, Pendant Mount, Pole Mount, Straight Tube Mount, Wall Mount |
| Storage | |
| Storage Type | Memory Card |
| Recording Formats | 4K |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 24-Month |
| Miscellaneous | |
| Features | 3-Axis Adjustable, 3D Digital Noise Reduction, Built-in IR LED, Cross Line Detection, Day/Night, Face Detection, Removable IR Cut-off Filter, SD Card Local Storage, Wide Dynamic Range |
| Indoor/Outdoor | Outdoor |
| Country of Origin | CN |
| Environmentally Friendly | Yes |
| Impact Protection Rating | IK10 |
| Environmental Certification | RoHS |
