GRI 180-12WG 180 Series 3/4" Steel Door Recessed Switch Set, Wide Gap, 10W, 200VDC, 0.40 Amp, Closed Loop, N/O, A, and U.L. 10C Fire Rated, White
Image of 1
Key Features
- Reliable wide-gap detection for steel doors — over 1" sensing gap ensures consistent monitoring on heavy-duty frames.
- Closed-loop N/O configuration simplifies integration with access control and intrusion monitoring systems.
- Durable steel, self-locking design with UL/ULC approval and UL 10C fire rating reduces maintenance and meets code requirements.
- Quick installation with standard 12" leads and wired connectivity cuts labor time and lowers total installation cost.
- Backed by a lifetime warranty from George Risk Industries for long-term reliability and lower lifecycle expense.
Quick Specifications
- Product Model
- 180-12WG
- Brand Name
- George Risk Industries
- Product Name
- 180-12WG Magnetic Contact
- Product Type
- Magnetic Contact
Frequently Bought Together
GRI 180-12WG 180 Series 3/4" Steel Door Recessed Switch Set, Wide Gap, 10W, 200VDC, 0.40 Amp, Closed Loop, N/O, A, and U.L. 10C Fire Rated, White
$7.61
8 items selected
Total: $54.14
Explore the details
Product information
180-12WG-W
Overview
Ensure dependable door monitoring for commercial and industrial steel doors with the George Risk Industries GRI 180-12WG recessed magnetic contact. Designed as a purpose-built magnetic contact for access control, intrusion detection and security monitoring, this 3/4" recessed switch set delivers reliable performance even on heavy-duty frames thanks to a wide gap capability (standard 0.75", over 1" on steel). The closed-loop N/O contact and 10W / 0.40A / 200VDC ratings make it easy to integrate with alarm panels, surveillance systems and building automation.
Built from steel with a self-locking, one-piece design and UL/ULC approvals — including a UL 10C fire rating — the 180-12WG minimizes service calls and complies with safety requirements. Standard 12" leads speed installation and eliminate extra labor for soldering or terminal work. Ideal for retrofits or new builds where dependable door supervision and low maintenance are priorities.
Specify the GRI 180-12WG for robust security and access control on steel doors — add to your system or contact sales for bulk orders and project support.
Features
- Reliable wide-gap detection for steel doors — over 1" sensing gap ensures consistent monitoring on heavy-duty frames.
- Closed-loop N/O configuration simplifies integration with access control and intrusion monitoring systems.
- Durable steel, self-locking design with UL/ULC approval and UL 10C fire rating reduces maintenance and meets code requirements.
- Quick installation with standard 12" leads and wired connectivity cuts labor time and lowers total installation cost.
- Backed by a lifetime warranty from George Risk Industries for long-term reliability and lower lifecycle expense.
| General Information | |
|---|---|
| Brand Name | George Risk Industries |
| Manufacturer | George Risk Industries |
| Product Name | 180-12WG Magnetic Contact |
| Product Type | Magnetic Contact |
| Product Model | 180-12WG |
| Product Series | 180 |
| Country of Origin | US |
| Manufacturer Part Number | 180-12WG-W |
| Technical Information | |
| Standard Gap | 0.75" |
| Connectivity Technology | Wired |
| Physical Characteristics | |
| Color | White |
| Material | Steel |
| Power Description | |
| Power Source | DC Power |
| Product Information | |
| Contact Type | NO (Normally Open) |
| Installation Type | Commercial |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | 1078CW-N |
| Warranty | |
| Limited Warranty | Lifetime |
| Miscellaneous | |
| Features | Closed loop, Electrical Configuration - N/O, Maximum Contact Rating - 10W, Maximum Switching Current - 0.400A, Maximum Switching Voltage - 200VDC, Wide Gap 1"+ Gap on Steel, Wide gap 3/4"+Self-locking |
