ORION Images 19HSDI3G 18.5" SD/HD/3G-SDI Full HD LED LCD Monitor
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 3
Key Features
- Broadcast-grade 3G-SDI inputs (Level A/B) for reliable, low-latency video integration with SD/HD security cameras and DVR/NVR systems
- HD 18.5-inch LED panel (1366 x 768) with 250 cd/m² brightness and 1000:1 contrast for clear image detail and faster incident assessment
- Multiple inputs (HDMI, DVI, VGA, composite) simplify connections to cameras, encoders and PCs without extra adapters
- PIP/PBP multi-display plus non-glare coating to monitor multiple feeds and reduce operator eye fatigue in control rooms
- Energy-efficient LED backlight and rugged galvanized metal frame built for continuous 24/7 surveillance use and lower operating cost
- VESA-compatible mounting and a 3-year limited warranty for flexible installation and long-term protection
Quick Specifications
- Product Model
- 19HSDI3G
- Brand Name
- ORION Images
- Product Name
- HD-SDI 3G Monitor
- Product Type
- LCD Monitor
Explore the details
Product information
19HSDI3G
Overview
Designed for security professionals, the ORION Images 19HSDI3G is an HD surveillance monitor built to deliver dependable, real-time video monitoring in control rooms and security stations. This 18.5-inch LED LCD monitor supports SD / HD / 3G-SDI (Level A/B) alongside HDMI, VGA and DVI inputs, making it easy to integrate with cameras, DVRs and NVRs. The 1366 x 768 display, 250 cd/m² brightness and 1000:1 contrast ratio provide crisp image detail for rapid incident verification and evidence capture.
Operators benefit from practical monitoring features including PIP/PBP multi-view, a non-glare surface for bright environments, and an energy-saving LED backlight that reduces operating costs during continuous use. The galvanized metal frame and VESA-compatible design ensure secure mounting in control rooms, mobile units or wall/ceiling installations. Backed by a 3-year limited warranty, the 19HSDI3G offers reliable performance for long-term security deployments. Upgrade your surveillance workflow with a monitor optimized for monitoring, recording and live video assessment — ideal for security integrators and facilities managers seeking dependable, broadcast-grade imaging. Order or request a quote to add this monitor to your security system.
Features
- Broadcast-grade 3G-SDI inputs (Level A/B) for reliable, low-latency video integration with SD/HD security cameras and DVR/NVR systems
- HD 18.5-inch LED panel (1366 x 768) with 250 cd/m² brightness and 1000:1 contrast for clear image detail and faster incident assessment
- Multiple inputs (HDMI, DVI, VGA, composite) simplify connections to cameras, encoders and PCs without extra adapters
- PIP/PBP multi-display plus non-glare coating to monitor multiple feeds and reduce operator eye fatigue in control rooms
- Energy-efficient LED backlight and rugged galvanized metal frame built for continuous 24/7 surveillance use and lower operating cost
- VESA-compatible mounting and a 3-year limited warranty for flexible installation and long-term protection
| General Information | |
|---|---|
| Brand Name | ORION Images |
| Manufacturer | ORION Images Corporation |
| Product Name | HD-SDI 3G Monitor |
| Product Type | LCD Monitor |
| Product Model | 19HSDI3G |
| Product Series | HD-SDI |
| Manufacturer Part Number | 19HSDI3G |
| Technical Information | |
| Viewable Screen Size | 18.5" |
| Audio | |
| Speakers | Yes |
| Display & Graphics | |
| Screen Size | 19" |
| Number of Screens | 1 |
| Backlight Technology | LED |
| Image | |
| Aspect Ratio | 16:9 |
| Interfaces/Ports | |
| VGA | Yes |
| HDMI | Yes |
| Physical Characteristics | |
| Color | Black |
| Depth | 3.6" |
| Width | 17.6" |
| Height | 11.7" |
| Weight | 10.80 lb |
| VESA Mount Standard | 100 x 100 |
| VESA Mount Compatible | Yes |
| Product Information | |
| Mount Type | Ceiling Mount, Wall Mount |
| Display Screen Type | LCD |
| Video | |
| Contrast Ratio | 1,000:1 |
| Graphics Modes | HD |
| Brightness (Nit) | 250 |
| Maximum Resolution | 1366 x 768 |
| Standard Refresh Rate | 60 Hz |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Non-glare surface coating |
| Country of Origin | KR |
