Genesis 22071109 22/8 Stranded Shielded Cable, Riser, CMR, FT4, 1000' (304.8 m) Pull Box, Gray
Image of 4
Key Features
- Protects sensitive security and surveillance signals from EMI/RFI with full foil shielding to ensure reliable monitoring and fewer false alarms
- Stranded 22 AWG bare copper conductors deliver flexible runs and consistent low-voltage performance for access control, audio and CCTV devices
- Riser-rated CMR (FT4) PVC jacket for compliant indoor vertical installations in commercial buildings
- 1000' pull box with countdown length markings and rip cord speeds installation, reduces labor time and material waste
- Durable, sunlight-resistant construction and -20°C to 75°C rating for dependable indoor performance in varied environments
- RoHS/REACH and TAA compliant with a 3-year limited warranty for procurement confidence and regulatory compliance
Quick Specifications
- Product Model
- 22071109
- Brand Name
- Genesis
- Product Name
- 22071109 - 22 AWG 8C STR Shielded Riser, Gray, 1000 FT. Pull Box
- Product Type
- Access & Security Cable
Explore the details
Product information
22071109
Overview
Optimize your security and monitoring installations with the Genesis 22071109 22/8 stranded shielded riser cable — engineered to keep low-voltage signals clean and dependable. This Genesis riser shielded cable is ideal for surveillance, access control, and audio systems where interference can compromise performance. The foil shield over all conductors minimizes electromagnetic and radio-frequency noise, helping reduce false alarms and maintain crisp video and sensor data.
Designed for installers, the 22 AWG stranded bare copper conductors provide flexibility for tight pathways while delivering consistent conductivity. The cable includes four pairs (8 conductors) in a 1000' pull box with convenient countdown length markings and a rip cord for fast jacket removal, speeding deployment on large projects. Its CMR/FT4 PVC jacket meets riser-rated requirements for vertical building runs and is UV-resistant for reliable indoor durability.
Specify this Genesis shielded multi-conductor cable for commercial security, CCTV, access control and monitoring networks that demand interference protection and quick installation. Order a 1000' pull box today to streamline installation and improve signal integrity across your system.
Features
- Protects sensitive security and surveillance signals from EMI/RFI with full foil shielding to ensure reliable monitoring and fewer false alarms
- Stranded 22 AWG bare copper conductors deliver flexible runs and consistent low-voltage performance for access control, audio and CCTV devices
- Riser-rated CMR (FT4) PVC jacket for compliant indoor vertical installations in commercial buildings
- 1000' pull box with countdown length markings and rip cord speeds installation, reduces labor time and material waste
- Durable, sunlight-resistant construction and -20°C to 75°C rating for dependable indoor performance in varied environments
- RoHS/REACH and TAA compliant with a 3-year limited warranty for procurement confidence and regulatory compliance
| General Information | |
|---|---|
| Brand Name | Genesis |
| Manufacturer | Genesis Cable |
| Product Name | 22071109 - 22 AWG 8C STR Shielded Riser, Gray, 1000 FT. Pull Box |
| Product Type | Access & Security Cable |
| Product Model | 22071109 |
| Packaged Quantity | 1 |
| Manufacturer Part Number | 22071109 |
| Technical Information | |
| Material | Bare Copper |
| Impedance | 59 ohms |
| Shielding | Yes |
| Cable Type | Multi-conductor, Multi-pair |
| Jacket Type | FT4, Riser |
| Cable Rating | Riser |
| Conductor Count | 4 |
| Jacket Material | PVC |
| Number of Pairs | 4 |
| Device Supported | Audio Device, Security Device |
| Solid or Stranded | Stranded |
| Conductor Material | Bare Copper |
| American Wire Gauge | 22AWG |
| Number of Conductors | 8 |
| Connector on First End | Bare Wire |
| Core/Cladding Diameter | 22/8 |
| Certifications | |
| TAA Compliant | Yes |
| Others | |
| Model Number Replaces | 12071109 |
| Physical Characteristics | |
| Color | Gray |
| Weight | 25.80 lb |
| Cable Length | 1000' |
| Package Type | Pull Box |
| Insulation Material | PP |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Stranded |
| Indoor/Outdoor | Indoor |
| Country of Origin | US |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
