West Penn 226BK1000 14/2 Stranded Audio Cable, 1000' (304.8m) Reel, Black

SKU: 226BK1000 West Penn Wire
West Penn Audio/Control Cable
Product images for West Penn 226BK1000 14/2 Stranded Audio Cable, 1000' (304.8m) Reel, Black. 1 image(s) available. Click on image to view full size.

Key Features

  • Flexible stranded 14 AWG construction makes routing and termination fast and reduces installation time
  • Riser-rated PVC jacket for safe, code-compliant vertical runs in commercial buildings
  • 1000' black reel minimizes splices and site waste—ideal for large speaker and paging systems
  • BareWire design supports custom terminations for clean, professional speaker and security connections
  • Reliable audio performance for clear paging, surveillance audio, and monitoring applications
  • RoHS compliant with a 10-year limited warranty for long-term peace of mind

Quick Specifications

Product Model
226BK1000
Brand Name
West Penn Wire
Package Type
Reel/Spool
Product Name
1P 14G STRD USHLD PVC JKT
View Full Technical Specifications

Explore the details

Product information

226BK1000

Overview

Deliver clear, dependable audio across commercial and security installations with the West Penn Wire 226BK1000 14/2 Stranded Audio Cable. Built as part of West Penn's riser audio cables lineup, this 14 AWG stranded pair on a 1000' black reel combines flexibility and power handling to support long speaker runs, paging systems, and audio feeds for surveillance and monitoring equipment. The stranded conductors simplify routing through conduit and tight pathways, while the riser-rated PVC jacket meets building code requirements for vertical runs between floors. The BareWire design gives technicians the freedom to terminate directly to speaker terminals, patch panels, or security devices for a clean, professional finish. With no shield and a durable jacket, this cable is optimized for speaker and low-voltage audio/control use where reliable signal and ease of installation matter most. Backed by RoHS compliance and a 10-year limited warranty, it’s a practical choice for integrators specifying audio wiring for commercial, retail, hospitality, and security projects. Order the 226BK1000 for efficient installs and consistent audio performance in monitoring, surveillance, and paging applications.

Features

  • Flexible stranded 14 AWG construction makes routing and termination fast and reduces installation time
  • Riser-rated PVC jacket for safe, code-compliant vertical runs in commercial buildings
  • 1000' black reel minimizes splices and site waste—ideal for large speaker and paging systems
  • BareWire design supports custom terminations for clean, professional speaker and security connections
  • Reliable audio performance for clear paging, surveillance audio, and monitoring applications
  • RoHS compliant with a 10-year limited warranty for long-term peace of mind
27 of 27 specifications
Technical specifications for West Penn 226BK1000 14/2 Stranded Audio Cable, 1000' (304.8m) Reel, Black
General Information
Brand Name West Penn Wire
Manufacturer Belden CDT, Inc
Package Type Reel/Spool
Product Name 1P 14G STRD USHLD PVC JKT
Product Type Audio/Control Cable
Application/Usage Audio, Control, Alarm Initiating Devices and Low Voltage Power
Manufacturer Part Number 226BK1000
Technical Information
Shielding No
Jacket Type TC
Cable Rating Riser
Conductor Count 1
Number of Pairs 1
Device Supported Audio Device, Security Device
Solid or Stranded Stranded
American Wire Gauge 14AWG
Number of Conductors 2
Certifications
RoHS Compliant Not Evaluated
Certifications & Standards UL1666 Vertical Shaft
Physical Characteristics
Color Black
Weight 42.00lb
Cable Length 1000'
Jacket Material PVC (Polyvinyl Chloride)
Insulation Material PVC
Warranty
Limited Warranty 10-Year
Miscellaneous
Features Stranded
Environmentally Friendly Yes
Environmental Certification RoHS
