Belden 2413 009A1000 Category 6+ Enhanced Premise Horizontal Cable 350MHz, 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Plenum-CMP, Flamarrest PVC-LS Jacket, White, Reel-in-Box, 1,000'

SKU: 2413-009A1000 MPN: 2413 009A1000 Belden
Image of 7B-2413009A1
Product images for Belden 2413 009A1000 Category 6+ Enhanced Premise Horizontal Cable 350MHz, 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Plenum-CMP, Flamarrest PVC-LS Jacket, White, Reel-in-Box, 1,000'. 1 image(s) available. Click on image to view full size.

Key Features

  • Deliver dependable high-bandwidth connections for IP cameras, access points and PoE devices with Category 6+ 350MHz performance.
  • Reduce installation time and waste with a 1,000' reel-in-a-box engineered for large premises and easier cable runs.
  • Ensure long-term signal integrity with 23 AWG solid bare copper conductors that minimize attenuation on horizontal runs.
  • Meet plenum fire-safety requirements using the Flamarrest PVC-LS CMP jacket for compliant installations in air-handling spaces.
  • Power and simplify deployments: supports PoE, PoE+ and PoE++ to eliminate separate power cabling for security and monitoring systems.

Quick Specifications

Product Model
2413 009A1000
Brand Name
Belden
Package Type
Reel-in-a-Box
Product Name
2413 Multi-Conductor - Enhanced Category 6 Nonbonded-Pair Cables
View Full Technical Specifications

Explore the details

Product information

2413 009A1000

Overview

Deploy reliable, high-performance network and security infrastructure with the Belden 2413 Category 6+ Enhanced Premise Horizontal Cable. Designed for critical applications such as IP surveillance, access control and facility monitoring, this Belden Category 6 network cable delivers up to 350MHz bandwidth and consistent throughput for demanding environments. Four pairs of 23 AWG solid bare copper conductors preserve signal integrity across horizontal runs, while the CMP-rated Flamarrest PVC-LS plenum jacket provides flame resistance required for air-handling spaces and code-compliant installations.

Ideal for enterprise security, campus surveillance and commercial networking, this 1,000' reel-in-a-box minimizes waste and speeds bulk installations. The cable supports Gigabit Ethernet (1000BASE-T) and high-power PoE deployments—so cameras, access points and sensors can be powered and connected over a single cable. Backed by Belden’s reputation for durable cabling, the 2413 series helps reduce downtime and maintenance costs while future-proofing your premise wiring.

Specify Belden 2413 Category 6+ plenum cable for secure, code-compliant surveillance and networking projects—order the 1,000' reel today to streamline installation and maximize uptime.

Features

  • Deliver dependable high-bandwidth connections for IP cameras, access points and PoE devices with Category 6+ 350MHz performance.
  • Reduce installation time and waste with a 1,000' reel-in-a-box engineered for large premises and easier cable runs.
  • Ensure long-term signal integrity with 23 AWG solid bare copper conductors that minimize attenuation on horizontal runs.
  • Meet plenum fire-safety requirements using the Flamarrest PVC-LS CMP jacket for compliant installations in air-handling spaces.
  • Power and simplify deployments: supports PoE, PoE+ and PoE++ to eliminate separate power cabling for security and monitoring systems.
35 of 35 specifications
Technical specifications for Belden 2413 009A1000 Category 6+ Enhanced Premise Horizontal Cable 350MHz, 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Plenum-CMP, Flamarrest PVC-LS Jacket, White, Reel-in-Box, 1,000'
General Information
Brand Name Belden
Manufacturer Belden CDT, Inc
Package Type Reel-in-a-Box
Product Name 2413 Multi-Conductor - Enhanced Category 6 Nonbonded-Pair Cables
Product Type Network Cable
Application/Usage Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE, PoE+, PoE++, Premise Horizontal Cable
Manufacturer Part Number 2413 009A1000
Technical Information
Shielding No
Cable Type Category 6
Cable Style Unshielded
Jacket Type CMP, Plenum Duplex Zip
Cable Rating Plenum
Conductor Count 8
Number of Pairs 4
Device Supported Network Device
Solid or Stranded Solid
Conductor Material Bare Copper
American Wire Gauge 23AWG
CPR Euroclass Rating Eca,EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16
Number of Conductors 8
Certifications
UL Listed Yes
Certifications & Standards CMP;CMP-LP (0.5A);CL3P-LP (0.5A),ANSI/NEMA WC-66,Article 800,ANSI/TIA-568.2-D Category 6,IEC 60332-1-2,IEEE 802.3bt Type 1, Type 2, Type 3, Type 4,Plenum,CMP,FT6,Yes,CMP,IEC 60332-1-2,IEEE 802.3bt Type 1, Type 2, Type 3, Type 4,CMP;CMP-LP (
Environmental Conditions
Storage Temperature (T-T) -20°C to +75°C
Operating Temperature (T-T) 0°C to +50°C
Media & Performance
Data Transfer Rate 100Mbps
Physical Characteristics
Height 1000.0'
Material Bare Copper, PVC
Cable Length 1000'
Jacket Material PVC (Polyvinyl Chloride)
Power Description
Voltage Rating 300V
Product Information
Length 1000'
Miscellaneous
Features Premise Horizontal Cable,N/A to N/A
Indoor/Outdoor Indoor
Environmentally Friendly Yes
Environmental Certification China RoHS, ELV, EU RoHS, RoHS, RoHS 2, WEEE
