ORION Images 24RPE 24" Full HD PoE Monitor Plus Additional Lan Out
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 3
Key Features
- Simplified PoE installation: RJ45 PoE input powers the monitor and reduces separate power cabling for faster deployment and lower labor costs
- LAN passthrough for networking: Additional LAN out lets you daisy-chain network devices or cameras for tidy, single-cable installations
- Clear 24" Full HD imagery: 1920x1080 resolution with 250 nits and 1000:1 contrast improves identification and situational awareness in surveillance environments
- Flexible video inputs: HDMI, VGA and BNC support mixed CCTV and IP workflows for easy integration with recorders and cameras
- Designed for continuous operation: Low 35W power draw, 5ms response and 3-year warranty deliver reliable, energy-efficient monitoring for control rooms and security stations
Quick Specifications
- Product Model
- 24RPE
- Brand Name
- ORION Images
- Product Name
- The ORION Images PoE monitor Series. Screen Size 21.5inch/ 23.8inch LED backlights
- Product Type
- Monitor
Explore the details
Product information
24RPE
Overview
Designed for security professionals who need reliable, easy-to-install displays, the ORION Images 24RPE PoE monitor puts surveillance efficiency first. This 24" Full HD video surveillance monitor supplies power over Ethernet (RJ45 PoE) to eliminate extra power wiring while an additional LAN out enables clean daisy-chaining of cameras or switches — ideal for retail, transport hubs and control rooms. With 1920x1080 resolution, 250 nits brightness and a 1000:1 contrast ratio, the 24RPE delivers crisp live video and playback that helps operators spot details quickly. Multiple inputs (HDMI, VGA, BNC) and OSD controls make integration with NVRs, DVRs and hybrid systems straightforward, while VESA mounting and a compact freestanding design fit varied installation needs. At just 35W operating power and a responsive 5ms panel, it’s built for continuous monitoring with lower energy costs and proven reliability backed by a 3-year warranty. Upgrade your security monitoring setup with the ORION Images 24RPE for a cleaner installation and clearer situational awareness — contact sales or add to cart to specify for your next surveillance deployment.
Features
- Simplified PoE installation: RJ45 PoE input powers the monitor and reduces separate power cabling for faster deployment and lower labor costs
- LAN passthrough for networking: Additional LAN out lets you daisy-chain network devices or cameras for tidy, single-cable installations
- Clear 24" Full HD imagery: 1920x1080 resolution with 250 nits and 1000:1 contrast improves identification and situational awareness in surveillance environments
- Flexible video inputs: HDMI, VGA and BNC support mixed CCTV and IP workflows for easy integration with recorders and cameras
- Designed for continuous operation: Low 35W power draw, 5ms response and 3-year warranty deliver reliable, energy-efficient monitoring for control rooms and security stations
| General Information | |
|---|---|
| Brand Name | ORION Images |
| Manufacturer | ORION Images |
| Product Name | The ORION Images PoE monitor Series. Screen Size 21.5inch/ 23.8inch LED backlights |
| Product Type | Monitor |
| Product Model | 24RPE |
| Manufacturer Part Number | 24RPE |
| Technical Information | |
| Bluetooth | No |
| Aspect Ratio | 16:9 |
| Response Time | 5ms |
| Stand Included | Yes |
| Backlight Technology | LED |
| Viewable Screen Size | 22.0" |
| Audio | |
| Speakers | No |
| Display & Graphics | |
| Screen Size | 24" |
| Energy & Performance | |
| Operating Power Consumption | 35W |
| Interfaces/Ports | |
| HDMI | Yes |
| Microphone | No |
| Number of USB Ports | 1 |
| Number of HDMI Inputs | 1 |
| Physical Characteristics | |
| VESA Mount Compatible | Yes |
| Product Information | |
| Mount Type | Freestanding |
| Video | |
| Graphics Mode | Full HD |
| Contrast Ratio | 16:01 |
| Brightness (Nit) | 250 |
| Maximum Resolution | 1920 x 1080 |
| Standard Refresh Rate | 60Hz |
| Warranty | |
| Limited Warranty | 3-Year |
No matching specifications
Try a different term, such as a connector type or resolution.
Plan your purchase
Is this right for your project?
Confirm the model, required accessories and delivery needs before ordering.
- SKU:
- 24RPE
- Manufacturer part:
- 24RPE
How do I confirm compatibility?
Check the specifications and manufacturer documents for your existing system. Send us your model numbers and project requirements if you need help selecting equipment or accessories.
Ask a product specialistWhen will this item ship?
Availability is shown above. Special-order items and project quantities may need additional lead time. Contact us to confirm a delivery date before scheduling installation.
Shipping, freight and delivery detailsWhat should I know about returns?
Returns require an approved RMA. Consult the linked return policy for deadlines and eligibility. For standard non-defective returns, eligible factory-sealed items carry a 15% restocking fee and customer-paid return shipping; open-box and used items are refused. Defective and DOA claims follow the policy's separate terms. Special orders and other exclusions are final sale.
Read return eligibility and exclusionsORION Images 24RPE 24" Full HD PoE Monitor Plus Additional Lan Out
24RPE
