GRI 29B-W 29 Series Surface Mount Magnetic Reed Switch Set, 1' Standard Gap, Open Loop, N/C, B, White
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 1
Key Features
- Reliable, low-maintenance perimeter detection with a hermetically sealed reed sensor and lifetime warranty to reduce downtime and service costs.
- Fast surface-mount installation on steel or non-ferrous frames with a 1-inch standard gap (5/8" on steel) and side screw terminals for easy wiring.
- Open-loop, normally-closed (N/C) contact design ideal for commercial security, access control and monitoring systems.
- Plated contacts resist sticking or freezing and UL/ULC approvals support code-compliant deployments.
- Pre-wired options and customizable lead lengths simplify integration with alarm panels and surveillance networks.
Quick Specifications
- Product Model
- 29B
- Brand Name
- George Risk Industries
- Product Name
- 29B Magnetic Contact
- Product Type
- Magnetic Contact
Frequently Bought Together
GRI 29B-W 29 Series Surface Mount Magnetic Reed Switch Set, 1' Standard Gap, Open Loop, N/C, B, White
$7.03
8 items selected
Total: $48.67
Explore the details
Product information
29B-W
Overview
Designed for dependable perimeter protection, the George Risk Industries 29B series surface-mount magnetic contact delivers reliable door and window monitoring for commercial security systems. The GRI 29B-W magnetic reed switch features an open-loop, normally-closed (N/C) contact and a 1-inch standard gap (5/8-inch on steel), providing consistent detection on steel or non-ferrous installations with minimal gap penalty. Its hermetically sealed reed and plated contacts resist sticking and freezing, lowering false alarms and maintenance overhead for integrators and facility managers.
Installation is straightforward: side-mounted screw terminals and included spacers, covers and screws speed mounting, while pre-wired and PA series cable options let you tailor connections to alarm panels and surveillance controllers. UL/ULC approvals and a lifetime warranty protect your investment and simplify compliance on access control and monitoring projects. Ideal for commercial doors, gates and asset protection, the GRI 29B-W combines durable construction with the flexibility installers need to keep security and surveillance systems reliable. Add the GRI 29B-W to your next access control or perimeter monitoring deployment for a robust, low-maintenance magnetic contact solution.
Features
- Reliable, low-maintenance perimeter detection with a hermetically sealed reed sensor and lifetime warranty to reduce downtime and service costs.
- Fast surface-mount installation on steel or non-ferrous frames with a 1-inch standard gap (5/8" on steel) and side screw terminals for easy wiring.
- Open-loop, normally-closed (N/C) contact design ideal for commercial security, access control and monitoring systems.
- Plated contacts resist sticking or freezing and UL/ULC approvals support code-compliant deployments.
- Pre-wired options and customizable lead lengths simplify integration with alarm panels and surveillance networks.
| General Information | |
|---|---|
| Brand Name | George Risk Industries |
| Manufacturer | George Risk Industries |
| Product Name | 29B Magnetic Contact |
| Product Type | Magnetic Contact |
| Product Model | 29B |
| Product Series | 29 |
| Manufacturer Part Number | 29B-W |
| Technical Information | |
| Material | Steel |
| Standard Gap | 1" |
| Connectivity Technology | Wired |
| Physical Characteristics | |
| Color | White |
| Power Description | |
| Power Source | DC |
| Product Information | |
| Mount Type | Surface Mount |
| Contact Type | N.C. |
| Installation Type | Commercial |
| Warranty | |
| Limited Warranty | Lifetime Warranty |
| Miscellaneous | |
| Features | 24" jacketed cable on PA Series, Concealed terminals on 28 Series, Extra wide gap up to 2", 1" on steel, Hermetically sealed, Lifetime warranty against workmanship, material and factory defects, Longer leads upon request on PA series, Plated contacts resist sticking or freezing, Screw down flanges, Side mounted screw terminals on 29 series, Side screw terminals on 29 series, Spacers, covers and screws Included, Standard gap up to 1", 5/8" on steel, Surface mount open loop magnetic contacts, UL and ULC Approved, Wide gap up to 1 1/2", 3/4" on steel |
| Country of Origin | US |
