DynaLock 3101C 1500 lb Delayed Egress Single Lock, Satin Aluminum with Clear Anodize (Replaces 3101A, 3101B)
Image of 2
Key Features
- Secure, code-compliant delayed egress: prevents unauthorized exits while meeting egress and safety requirements for commercial facilities
- High holding strength: 1500 lb magnetic lock provides robust perimeter security and reliable performance for heavy-use doors
- Flexible timing and override options: field-selectable 15/30 second delay with audible/LED alerts and built-in keyswitch or remote reset for fast control
- Easy integration: auto-sensing 12/24V input and fire-alarm contacts (NO/NC selectable) simplify connection to access control and building monitoring systems
- Durable, low-profile design: satin clear-anodized aluminum finish and surface-mount installation for clean, tamper-resistant aesthetics and long service life
Quick Specifications
- Product Model
- 3101C
- Brand Name
- DynaLock
- Product Name
- 3101C Series Delay Egress System Magnetic Lock
- Product Type
- Magnetic Lock
Explore the details
Product information
3101C-US28
Overview
Protect controlled exits without compromising safety with the DynaLock 3101C delayed egress magnetic lock. Designed for access control and security-conscious facilities, this self-contained magnetic lock secures outswing single or double doors with a 1500 lb holding force while providing a code-compliant delay to manage authorized egress. The 3101C Series integrates updated electronics and DynaLock’s forgiving egress-sensing technology to reduce nuisance activations and handle minor door misalignment.
Installers and security integrators will appreciate the auto-sensing 12/24V input, selectable 15 or 30 second delay with audible and LED alerts, and field-selectable fire-alarm contacts for seamless integration with alarm and building management systems. The satin clear-anodized aluminum housing and surface-mount design deliver durable, professional aesthetics for hospitals, schools, retail, and commercial properties. Backed by a lifetime warranty, the 3101C is optimized for long-term monitoring and surveillance workflows within an access control architecture. Specify the DynaLock 3101C for your next delayed egress or security upgrade—contact us for ordering and integration support.
Features
- Secure, code-compliant delayed egress: prevents unauthorized exits while meeting egress and safety requirements for commercial facilities
- High holding strength: 1500 lb magnetic lock provides robust perimeter security and reliable performance for heavy-use doors
- Flexible timing and override options: field-selectable 15/30 second delay with audible/LED alerts and built-in keyswitch or remote reset for fast control
- Easy integration: auto-sensing 12/24V input and fire-alarm contacts (NO/NC selectable) simplify connection to access control and building monitoring systems
- Durable, low-profile design: satin clear-anodized aluminum finish and surface-mount installation for clean, tamper-resistant aesthetics and long service life
| General Information | |
|---|---|
| Brand Name | DynaLock |
| Manufacturer | DynaLock Corporation |
| Product Name | 3101C Series Delay Egress System Magnetic Lock |
| Product Type | Magnetic Lock |
| Product Model | 3101C |
| Product Series | 3101C |
| Application/Usage | Outswing Door |
| Country of Origin | US |
| Packaged Quantity | 1 |
| Manufacturer Part Number | 3101C-US28 |
| Technical Information | |
| Egress Delay | 30s |
| Door Supported | Hinged |
| Nuisance Delay | 3s |
| Physical Characteristics | |
| Color | Silver |
| Depth | 3.00" |
| Width | 11.00" |
| Material | Aluminum |
| Power Description | |
| Input Voltage | 12V DC, 24V AC |
| Product Information | |
| Finishing | Clear Anodized, Satin |
| Mount Type | Surface Mount |
| Holding Force | 1500.00lb |
| Warranty | |
| Limited Warranty | Lifetime |
| Miscellaneous | |
| Features | Status LED |
| Compatibility | Outswing single or double doors |
