Genesis 32261012 18/3 Stranded Shielded Cable, Plenum, CMP, FT6, 1000' (304.8 m) Reel, Natural
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Image of 3
Key Features
- Minimizes interference for reliable security and surveillance signals with foil shielding and bare copper conductors
- CMP/FT6 plenum rating for safe installation in air-handling spaces and commercial buildings
- 1000' reel reduces splices and labor, ideal for long runs and large projects
- Stranded 18 AWG bare copper provides flexibility for easy routing and dependable conductivity
- Installer-friendly features: rip cord and countdown length markings speed stripping and job tracking
- RoHS/REACH and TAA compliant with a 3-year limited warranty for commercial deployments
Quick Specifications
- Product Model
- 32261012
- Brand Name
- Genesis
- Product Name
- 32261012 Control Cable
- Product Type
- Access & Security Cable
Product Information Tabs
Overview
Deliver clean, interference-free signal runs in plenum spaces with the Genesis 32261012 18/3 Stranded Shielded Plenum Cable. Designed for security, surveillance and monitoring applications, this Genesis plenum shielded cable combines a foil shield and bare copper conductors to minimize EMI and protect sensitive alarm, access control and phone lines. The stranded 18 AWG construction offers flexible routing through conduit and tight pathways, while the CMP/FT6-rated LS-PVC jacket meets strict plenum fire and low-smoke requirements for commercial buildings.
Supplied on a 1000' reel to reduce splices and installation time, the cable also includes a durable rip cord and countdown length markings for faster jacket removal and accurate job tracking. TAA, RoHS/REACH compliant and backed by a 3-year limited warranty, this cable is engineered for dependable long-term performance in monitoring and security systems. Ideal for system integrators, security contractors and facility managers installing cameras, alarms or access control in plenum spaces—order a reel today or contact us for volume pricing.
Features
- Minimizes interference for reliable security and surveillance signals with foil shielding and bare copper conductors
- CMP/FT6 plenum rating for safe installation in air-handling spaces and commercial buildings
- 1000' reel reduces splices and labor, ideal for long runs and large projects
- Stranded 18 AWG bare copper provides flexibility for easy routing and dependable conductivity
- Installer-friendly features: rip cord and countdown length markings speed stripping and job tracking
- RoHS/REACH and TAA compliant with a 3-year limited warranty for commercial deployments
| General Information | |
|---|---|
| Brand Name | Genesis |
| Manufacturer | Genesis Cable |
| Product Name | 32261012 Control Cable |
| Product Type | Access & Security Cable |
| Product Model | 32261012 |
| Packaged Quantity | 1 |
| Manufacturer Part Number | 32261012 |
| Technical Information | |
| Material | Bare Copper |
| Shielding | Yes |
| Cable Type | Multi-conductor, Multi-pair |
| Jacket Type | FT6, Plenum |
| Cable Rating | Plenum |
| Conductor Count | 1 |
| Jacket Material | LS PVC |
| Number of Pairs | 1 |
| Device Supported | Alarm, Phone |
| Solid or Stranded | Stranded |
| Conductor Material | Bare Copper |
| American Wire Gauge | 18AWG |
| Number of Conductors | 3 |
| Core/Cladding Diameter | 18/3 |
| Certifications | |
| TAA Compliant | Yes |
| Physical Characteristics | |
| Color | Natural |
| Cable Length | 1000' |
| Package Type | Reel |
| Insulation Material | LS-PVC |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Stranded |
| Indoor/Outdoor | Indoor |
| Country of Origin | US |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
