Honeywell Home 4208U V-Plex Universal 8-Zone Remote Point Module
Key Features
- Expands a security system by eight supervised zones to support larger commercial or multi-site installations
- Optional external DC power reduces loop current draw for more reliable polling and longer device life
- Flexible zone mapping with DIP switches or serial-number mode simplifies installation and inventory management
- Fast 10 ms loop response option for critical monitoring and rapid alarm reporting in access control or fire applications
- Built-in cover tamper (enable/disable) protects equipment integrity and reduces false alarms for continuous surveillance
Quick Specifications
- Product Model
- 4208U
- Brand Name
- Honeywell Home
- Product Line
- V-Plex
- Product Name
- Universal Eight Zone Remote Point Module
Product Information Tabs
Overview
Improve system capacity and reliability with the Honeywell Home 4208U V-Plex Universal 8-Zone Remote Point Module. This zone expander module provides a simple way to add eight supervised zones to V-Plex-compatible control panels, making it ideal for commercial access control, fire alarm, and security monitoring projects. Installers benefit from flexible configuration — set zones directly with DIP switches or use serial-number mode to map devices to any zone — and optional external DC power reduces current draw on the polling loop for longer, more stable operation. Loops A & B support a fast 10 ms response for time-sensitive surveillance and alarm reporting, while the on-board cover tamper adds a layer of physical protection. Packaged in a compact, tamper-proof housing, the 4208U integrates seamlessly into Honeywell V-Plex systems to expand monitored points without complex rewiring. For scalable, professional-grade security and monitoring, choose the Honeywell Home 4208U — contact sales or add to your project spec to deploy reliable zone expansion today.
Features
- Expands a security system by eight supervised zones to support larger commercial or multi-site installations
- Optional external DC power reduces loop current draw for more reliable polling and longer device life
- Flexible zone mapping with DIP switches or serial-number mode simplifies installation and inventory management
- Fast 10 ms loop response option for critical monitoring and rapid alarm reporting in access control or fire applications
- Built-in cover tamper (enable/disable) protects equipment integrity and reduces false alarms for continuous surveillance
| General Information | |
|---|---|
| Brand Name | Honeywell Home |
| Manufacturer | Resideo |
| Product Line | V-Plex |
| Product Name | Universal Eight Zone Remote Point Module |
| Product Type | Zone Expander Module |
| Product Model | 4208U |
| Product Series | V-Plex |
| Manufacturer Part Number | 4208U |
| Technical Information | |
| Application/Usage | Access Control, Fire Alarm |
| Physical Characteristics | |
| Color | White |
| Depth | 1.3" |
| Width | 6.4" |
| Height | 4.3" |
| Power Description | |
| Power Source | Battery |
| Miscellaneous | |
| Features | Tamper Proof |
| Compatibility | Honeywell V-Plex Devices |
| Country of Origin | MX |
