AJAX 42837.19.NC3 Remote Control Low Current Relay with Dry Contacts

For secure, flexible equipment control in security and monitoring applications, the AJAX Remote Control Low Current Relay with Dry Contacts delivers reliable switching without compromising system integrity. The AJAX relay’s SPDT dry contact isolates loads from the device’s power, enabling safe control of both low-voltage and household circuits — ideal for intrusion panels, access control gates, CCTV switchovers and industrial automation. Operating on 7–24 V and offering configurable pulse durations from 1 to 255 seconds, it supports timed operations and bistable control to match diverse installation needs. Two-way radio communication up to 1000 meters (with support for five signal range extenders) and a compact 39×33×18 mm form factor let you deploy the relay in junction boxes, electrical panels or DIN-mounted enclosures while maintaining robust connectivity. Low power consumption, fast command delivery (~0.15 s) and simple QR-code pairing via the Ajax app reduce installation time and total cost of ownership. Add this AJAX relay to your security, surveillance, or monitoring projects for dependable remote switching — contact sales or add to cart to begin integration.

• Reliable low-power control: operates on 7–24 V for seamless integration with power supplies and battery backups
• Universal dry-contact output (SPDT): safely switches both low-voltage and household circuits without galvanic connection to device power
• Fast system integration: pair with an Ajax hub in under a minute by scanning a QR code for rapid commissioning
• Long-range, resilient connectivity: two-way radio up to 1000 m and support for up to 5 range extenders ensures stable links across large sites
• Compact, install-friendly design: miniature 39×33×18 mm housing fits junction boxes, electrical panels or DIN-mounted enclosures
