Genesis 43015501 22/4 Solid Unshielded Fire Alarm Cable, Riser, FPLR, 500' (152.4 m) Pull Box, White
Image of 4
Key Features
- Delivers reliable alarm and monitoring signals for security systems with solid 22 AWG conductors to reduce voltage drop and false alarms
- UL-listed FPLR riser rating and TAA compliance for code‑approved vertical runs in commercial buildings
- 500' pull box and countdown length markings speed installation and reduce waste on large projects
- Durable PVC jacket, UV resistance and Made in the USA construction for long-term performance and regulatory confidence
- Built-in rip cord and solid conductor design simplify termination and save technician time during deployment
Quick Specifications
- Product Model
- 43015501
- Brand Name
- Genesis
- Product Name
- 22 AWG 4 Solid Conductors, Riser FPLR
- Product Type
- Fire Alarm Cable
Explore the details
Product information
43015501
Overview
Keep life-safety systems dependable and code-compliant with the Genesis 22/4 Solid Unshielded Fire Alarm Cable. This Genesis fire alarm cable is built for security and monitoring applications where uninterrupted signal integrity matters — it uses four solid 22 AWG bare copper conductors and a UL-listed FPLR riser rating for safe vertical runs. Supplied in a 500' pull box with countdown length markings, the cable reduces installation time and material waste on large projects. The PVC jacket and sunlight-resistant construction provide durable protection for indoor installations near light sources, while the rip cord enables fast jacket removal for cleaner terminations. Ideal for fire alarm, monitoring and integrated security systems, this cable supports reliable connectivity between devices, panels and annunciators. TAA compliant and backed by Genesis quality, the 43015501 model balances performance and code compliance for contractors, integrators and facility managers. Specify Genesis 22/4 FPLR for your next riser application — order the 500' pull box to streamline installation on commercial or institutional projects.
Features
- Delivers reliable alarm and monitoring signals for security systems with solid 22 AWG conductors to reduce voltage drop and false alarms
- UL-listed FPLR riser rating and TAA compliance for code‑approved vertical runs in commercial buildings
- 500' pull box and countdown length markings speed installation and reduce waste on large projects
- Durable PVC jacket, UV resistance and Made in the USA construction for long-term performance and regulatory confidence
- Built-in rip cord and solid conductor design simplify termination and save technician time during deployment
| General Information | |
|---|---|
| Brand Name | Genesis |
| Manufacturer | Genesis Cable |
| Product Name | 22 AWG 4 Solid Conductors, Riser FPLR |
| Product Type | Fire Alarm Cable |
| Product Model | 43015501 |
| Packaged Quantity | 1 |
| Manufacturer Part Number | 43015501 |
| Technical Information | |
| Material | Bare Copper |
| Shielding | No |
| Jacket Type | Plenum |
| Cable Rating | Riser |
| Conductor Count | 4 |
| Jacket Material | PVC |
| Number of Pairs | 1 |
| Device Supported | Fire Alarm |
| Solid or Stranded | Solid |
| Conductor Material | Bare Copper |
| American Wire Gauge | 22AWG |
| Number of Conductors | 4 |
| Connector on First End | Bare Wire |
| Core/Cladding Diameter | 22/4 |
| Connector on Second End | Bare Wire |
| Certifications | |
| TAA Compliant | Yes |
| Physical Characteristics | |
| Color | White |
| Cable Length | 500' |
| Package Type | Pull Box |
| Insulation Material | PP |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Stranded |
| Indoor/Outdoor | Indoor |
| Country of Origin | US |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
