Genesis 45131001 14/2 Solid Unshielded Fire Alarm Cable, Plenum, FPLP, 1000' (304.8 m) Reel, White
Image of 3
Key Features
- Provides dependable alarm and monitoring signals with solid 14 AWG bare copper conductors for low voltage drop and consistent performance
- Plenum-rated LS-PVC jacket and low-smoke insulation reduce toxic fumes and meet HVAC space requirements for commercial installations
- 1000' reel minimizes splices and labor on large security, fire and surveillance projects, speeding deployment and reducing failure points
- Built-in rip cord and countdown length markings streamline installation and inventory tracking for faster, cleaner terminations
- TAA compliant, RoHS certified and Made in the USA for procurement confidence and regulatory compliance
- 3-year limited warranty gives long-term peace of mind for mission-critical life-safety systems
Quick Specifications
- Product Model
- 45131001
- Brand Name
- Genesis
- Package Type
- Reel/Spool
- Product Name
- 45131001 - 14 AWG 2C Sol Plenum, White, 1000 ft. Reel
Explore the details
Product information
45131001
Overview
Ideal for commercial fire alarm, security and life-safety installations, the Genesis 45131001 14/2 Solid Unshielded Fire Alarm Cable delivers reliable, low-smoke signal transmission where safety and code compliance matter most. This plenum-rated (FPLP) fire alarm cable features solid 14 AWG bare copper conductors in a 2-conductor configuration, providing consistent conductivity and reduced voltage drop for long runs. The LS-PVC low-smoke insulation and plenum PVC jacket protect building occupants and HVAC spaces by limiting toxic fumes and supporting plenum space requirements.
Supplied on a 1000' reel, the cable reduces joints and labor on larger projects, while the durable rip cord and countdown length markings make jacket removal and inventory management faster and more accurate. Rated for 300V and a wide operating temperature range (-20 °C to 75 °C), this RoHS-compliant, TAA-friendly cable is well suited for fire alarm, monitoring, security and surveillance systems in schools, hospitals, data centers and office buildings. Backed by Genesis quality and a 3-year limited warranty, it’s an efficient choice for installers and specifiers. Order now to streamline installation and ensure reliable protection for your next life-safety or security project.
Features
- Provides dependable alarm and monitoring signals with solid 14 AWG bare copper conductors for low voltage drop and consistent performance
- Plenum-rated LS-PVC jacket and low-smoke insulation reduce toxic fumes and meet HVAC space requirements for commercial installations
- 1000' reel minimizes splices and labor on large security, fire and surveillance projects, speeding deployment and reducing failure points
- Built-in rip cord and countdown length markings streamline installation and inventory tracking for faster, cleaner terminations
- TAA compliant, RoHS certified and Made in the USA for procurement confidence and regulatory compliance
- 3-year limited warranty gives long-term peace of mind for mission-critical life-safety systems
| General Information | |
|---|---|
| Brand Name | Genesis |
| Manufacturer | Genesis Cable |
| Package Type | Reel/Spool |
| Product Name | 45131001 - 14 AWG 2C Sol Plenum, White, 1000 ft. Reel |
| Product Type | Fire Alarm Cables |
| Product Model | 45131001 |
| Country of Origin | US |
| Packaged Quantity | 1 |
| Manufacturer Part Number | 45131001 |
| Technical Information | |
| Armored | No |
| Shielding | No |
| Jacket Type | Plenum Duplex Zip |
| Cable Rating | Plenum |
| Conductor Count | 2 |
| Number of Pairs | 1 |
| Solid or Stranded | Solid |
| Conductor Material | Bare Copper |
| American Wire Gauge | 14AWG |
| Number of Conductors | 2 |
| Core/Cladding Diameter | 14/2 |
| Certifications | |
| TAA Compliant | Yes |
| Physical Characteristics | |
| Color | White |
| Weight | 32.60lb |
| Cable Length | 1000.00' |
| Jacket Material | LS-PVC |
| Insulation Material | LS-PVC |
| Warranty | |
| Limited Warranty | 1-Year |
| Miscellaneous | |
| Indoor/Outdoor | Indoor |
| Environmental Certification | RoHS |
