Genesis 45131002 14/2 Solid Unshielded Fire Alarm Cable, Plenum, FPLP, 1000' (304.8 m) Reel, Yellow
Image of 3
Key Features
- Ensures dependable fire alarm signaling across plenum spaces for uninterrupted life-safety monitoring
- Plenum-rated LS-PVC jacket and low-smoke insulation reduce toxic fumes and meet air-handling space requirements
- Solid 14 AWG bare copper conductors deliver consistent conductivity and low voltage drop for reliable system performance
- 1000' reel with countdown markings and rip cord speeds installation and minimizes downtime on large projects
- TAA compliant and Made in the USA for procurement confidence on commercial, government, and security installations
Quick Specifications
- Product Model
- 45131002
- Brand Name
- Genesis
- Product Name
- 45131002 - 14 AWG 2C Sol Plenum, Yellow, 1000 ft. Reel
- Product Type
- Fire Alarm Cable
Explore the details
Product information
45131002
Overview
Built for reliable life-safety performance, the Genesis 45131002 14/2 Solid Unshielded Fire Alarm Cable is a professional-grade solution for fire alarm, security, and monitoring systems. This plenum-rated fire alarm cable combines solid 14 AWG bare copper conductors with low-smoke PVC insulation and a plenum LS-PVC jacket to maintain signal integrity while minimizing toxic fumes in air-handling spaces. Supplied on a 1000' reel with countdown length markings and a durable rip cord, this cable reduces install time and waste on long runs and multi-floor deployments.
Ideal for commercial buildings, schools, hospitals and data center environments, the Genesis fire alarm cable is UL-listed and TAA compliant, giving contractors and integrators the code-compliant performance they require. The 2-conductor design supports dependable alarm and supervisory circuits for monitoring and security systems, while the 3-year limited warranty provides added peace of mind. Choose Genesis for a plenum unshielded cable that balances safety, ease of install, and long-term reliability. Order now to outfit your next fire alarm or security monitoring project with code-approved, plenum-rated wiring.
Features
- Ensures dependable fire alarm signaling across plenum spaces for uninterrupted life-safety monitoring
- Plenum-rated LS-PVC jacket and low-smoke insulation reduce toxic fumes and meet air-handling space requirements
- Solid 14 AWG bare copper conductors deliver consistent conductivity and low voltage drop for reliable system performance
- 1000' reel with countdown markings and rip cord speeds installation and minimizes downtime on large projects
- TAA compliant and Made in the USA for procurement confidence on commercial, government, and security installations
| General Information | |
|---|---|
| Brand Name | Genesis |
| Manufacturer | Genesis Cable |
| Product Name | 45131002 - 14 AWG 2C Sol Plenum, Yellow, 1000 ft. Reel |
| Product Type | Fire Alarm Cable |
| Product Model | 45131002 |
| Packaged Quantity | 1 |
| Manufacturer Part Number | 45131002 |
| Technical Information | |
| Material | Bare Copper |
| Impedance | 63 ohms |
| Shielding | No |
| Jacket Type | Plenum |
| Cable Rating | Plenum |
| Conductor Count | 2 |
| Jacket Material | LS PVC |
| Number of Pairs | 1 |
| Device Supported | Fire Alarm |
| Solid or Stranded | Solid |
| Conductor Material | Bare Copper |
| American Wire Gauge | 14AWG |
| Number of Conductors | 2 |
| Connector on First End | Bare Wire |
| Core/Cladding Diameter | 14/2 |
| Connector on Second End | Bare Wire |
| Certifications | |
| TAA Compliant | Yes |
| Physical Characteristics | |
| Color | Yellow |
| Weight | 32.70 lb |
| Cable Length | 1000' |
| Package Type | Reel |
| Insulation Material | LS-PVC |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Indoor/Outdoor | Indoor |
| Country of Origin | US |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
