Kramer 50-80021190 TP-580Txr 4K60 4:2:0 HDMI HDCP 2.2 Transmitter with RS–232 and IR over Extended–Reach HDBaseT
Image of 4
Key Features
- Extend 4K video, audio and control up to 100m (330ft) over a single CAT cable, reducing cabling complexity and installation cost.
- Future-ready HDMI 2.0 / HDCP 2.2 support for 4K@60Hz (4:2:0) content and up to 32 channels of uncompressed audio—ideal for immersive AV and surveillance feeds.
- Bidirectional RS-232 and IR passthrough enables centralized control of displays, PTZ cameras and matrix switchers in monitoring and control-room environments.
- I-EDIDPro intelligent EDID management ensures reliable plug-and-play interoperability across diverse sources and displays, cutting commissioning time.
- Compact, fan-less DigiTOOLS rack-mount design with status LEDs and local firmware upgrade capability for low-maintenance, long-term deployments.
- HDBaseT interoperability with existing twisted-pair infrastructures makes it well suited for conference rooms, auditoriums, hotels, and security/surveillance installations.
Quick Specifications
- Product Model
- TP-580Txr
- Brand Name
- Kramer Electronics
- Product Line
- DigiTOOLS
- Product Name
- DigiTOOLS TP-580Txr Video Extender Transmitter
Frequently Bought Together
Kramer 50-80021190 TP-580Txr 4K60 4:2:0 HDMI HDCP 2.2 Transmitter with RS–232 and IR over Extended–Reach HDBaseT
$278.83
2 items selected
Total: $303.78
Product Information Tabs
Overview
Deliver long-distance, reliable 4K HDMI video and centralized device control for professional AV and security projects. The Kramer Electronics TP-580Txr Pro HDMI Extender converts HDMI, RS‑232 and IR into a single HDBaseT stream to extend signals up to 100m (330ft) over CAT copper—simplifying cabling and consolidating infrastructure for large venues. It supports HDMI 2.0 and HDCP 2.2 for 4K@60Hz (4:2:0) sources, deep color, and up to 32 channels of uncompressed audio, ensuring high-quality playback for digital signage, surveillance monitoring and control rooms.
Bidirectional RS‑232 and IR enable remote control of displays and cameras, while I‑EDIDPro intelligent EDID processing minimizes compatibility issues during installation. The fanless DigiTOOLS enclosure is rack-mountable and includes status LEDs and local firmware upgrade options for straightforward maintenance. Designed for interoperability with HDBaseT-compliant devices, the TP-580Txr is a cost-effective solution for conference centers, lecture halls, hotels and security/surveillance systems. Specify the TP-580Txr for your next pro AV or monitoring deployment—contact us to order or integrate it into your system design.
Features
- Extend 4K video, audio and control up to 100m (330ft) over a single CAT cable, reducing cabling complexity and installation cost.
- Future-ready HDMI 2.0 / HDCP 2.2 support for 4K@60Hz (4:2:0) content and up to 32 channels of uncompressed audio—ideal for immersive AV and surveillance feeds.
- Bidirectional RS-232 and IR passthrough enables centralized control of displays, PTZ cameras and matrix switchers in monitoring and control-room environments.
- I-EDIDPro intelligent EDID management ensures reliable plug-and-play interoperability across diverse sources and displays, cutting commissioning time.
- Compact, fan-less DigiTOOLS rack-mount design with status LEDs and local firmware upgrade capability for low-maintenance, long-term deployments.
- HDBaseT interoperability with existing twisted-pair infrastructures makes it well suited for conference rooms, auditoriums, hotels, and security/surveillance installations.
| General Information | |
|---|---|
| Brand Name | Kramer Electronics |
| Manufacturer | Kramer Electronics LTD |
| Product Line | DigiTOOLS |
| Product Name | DigiTOOLS TP-580Txr Video Extender Transmitter |
| Product Type | Video Extender Transmitter |
| Product Model | TP-580Txr |
| Manufacturer Part Number | 50-80021190 |
| Technical Information | |
| Media Type Supported | Twisted Pair |
| Connectivity Technology | Wired |
| Maximum Operating Distance | 590.55' |
| Number of Input Devices Supported | 1 |
| Display & Graphics | |
| Maximum Video Resolution | 4096 x 2160 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Number of HDMI Inputs | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Physical Characteristics | |
| Depth | 2.81" |
| Width | 4.72" |
| Height | 0.96" |
| Form Factor | Rack Mount |
| Product Information | |
| Mount Type | Rack Mount |
| Video | |
| Graphics Modes | 4K |
