Kramer 50-80319190 TP-590Rxr 4K60 4:2:0 HDMI PoE Receiver with USB, Ethernet, RS-232, IR and Stereo Audio De-embedding over Extended-Reach HDBaseT 2.0
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 3
Key Features
- Extend 4K60 video and control up to 100m (330ft) and 1080p up to 180m, reducing cabling and avoiding repeaters
- Single‑cable HDBaseT with PoE simplifies installation and powers the receiver for clean, professional deployments
- Stereo audio de‑embedding delivers local balanced analog output while continuing HDMI audio to displays
- USB 2.0, Ethernet (100Mbps), RS‑232 and bidirectional IR extension for KVM, device control and networked peripherals
- Compact MegaTOOLS form factor with rack mounting and remote management via web UI, Kramer Network and firmware upgrades
- HDMI 2.0 / HDCP 1.4 compatibility for reliable AV, security and surveillance monitoring systems
Quick Specifications
- Product Model
- TP-590RXR
- Brand Name
- Kramer Electronics
- Product Line
- MegaTOOLS
- Product Name
- MegaTOOLS TP-590RXR Video Extender Receiver
Explore the details
Product information
50-80319190
Overview
Deliver long‑reach 4K video, control and audio over a single cable for mission‑critical AV and security installations. The Kramer Electronics TP-590RXR Pro Receiver is a high-performance HDBaseT 2.0 receiver that extends HDMI 4K@60Hz (4:2:0) up to 100m (330ft) and Full HD up to 180m (590ft) over standard CAT copper cabling. It carries HDMI, USB 2.0, Ethernet, RS-232 and bidirectional IR while providing PoE power and stereo analog audio de‑embedding for local sound systems.
Designed for integration into conferencing, control room, surveillance and monitoring environments, the TP-590RXR supports HDMI 2.0/HDCP 1.4, multi-channel audio and Kramer’s I-EDIDPro for plug-and-play interoperability. Status LEDs, web-based management and Kramer Network support make large deployments easier to maintain, and compact MegaTOOLS rack-mountability saves space in equipment racks. Whether you’re extending video for security cameras, delivering AV to remote displays, or enabling remote KVM and device control, the TP-590RXR streamlines installation and improves system reliability. Ideal for security and surveillance monitoring, corporate AV and digital signage — order the TP-590RXR today to extend your AV network with confidence.
Features
- Extend 4K60 video and control up to 100m (330ft) and 1080p up to 180m, reducing cabling and avoiding repeaters
- Single‑cable HDBaseT with PoE simplifies installation and powers the receiver for clean, professional deployments
- Stereo audio de‑embedding delivers local balanced analog output while continuing HDMI audio to displays
- USB 2.0, Ethernet (100Mbps), RS‑232 and bidirectional IR extension for KVM, device control and networked peripherals
- Compact MegaTOOLS form factor with rack mounting and remote management via web UI, Kramer Network and firmware upgrades
- HDMI 2.0 / HDCP 1.4 compatibility for reliable AV, security and surveillance monitoring systems
| General Information | |
|---|---|
| Brand Name | Kramer Electronics |
| Manufacturer | Kramer Electronics LTD |
| Product Line | MegaTOOLS |
| Product Name | MegaTOOLS TP-590RXR Video Extender Receiver |
| Product Type | IR Receiver |
| Product Model | TP-590RXR |
| Manufacturer Part Number | 50-80319190 |
| Technical Information | |
| Media Type Supported | Twisted Pair |
| Connectivity Technology | Wired |
| Maximum Operating Distance | 330.00' |
| Number of Output Devices Supported | 1 |
| Display & Graphics | |
| Maximum Video Resolution | 4096 x 2160 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Number of USB Ports | 5 |
| Number of HDMI Outputs | 1 |
| Number of Network (RJ-45) Ports | 2 |
| Physical Characteristics | |
| Depth | 4.53" |
| Height | 1.00" |
| Product Information | |
| Mount Type | Rack Mount |
| Video | |
| Graphics Mode | 4K UHD |
