Genesis 50031001 RG6 CCS 75 Ohm Coaxial with Dual-Shield Cable, General Purpose, CATV, 1000' (304.8 m) Reel, White
Image of 1
Key Features
- Consistent, low-loss signal for CATV, satellite and security systems—keeps video and data clear for monitoring and surveillance
- Dual-shield (foil + braid) construction minimizes EMI/RFI for reliable performance in crowded RF environments
- Solid CCS RG‑6 conductor balances strength and cost while supporting transmissions up to 3 GHz and 75 ohm impedance
- 1,000' reel with countdown length markings speeds installs and reduces waste on large runs
- Durable sunlight-resistant PVC jacket and PE insulation increase longevity for indoor installations; backed by a 3-year limited warranty
Quick Specifications
- Product Model
- 50031001
- Brand Name
- Genesis
- Product Name
- 50031001 Coaxial Antenna Cable
- Product Type
- Coaxial Cable
Product Information Tabs
Overview
Get dependable signal performance for CATV, CCTV, security and monitoring applications with the Genesis RG‑6 coaxial cable. This Genesis 50031001 coaxial cable is built for professional installs—featuring a solid Copper Clad Steel (CCS) conductor and 75 ohm impedance to support video and data transmissions up to 3 GHz. Dual shielding (aluminum foil + aluminum braid) reduces electromagnetic and radio-frequency interference so surveillance feeds, broadcast signals and two-way communication remain clean and stable.
Packaged on a 1,000' reel, the cable includes countdown length markings for accurate measurement and faster deployments across long runs. The PE insulation and sunlight-resistant PVC jacket provide durable protection during indoor installations while maintaining flexibility for routing in racks, walls and conduits. Rated for general-purpose use and RoHS compliant, this RG‑6 coaxial cable is an economical choice for integrators and network technicians who need consistent performance.
Choose Genesis RG‑6 for reliable CATV, satellite, security camera and monitoring links—ideal for professional surveillance and broadcast projects. Add to your installation kit or order now for your next deployment.
Features
- Consistent, low-loss signal for CATV, satellite and security systems—keeps video and data clear for monitoring and surveillance
- Dual-shield (foil + braid) construction minimizes EMI/RFI for reliable performance in crowded RF environments
- Solid CCS RG‑6 conductor balances strength and cost while supporting transmissions up to 3 GHz and 75 ohm impedance
- 1,000' reel with countdown length markings speeds installs and reduces waste on large runs
- Durable sunlight-resistant PVC jacket and PE insulation increase longevity for indoor installations; backed by a 3-year limited warranty
| General Information | |
|---|---|
| Brand Name | Genesis |
| Manufacturer | Genesis Cable |
| Product Name | 50031001 Coaxial Antenna Cable |
| Product Type | Coaxial Cable |
| Product Model | 50031001 |
| Packaged Quantity | 1 |
| Manufacturer Part Number | 50031001 |
| Technical Information | |
| Material | Copper Clad Steel |
| Impedance | 75 ohms |
| Shielding | Yes |
| Cable Type | RG-6 |
| Jacket Type | General Purpose |
| Cable Rating | General Purpose |
| Conductor Count | 1 |
| Jacket Material | PVC |
| Solid or Stranded | Solid |
| Conductor Material | CCS |
| American Wire Gauge | 18AWG |
| Number of Conductors | 1 |
| Certifications | |
| TAA Compliant | No |
| Physical Characteristics | |
| Color | White |
| Cable Length | 1000' |
| Package Type | Reel |
| Insulation Material | PE |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Indoor/Outdoor | Indoor |
| Country of Origin | CN |
| Environmental Certification | RoHS |
