Genesis 53071101 RG6 CCS 75 Ohm Coaxial with Quad-Shield Cable, Riser, CATVR, FT4, 1000' (304.8 m) Pull Box, White

SKU: 53071101 Genesis
Image of WG-53071101
Product images for Genesis 53071101 RG6 CCS 75 Ohm Coaxial with Quad-Shield Cable, Riser, CATVR, FT4, 1000' (304.8 m) Pull Box, White. 1 image(s) available. Click on image to view full size.

Key Features

  • Consistent, interference-resistant signal for CATV, CCTV and surveillance—quad-shield construction minimizes ingress for clearer video and monitoring
  • Ready for professional installs with 1000' pull-box and countdown length markings to speed deployment and reduce waste
  • Riser-rated (FT4) white jacket and UV-resistant PVC for reliable indoor runs in riser shafts and commercial spaces
  • 75 Ω RG6 performance with 18 AWG copper-clad steel conductor delivers long-distance transmission up to 3 GHz for broadband and satellite
  • Built for compliance and peace of mind: RoHS/REACH compliant and backed by a 3-year limited warranty

Quick Specifications

Product Model
53071101
Brand Name
Genesis
Product Name
18 AWG Copper-Clad Steel RG6, Quad-Shield, Riser CATVR/FT4
Product Type
Coaxial Cables
View Full Technical Specifications

Product Information Tabs

Overview

Deliver consistent, interference-resistant video and data for commercial CATV, security and surveillance projects with the Genesis 53071101 coaxial cable. This RG6, quad-shield coaxial cable combines a solid 18 AWG copper-clad steel (CCS) conductor and four layers of shielding to protect signals from EMI/RFI—critical for clear CCTV, monitoring and broadcast applications. Supplied in a 1000' (304.8 m) pull box with countdown length markings, the cable speeds installation and reduces downtime on long runs. The riser-rated FT4 PVC jacket and sunlight-resistant construction support indoor riser shafts and building backbone routes while maintaining a clean white appearance for visible runs. Rated at 75 ohms and capable of transmission up to 3 GHz, it’s ideal for broadband, satellite, security camera systems and professional monitoring installations. RoHS/REACH compliant and covered by a 3-year limited warranty, the Genesis RG6 cable balances performance, safety and value. Order the 53071101 quad-shield coaxial cable for reliable signal integrity on your next security or networking deployment.

Features

  • Consistent, interference-resistant signal for CATV, CCTV and surveillance—quad-shield construction minimizes ingress for clearer video and monitoring
  • Ready for professional installs with 1000' pull-box and countdown length markings to speed deployment and reduce waste
  • Riser-rated (FT4) white jacket and UV-resistant PVC for reliable indoor runs in riser shafts and commercial spaces
  • 75 Ω RG6 performance with 18 AWG copper-clad steel conductor delivers long-distance transmission up to 3 GHz for broadband and satellite
  • Built for compliance and peace of mind: RoHS/REACH compliant and backed by a 3-year limited warranty
General Information
Brand Name Genesis
Manufacturer Genesis Cable
Product Name 18 AWG Copper-Clad Steel RG6, Quad-Shield, Riser CATVR/FT4
Product Type Coaxial Cables
Product Model 53071101
Packaged Quantity 1
Manufacturer Part Number 53071101
Technical Information
Armored No
Impedance 75 ohms
Shielding Yes
Jacket Type FT4, Riser
Cable Rating Riser
Conductor Count 1
Jacket Material PVC
Solid or Stranded Solid
Conductor Material Copper Clad Steel
American Wire Gauge 18AWG
Number of Conductors 1
Certifications
TAA Compliant No
Physical Characteristics
Color White
Cable Length 1000'
Package Type Pull Box
Insulation Material PE
Warranty
Limited Warranty 1-Year
Miscellaneous
Indoor/Outdoor Indoor
Country of Origin CN
Environmental Certification RoHS
