Genesis 54745510 16/4 (65-Strand Oxygen-Free Copper) Audacious Unshielded Speaker Cable, Riser, CMR, FT4, 500' (152.4 m) Pull Box, Purple
Key Features
- Consistent, low-distortion audio over long runs—65-strand oxygen-free copper reduces signal loss for clearer speaker and PA performance
- Simplifies installations with a 500' pull box and countdown length markings, saving time on large commercial or security projects
- Riser-rated CMR/FT4 jacket for safe in-wall vertical runs in buildings and reliable compliance for surveillance and monitoring systems
- Durable PVC insulation and rip cord make stripping fast and damage-free, reducing labor and rework during installs
- UV- and RoHS-compliant construction with a 3-year limited warranty provides confidence in long-term deployments
Quick Specifications
- Product Model
- 54745510
- Brand Name
- Genesis
- Product Line
- Audacious Sound Cable
- Product Name
- 16 AWG 4C STR Audacious Riser, Purple, 500 ft. Pull Box
Product Information Tabs
Overview
Deliver reliable, low‑distortion audio where it matters most — from conference rooms and public-address systems to security and surveillance speaker networks. The Genesis Audacious 16/4 riser audio cable pairs a high 65‑strand oxygen‑free copper conductor with 16 AWG performance to minimize voltage drop and preserve audio fidelity across long runs. Packaged in a 500' pull box with countdown markings, this Genesis riser cable speeds installations and helps crews manage inventory on-site.
Built for commercial environments, the CMR/FT4 riser jacket and PVC insulation meet vertical in-wall routing requirements, while the durable rip cord enables fast, clean jacket removal. The cable is sunlight resistant and RoHS-compliant, making it suitable for a variety of indoor security, surveillance, and PA system applications that demand dependable audio and easy maintenance. Rated for 300V and a broad temperature range, it supports consistent performance in demanding installations. Backed by a 3-year limited warranty, the Audacious line gives integrators the reliability they need.
Choose Genesis Audacious 16/4 riser speaker cable for cleaner sound, faster installs, and confidence in your security and monitoring audio deployments. Order a pull box for your next project.
Features
- Consistent, low-distortion audio over long runs—65-strand oxygen-free copper reduces signal loss for clearer speaker and PA performance
- Simplifies installations with a 500' pull box and countdown length markings, saving time on large commercial or security projects
- Riser-rated CMR/FT4 jacket for safe in-wall vertical runs in buildings and reliable compliance for surveillance and monitoring systems
- Durable PVC insulation and rip cord make stripping fast and damage-free, reducing labor and rework during installs
- UV- and RoHS-compliant construction with a 3-year limited warranty provides confidence in long-term deployments
| General Information | |
|---|---|
| Brand Name | Genesis |
| Manufacturer | Genesis Cable |
| Product Line | Audacious Sound Cable |
| Product Name | 16 AWG 4C STR Audacious Riser, Purple, 500 ft. Pull Box |
| Product Type | Audio Cable |
| Product Model | 54745510 |
| Packaged Quantity | 1 |
| Manufacturer Part Number | 54745510 |
| Technical Information | |
| Material | Oxygen-free Bare Copper |
| Shielding | No |
| Cable Type | Multi-conductor, Multi-pair |
| Jacket Type | FT4, Riser |
| Cable Rating | Riser |
| Conductor Count | 1 |
| Jacket Material | PVC |
| Number of Pairs | 1 |
| Device Supported | Audio Device, Speaker |
| Solid or Stranded | Stranded |
| Conductor Material | OFC |
| American Wire Gauge | 16AWG |
| Number of Conductors | 4 |
| Certifications | |
| TAA Compliant | Yes |
| Physical Characteristics | |
| Color | Purple |
| Weight | 24.40 lb |
| Cable Length | 500' |
| Package Type | Pull Box |
| Insulation Material | PVC |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Stranded |
| Indoor/Outdoor | Indoor |
| Country of Origin | US |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
