Intellinet 561341 16-Port Gigabit Ethernet PoE+ Web-Managed Switch with SFP Ports,IEEE 802.3at/af PoE+ / PoE Compliant, 220W, Self-Healing Network, Endspan, 19" Rackmount
Image of 4
Key Features
- Deliver data and up to 220W total PoE power to 16 devices, eliminating separate power runs and reducing installation cost for IP cameras, access points and VoIP phones
- Web-managed PoE+ controls and PDM self-healing restart unresponsive devices to maximize uptime for security and monitoring systems
- Two SFP fiber slots extend network reach and isolate traffic for remote surveillance sites or backbone connectivity
- Layer 2+ management (VLAN, QoS, RSTP, ACLs) secures and prioritizes video, voice and critical monitoring traffic
- Rackmount metal chassis with 16 Gigabit ports provides reliable, high-throughput connectivity for medium enterprise networks
Quick Specifications
- Product Model
- 561341
- Brand Name
- Intellinet
- Product Name
- 16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
- Product Type
- Ethernet Switch
Explore the details
Product information
561341
Overview
Streamline deployments for security, surveillance and enterprise Wi‑Fi with the Intellinet 16-Port Gigabit Ethernet PoE+ Web-Managed Switch (561341). This Intellinet network switch delivers both network data and power over Cat5e/Cat6 cabling to IP cameras, wireless access points and VoIP phones, cutting installation time and eliminating extra power supplies. With sixteen auto-sensing Gigabit RJ45 ports and a 220W PoE budget (IEEE 802.3at/af), you can power multiple PoE+ devices while reserving bandwidth for video and monitoring traffic. Two SFP slots enable fiber uplinks for long-distance camera runs or secure backbone connections. Admins benefit from web-managed PoE controls, per-port power limits, PoE priority and a Powered Device Monitor (PDM) that can automatically restart unresponsive devices — keeping surveillance and monitoring systems online. Advanced Layer 2+ features including VLANs, QoS, 802.1X and ACLs help segment and protect critical security infrastructure. Rackmountable and built from durable metal, the switch fits server rooms and network closets. Upgrade your site’s networking and secure your PoE deployments today — ideal for CCTV, access control, VoIP and wireless projects.
Features
- Deliver data and up to 220W total PoE power to 16 devices, eliminating separate power runs and reducing installation cost for IP cameras, access points and VoIP phones
- Web-managed PoE+ controls and PDM self-healing restart unresponsive devices to maximize uptime for security and monitoring systems
- Two SFP fiber slots extend network reach and isolate traffic for remote surveillance sites or backbone connectivity
- Layer 2+ management (VLAN, QoS, RSTP, ACLs) secures and prioritizes video, voice and critical monitoring traffic
- Rackmount metal chassis with 16 Gigabit ports provides reliable, high-throughput connectivity for medium enterprise networks
| General Information | |
|---|---|
| Brand Name | Intellinet |
| Manufacturer | IC INTRACOM |
| Product Name | 16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports |
| Product Type | Ethernet Switch |
| Product Model | 561341 |
| Manufacturer Part Number | 561341 |
| Technical Information | |
| Material | Metal |
| Power Consumption | 260W |
| Network Switch Type | Managed, PoE |
| Media Type Supported | Optical Fiber, Twisted Pair |
| I/O Expansions | |
| Expansion Slot Type | SFP (mini-GBIC) |
| Number of SFP Slots | 2 |
| Number of Total Expansion Slots | 2 |
| Interfaces/Ports | |
| Modular | Yes |
| Network (RJ-45) | Yes |
| Total Number of Network Ports | 16 |
| Management & Protocols | |
| Manageable | Yes |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T, 1000Base-X |
| Network & Communication | |
| Layer Supported | 2 |
| Ethernet Technology | 10 Gigabit Ethernet |
| Networking Standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Physical Characteristics | |
| Width | 17.3" |
| Height | 1.7" |
| Weight | 5.51lb |
| Power Description | |
| Frequency | 50 Hz, 60 Hz |
| PoE Budget | 220W |
| Power Source | Power Supply |
| PoE (RJ-45) Port | Yes |
| Product Information | |
| Length | 8.2" |
| Mount Type | Rack Mount |
| Warranty | |
| Limited Warranty | 3-Year |
