Belden 6000UE 010Z500 12/2 Stranded Security and Commercial Audio Cable, Plenum-CL2P Stranded Bare Copper Conductors with Flamarrest Insulation, Flamarrest Jacket with Ripcord, 500' (152.4m), Black

SKU: 6000UE-010Z500 MPN: 6000UE 010Z500 Belden
Product images for Belden 6000UE 010Z500 12/2 Stranded Security and Commercial Audio Cable, Plenum-CL2P Stranded Bare Copper Conductors with Flamarrest Insulation, Flamarrest Jacket with Ripcord, 500' (152.4m), Black. 1 image(s) available. Click on image to view full size.

Key Features

  • Reliable, low‑noise audio transmission for security, surveillance and intercom systems, minimizing false alarms and improving voice clarity
  • Plenum‑rated CL2P construction with Flamarrest® insulation and jacket for safe, code‑compliant installations in air handling spaces
  • Heavy 12 AWG stranded bare copper conductors deliver robust current capacity and consistent performance over long 500' runs
  • Ripcord and ReelTuff box speed termination and handling on the jobsite, reducing installation time and labor costs
  • 10‑year limited warranty and RoHS/WEEE compliance for long‑term reliability and environmental assurance

Quick Specifications

Brand Name
Belden
Manufacturer
Belden CDT, Inc
Product Name
Security & Sound, 2 Conductor 12 AWG BC, CL2P
Product Type
Audio Cable
View Full Technical Specifications

Product Information Tabs

Overview

Built for mission‑critical audio in security, monitoring and PA environments, the Belden 6000UE 010Z500 is a plenum audio cable engineered to deliver clear, dependable sound where it matters most. This Plenum‑CL2P cable features two 12 AWG stranded bare copper conductors with Belden’s Flamarrest® insulation and Flamarrest® plenum jacket to meet strict fire and smoke standards for plenum spaces. The 500' ReelTuff box and integrated ripcord make pulls and terminations faster, reducing installation time on large surveillance, intercom and commercial audio deployments. With stranded 12 AWG conductors you get superior flexibility for routing while maintaining the conductivity required for low‑noise, high‑fidelity audio and PA performance. Ideal for security and surveillance audio feeds, intercoms, and building monitoring systems, this cable is indoor rated and backed by a 10‑year limited warranty and industry environmental certifications. Choose Belden’s plenum audio cable to simplify code‑compliant installs and ensure consistent audio quality — perfect for your next security or commercial audio project.

Features

  • Reliable, low‑noise audio transmission for security, surveillance and intercom systems, minimizing false alarms and improving voice clarity
  • Plenum‑rated CL2P construction with Flamarrest® insulation and jacket for safe, code‑compliant installations in air handling spaces
  • Heavy 12 AWG stranded bare copper conductors deliver robust current capacity and consistent performance over long 500' runs
  • Ripcord and ReelTuff box speed termination and handling on the jobsite, reducing installation time and labor costs
  • 10‑year limited warranty and RoHS/WEEE compliance for long‑term reliability and environmental assurance
General Information
Brand Name Belden
Manufacturer Belden CDT, Inc
Product Name Security & Sound, 2 Conductor 12 AWG BC, CL2P
Product Type Audio Cable
Manufacturer Part Number 6000UE 010Z500
Technical Information
Material Bare Copper
Shielding No
Cable Type Category 6
Jacket Type Plenum
Cable Rating Plenum
Conductor Count 2
Jacket Material PVC-LS
Number of Pairs 1
Device Supported Audio Device, Intercom
Application/Usage Intercom/PA Systems, Sound/Audio Systems
Solid or Stranded Stranded
Conductor Material Bare Copper
American Wire Gauge 12AWG
Number of Conductors 2
Environmental Conditions
Operating Temperature (T-T) 0-75°C
Physical Characteristics
Color Black
Cable Length 500'
Package Type ReelTuff Box
Insulation Material PVC-LS
Product Information
Length 500'
Warranty
Limited Warranty 10-Year
Miscellaneous
Features Bendable, Stranded
Indoor/Outdoor Indoor
Environmentally Friendly Yes
Environmental Certification China RoHS 2, EU RoHS, EU WEEE, RoHS 2
