Belden 6100UE 009Z100014/2 Stranded Security and Commercial Audio Cable, Plenum, BC, CL2P, Flamarrest, 1000' (304.8m) ReelTuff Box, White

SKU: 6100UE-009Z1000 MPN: 6100UE 009Z1000 Belden
Belden 6100UE 009Z1000 Security and Commercial Audio Cable, Plenum-CL2P, 2-Conductor 14AWG Stranded Bare Copper Conductors with Flamarrest Insulation, Flamarrest Jacket with Ripcord, 1000' (304.8m) ReelTuff Box, White
Product images for Belden 6100UE 009Z100014/2 Stranded Security and Commercial Audio Cable, Plenum, BC, CL2P, Flamarrest, 1000' (304.8m) ReelTuff Box, White. 1 image(s) available. Click on image to view full size.

Key Features

  • Plenum-rated safety for air-handling spaces: reduces flame and smoke risk for compliant security and commercial audio installs
  • Reliable audio performance with 14 AWG stranded bare copper conductors for clear PA, intercom and surveillance audio
  • Flamarrest® insulation and jacket for enhanced flame retardance and low-smoke behavior in critical building spaces
  • 1000' ReelTuff box reduces pulls, speeds installation and minimizes waste on long runs
  • Flexible stranded construction eases routing through tight conduit and rack spaces, improving install efficiency
  • Backed by a 10-year limited warranty for long-term system reliability and peace of mind

Quick Specifications

Product Model
6100UE 009Z1000
Brand Name
Belden
Package Type
ReelTuff Box
Product Name
Security & Sound, 2 Conductor 14 AWG BC, CL2P
View Full Technical Specifications

Explore the details

Product information

6100UE 009Z1000

Overview

Keep audio channels safe and dependable in security, surveillance and commercial audio environments with the Belden plenum security and commercial audio cable. Designed for mission-critical intercom, PA and monitoring applications, this 2-conductor 14 AWG stranded cable delivers consistent signal integrity while meeting plenum (CL2P) fire-safety requirements. The Flamarrest® insulation and jacket provide superior flame retardance and low-smoke characteristics, making it ideal for use in air-handling plenums and riser spaces.

Built with stranded bare copper conductors for flexibility and reliable connectivity, the cable comes in a 1000' ReelTuff box to simplify long runs and reduce installation time. Its bendable construction and industry certifications ensure compatibility with audio devices, public address systems and surveillance audio feeds, while the 10-year limited warranty supports long-term deployments. Whether specifying cabling for a new security control room, upgrading PA infrastructure, or adding monitoring and intercom lines, the Belden 6100UE plenum audio cable provides a fire-safe, installer-friendly solution. Order now for safer, cleaner audio connections in your next security or commercial audio project.

Features

  • Plenum-rated safety for air-handling spaces: reduces flame and smoke risk for compliant security and commercial audio installs
  • Reliable audio performance with 14 AWG stranded bare copper conductors for clear PA, intercom and surveillance audio
  • Flamarrest® insulation and jacket for enhanced flame retardance and low-smoke behavior in critical building spaces
  • 1000' ReelTuff box reduces pulls, speeds installation and minimizes waste on long runs
  • Flexible stranded construction eases routing through tight conduit and rack spaces, improving install efficiency
  • Backed by a 10-year limited warranty for long-term system reliability and peace of mind
29 of 29 specifications
Technical specifications for Belden 6100UE 009Z100014/2 Stranded Security and Commercial Audio Cable, Plenum, BC, CL2P, Flamarrest, 1000' (304.8m) ReelTuff Box, White
General Information
Brand Name Belden
Manufacturer Belden CDT, Inc
Package Type ReelTuff Box
Product Name Security & Sound, 2 Conductor 14 AWG BC, CL2P
Product Type Audio Cable
Application/Usage Intercom/PA Systems, Sound/Audio Systems
Manufacturer Part Number 6100UE 009Z1000
Technical Information
Shielding No
Jacket Type Plenum Duplex Zip
Cable Rating Plenum
Conductor Count 2
Number of Pairs 1
Device Supported Audio Device, Audio System, Intercom, Public Address System, Sound System
Solid or Stranded Stranded
Conductor Material Bare Copper
American Wire Gauge 14AWG
Number of Conductors 2
Environmental Conditions
Operating Temperature (T-T) 0-75°C
Physical Characteristics
Color White
Material Bare Copper
Cable Length 1000.00'
Jacket Material PVC
Insulation Material PVC-LS
Product Information
Length 1000.00'
Warranty
Limited Warranty 10-Year
Miscellaneous
Features Bendable, Stranded
Indoor/Outdoor Indoor
Environmentally Friendly Yes
Environmental Certification China RoHS 2, EU WEEE, RoHS, RoHS 2
