Belden 6500FE 010U250 22/2 Stranded Speaker Cable, Plenum-CMP, stranded bare copper conductors with Flamarrest insulation, Beldfoil shield and Flamarrest jacket with ripcord, 250' (76.2m), Black
Key Features
- Delivers clear, low-noise audio for commercial security, intercom and PA systems, reducing interference that can impact surveillance and monitoring
- CMP plenum-rated construction (Flamarrest jacket and insulation) for fire-code compliant installations in air-handling spaces
- 22 AWG stranded bare copper conductors with Beldfoil® shielding for reliable signal transfer and improved audio fidelity
- Flexible, bendable design with ripcord for faster pulls and faster installation in tight conduits and plenum runs
- Durable build backed by a 10-year limited warranty to minimize maintenance and lower total cost of ownership
Quick Specifications
- Product Model
- 6500FE 010U250
- Brand Name
- Belden
- Product Name
- 6500FE Multi-Conductor - Commercial Audio Systems - 2 Conductors Cabled
- Product Type
- Audio Cable
Explore the details
Product information
6500FE 010U250
Overview
Ensure dependable, low-noise audio in your security and commercial audio projects with the Belden 6500FE plenum audio cable. Purpose-built for intercoms, public-address and monitoring systems, this plenum-CMP rated speaker cable combines 22 AWG stranded bare copper conductors with Beldfoil® shielding and Flamarrest® insulation and jacket to preserve signal integrity in demanding environments. The 250' reel gives you a convenient length for runs in air-handling plenums while meeting fire and safety codes.
Installers benefit from the cable's flexibility, stranded construction and ripcord for faster pulls and cleaner terminations, reducing labor time on large deployments. The Beldfoil shield and quality conductor materials cut down on electromagnetic interference—critical for clear voice announcements, surveillance audio feeds and multi-zone PA systems. Because it’s engineered by Belden, you get a cable designed for long service life and consistent performance. Ideal for security, surveillance, intercom and commercial audio installations—specify the Belden 6500FE for your next project or order a 250' reel today to ensure reliable, code-compliant audio distribution.
Features
- Delivers clear, low-noise audio for commercial security, intercom and PA systems, reducing interference that can impact surveillance and monitoring
- CMP plenum-rated construction (Flamarrest jacket and insulation) for fire-code compliant installations in air-handling spaces
- 22 AWG stranded bare copper conductors with Beldfoil® shielding for reliable signal transfer and improved audio fidelity
- Flexible, bendable design with ripcord for faster pulls and faster installation in tight conduits and plenum runs
- Durable build backed by a 10-year limited warranty to minimize maintenance and lower total cost of ownership
| General Information | |
|---|---|
| Brand Name | Belden |
| Manufacturer | Belden CDT, Inc |
| Product Name | 6500FE Multi-Conductor - Commercial Audio Systems - 2 Conductors Cabled |
| Product Type | Audio Cable |
| Country of Origin | MX |
| Manufacturer Part Number | 6500FE 010U250 |
| Technical Information | |
| Shielding | Yes |
| Cable Type | Category 6 |
| Jacket Type | CMP, FT6, Plenum Duplex Zip |
| Cable Rating | Plenum |
| Conductor Count | 2 |
| Number of Pairs | 1 |
| Device Supported | Audio Device, Audio System, Intercom, Public Address System, Sound System |
| Solid or Stranded | Stranded |
| Conductor Material | Bare Copper |
| American Wire Gauge | 22AWG |
| Number of Conductors | 2 |
| Environmental Conditions | |
| Operating Temperature (T-T) | 0-75°C |
| Physical Characteristics | |
| Color | Black |
| Material | Bare Copper |
| Cable Length | 250.00' |
| Jacket Material | PVC |
| Insulation Material | PVC-LS |
| Product Information | |
| Length | 250.00' |
| Warranty | |
| Limited Warranty | 10-Year |
| Miscellaneous | |
| Features | Bendable, Stranded |
| Indoor/Outdoor | Indoor |
| Environmentally Friendly | Yes |
| Environmental Certification | China RoHS, China RoHS 2, ELV, EU RoHS, RoHS, RoHS 2, WEEE |
