Belden 6502FE 009Z1000 22/4 Stranded Speaker Cable, Plenum-CMP, stranded bare copper conductors with Flamarrest insulation, Beldfoil shield and Flamarrest jacket with ripcord, 1000' (304.8m), White

SKU: 6502FE-009Z1000 MPN: 6502FE 009Z1000 Belden
Belden 6502FE 009Z1000 Security and Commercial Audio Cable, Plenum-CMP 4-22AWG Stranded Bare Copper Conductors, 1000' (304.8m), White
Product images for Belden 6502FE 009Z1000 22/4 Stranded Speaker Cable, Plenum-CMP, stranded bare copper conductors with Flamarrest insulation, Beldfoil shield and Flamarrest jacket with ripcord, 1000' (304.8m), White. 1 image(s) available. Click on image to view full size.

Key Features

  • Reliable, low-noise audio for security and surveillance systems, minimizing interference for clear PA, intercom and monitoring audio
  • CMP plenum rating and Flamarrest jacket provide fire-safe installation in air-handling spaces to meet building code requirements
  • Beldfoil shield and stranded 22 AWG bare copper conductors reduce EMI/RFI for consistent signal integrity in noisy environments
  • 4-conductor design and 1000' spool length cut installation time and splices on large commercial projects
  • Flexible stranded construction with ripcord simplifies routing and termination, improving installer efficiency and uptime

Quick Specifications

Product Model
6502FE 009Z1000
Brand Name
Belden
Product Name
6502FE Multi-Conductor - Commercial Applications
Product Type
Control Cable
View Full Technical Specifications

Explore the details

Product information

6502FE 009Z1000

Overview

Deliver clear, reliable audio in plenum spaces where safety and signal integrity matter most. The Belden 6502FE 22/4 Plenum Speaker Cable is engineered for commercial security, surveillance and AV installations, providing low-noise performance for intercom/PA, speaker runs and monitoring systems. This control-grade plenum audio cable features four stranded 22 AWG bare copper conductors, a Beldfoil® shield to block EMI/RFI, and Flamarrest® insulation and jacket for CMP/FT6 plenum compliance. With a full 1000' (304.8 m) spool, you reduce splices and labor on large deployments while maintaining consistent audio and power-limited control signals. The flexible stranded construction and built-in ripcord make jacket removal and termination fast for professional installers. Ideal for security, alarm and surveillance projects where code-compliant, high-performance audio cabling is required, the Belden 6502FE supports reliable monitoring and system uptime. Specify this plenum-rated speaker cable for your next commercial or institutional AV, security or intercom installation to ensure safe, interference-free audio — order now or contact your Belden supplier to add it to your project.

Features

  • Reliable, low-noise audio for security and surveillance systems, minimizing interference for clear PA, intercom and monitoring audio
  • CMP plenum rating and Flamarrest jacket provide fire-safe installation in air-handling spaces to meet building code requirements
  • Beldfoil shield and stranded 22 AWG bare copper conductors reduce EMI/RFI for consistent signal integrity in noisy environments
  • 4-conductor design and 1000' spool length cut installation time and splices on large commercial projects
  • Flexible stranded construction with ripcord simplifies routing and termination, improving installer efficiency and uptime
26 of 26 specifications
Technical specifications for Belden 6502FE 009Z1000 22/4 Stranded Speaker Cable, Plenum-CMP, stranded bare copper conductors with Flamarrest insulation, Beldfoil shield and Flamarrest jacket with ripcord, 1000' (304.8m), White
General Information
Brand Name Belden
Manufacturer Belden CDT, Inc
Product Name 6502FE Multi-Conductor - Commercial Applications
Product Type Control Cable
Application/Usage Audio/Speaker, Intercom/PA, Noisy Environment, Power-Limited Controls, Security System
Manufacturer Part Number 6502FE 009Z1000
Technical Information
Shielding Yes
Cable Type Bare Wire
Jacket Type CMP, FT6, Plenum Duplex Zip
Cable Rating Plenum
Conductor Count 4
Device Supported Alarm, Security Device
Solid or Stranded Stranded
Conductor Material Bare Copper
American Wire Gauge 22AWG
Number of Conductors 4
Environmental Conditions
Operating Temperature (T-T) 0-75°C
Physical Characteristics
Color White
Material Bare Copper
Cable Length 1000.00'
Jacket Material PVC
Insulation Material PVC-LS
Miscellaneous
Features Bendable, Stranded
Indoor/Outdoor Indoor
Environmentally Friendly Yes
Environmental Certification China RoHS, ELV, EU RoHS, RoHS, RoHS 2, WEEE
