Bose Professional EdgeMax EM180 In-Ceiling Loudspeaker with 8" Woofer, White
Image of 7
Key Features
- Room-filling, boundary-optimized coverage reduces the number of speakers needed and simplifies audio zoning for large venues
- Deep, accurate low end from an 8" woofer and 125W power for punchy background music and clear paging
- Wide 180° horizontal pattern with PhaseGuide technology ensures consistent coverage along wall-ceiling boundaries for uniform sound in lobbies, retail, and houses of worship
- 2-way design with high-frequency compression driver delivers intelligible speech for paging, security announcements, and surveillance monitoring
- Quick, secure installation with auto-hold spring mounting arms and magnetic grille minimizes install time and service disruption
- UL1480A plenum rating and 70/100V transformer options support compliant installations in air-handling spaces and flexible commercial wiring
Quick Specifications
- Product Model
- EM180
- Brand Name
- Bose Professional
- Product Line
- EdgeMax
- Product Name
- EdgeMax EM180 Loudspeaker
Frequently Bought Together
Bose Professional EdgeMax EM180 In-Ceiling Loudspeaker with 8" Woofer, White
$640.64
2 items selected
Total: $721.46
Explore the details
Product information
777189-0220
Overview
Deliver consistent, room-filling audio without compromising architectural aesthetics. The Bose Professional EdgeMax EM180 in-ceiling loudspeaker is engineered for commercial environments that demand both coverage and discretion — from retail and hospitality to transportation hubs and monitoring/control rooms. Its PhaseGuide technology produces a nominal 180° horizontal coverage pattern when mounted near wall-ceiling boundaries, reducing the number of units required to cover corridors, concourses, and bar or dining zones.
Built for performance, the EM180 combines a high-frequency compression driver and an 8" woofer with 125W RMS capability to provide clear voice reproduction and extended bass response (45 Hz–20 kHz). Sensitivity of 93 dB and an 8-ohm/70/100V selectable transformer ensure flexible deployment for paging, background music, security announcements, and surveillance monitoring. Installers benefit from spring-loaded auto-hold arms and a magnetic grille for fast access to wiring and tap settings.
Choose the EdgeMax EM180 when you need pro-level, plenum-rated in-ceiling speakers that support security, surveillance, and public-address applications. Contact your Bose Professional dealer to specify the EM180 for your next project.
Features
- Room-filling, boundary-optimized coverage reduces the number of speakers needed and simplifies audio zoning for large venues
- Deep, accurate low end from an 8" woofer and 125W power for punchy background music and clear paging
- Wide 180° horizontal pattern with PhaseGuide technology ensures consistent coverage along wall-ceiling boundaries for uniform sound in lobbies, retail, and houses of worship
- 2-way design with high-frequency compression driver delivers intelligible speech for paging, security announcements, and surveillance monitoring
- Quick, secure installation with auto-hold spring mounting arms and magnetic grille minimizes install time and service disruption
- UL1480A plenum rating and 70/100V transformer options support compliant installations in air-handling spaces and flexible commercial wiring
| General Information | |
|---|---|
| Brand Name | Bose Professional |
| Manufacturer | Bose Corporation |
| Product Line | EdgeMax |
| Product Name | EdgeMax EM180 Loudspeaker |
| Product Type | Speaker |
| Product Model | EM180 |
| Product Series | EM |
| Manufacturer Part Number | 777189-0220 |
| Technical Information | |
| Impedance | 8 ohms |
| Sensitivity | 93dB |
| Speaker Size | 8" |
| Crossover Type | 2-way |
| Application/Usage | Bar, Concourse, Conferencing, Hospitality, House of Worship, Resort, Restaurant, Retail Store, Transportation |
| Audio | |
| RMS Output Power | 125W |
| Maximum Frequency Response | 20 kHz |
| Minimum Frequency Response | 45Hz |
| Others | |
| Model Number Replaces | 777189-0210 |
| Physical Characteristics | |
| Size | 8" |
| Color | White |
| Depth | 9.8" |
| Width | 13.4" |
| Height | 13.18" |
| Product Information | |
| Mount Type | In-ceiling Mount, Surface Mount |
| Miscellaneous | |
| Indoor/Outdoor | Indoor |
| Country of Origin | CN |
