Bose Professional 794042-3360 Speaker, Arenamatch AM20/60 Outdoor Loudspeaker
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Image of 4
Key Features
- Deliver consistent, intelligible coverage across large outdoor venues, ensuring spectators hear announcements and music clearly from every seat
- Flexible DeltaQ array design with 10°, 20°, and 40° vertical modules plus replaceable 60/80/100° waveguides to tailor coverage and reduce required modules
- High output and vocal clarity driven by a 14" neodymium woofer and six EMB2S compression drivers for long-throw, high-SPL performance
- Built for harsh environments: water-resistant woofer, three-layer stainless grille, industrial polyurethane finish and EN54-24 certification for voice alarm systems
- Reduce installation time and system cost with lighter arrays, M12 mounting inserts and compatibility with Bose PowerMatch amps and ControlSpace DSP
- Adaptable for security and monitoring integrations—supports voice-alarm, public address and emergency notification systems for stadiums, arenas and critical infrastructure
Quick Specifications
- Product Model
- AM20/60
- Brand Name
- Bose Professional
- Product Line
- ArenaMatch
- Product Name
- ArenaMatch AM20 DeltaQ Array Loudspeaker
Product Information Tabs
Overview
When consistent, high-SPL coverage and spoken-word intelligibility matter, the Bose Professional ArenaMatch AM20/60 outdoor loudspeaker delivers. This ArenaMatch pro speaker from Bose Professional is designed for stadiums, arenas and outdoor entertainment complexes, providing clear music reproduction and emergency voice announcements across wide audience areas. Engineered with a 14-inch neodymium woofer and six EMB2S titanium-diaphragm compression drivers, the AM20/60 offers 750W RMS capability and a usable frequency range from about 65 Hz to 16 kHz for full-range performance.
DeltaQ array technology and interchangeable waveguides let system designers shape directivity (Q) precisely—minimizing coverage overlap and reducing the number of modules required. The AM20/60 is rated for direct-exposure outdoor installations with a three-layer stainless grille, water-resistant coatings and EN54-24 certification for voice alarm systems, making it suitable for security, surveillance audio distribution and emergency monitoring. Compatible with Bose PowerMatch amplifiers, ControlSpace DSP and ArenaMatch accessories, it streamlines commissioning and saves on labor and hardware costs. Specify the ArenaMatch AM20/60 for your next stadium, arena or critical-venue audio and voice-alarm installation—contact our sales team for system design or a quote.
Features
- Deliver consistent, intelligible coverage across large outdoor venues, ensuring spectators hear announcements and music clearly from every seat
- Flexible DeltaQ array design with 10°, 20°, and 40° vertical modules plus replaceable 60/80/100° waveguides to tailor coverage and reduce required modules
- High output and vocal clarity driven by a 14" neodymium woofer and six EMB2S compression drivers for long-throw, high-SPL performance
- Built for harsh environments: water-resistant woofer, three-layer stainless grille, industrial polyurethane finish and EN54-24 certification for voice alarm systems
- Reduce installation time and system cost with lighter arrays, M12 mounting inserts and compatibility with Bose PowerMatch amps and ControlSpace DSP
- Adaptable for security and monitoring integrations—supports voice-alarm, public address and emergency notification systems for stadiums, arenas and critical infrastructure
| General Information | |
|---|---|
| Brand Name | Bose Professional |
| Manufacturer | Bose Corporation |
| Product Line | ArenaMatch |
| Product Name | ArenaMatch AM20 DeltaQ Array Loudspeaker |
| Product Type | Speaker |
| Product Model | AM20/60 |
| Product Series | AM |
| Manufacturer Part Number | 794042-3360 |
| Technical Information | |
| Material | Neodymium |
| Impedance | 8 ohms |
| Sensitivity | 99dB |
| Crossover Type | 2-way |
| Application/Usage | Alarm, Arena, Entertainment Center, Fire Alarm, Stadium |
| Audio | |
| RMS Output Power | 750W |
| Maximum Frequency Response | 16 kHz |
| Minimum Frequency Response | 65Hz |
| Physical Characteristics | |
| Size | 14" |
| Color | Black |
| Depth | 16.38" |
| Width | 30.8" |
| Height | 17.2" |
| Weight | 79.81lb |
| Durability | Water Resistant |
| Miscellaneous | |
| Features | Adapt to a variety of configurations � all models ship standard with bi-amp capability, passive crossover, and 70/100V transformer inputs, Deliver high-SPL, long-throw music reproduction and vocal intelligibility with a 14-inch neodymium woofer and six Bose Professional EMB2S titanium-diaphragm neodymium compression drivers, Easily customize horizontal coverage with replaceable waveguides that allow you to further customize coverage and even form asymmetrical patterns for improved acoustic performance in left/right arrays, EN 54-24 certified: EN 54-24: 2008, Loudspeaker for Voice Alarm Systems for Fire Detection and Fire Alarm Systems for Buildings, refer to the installation guide for specifics, Improve sound quality, consistency, and vocal clarity with DeltaQ array technology, which allows directivity, or Q, to vary in each module to more precisely match coverage to audience area, Provide full coverage with fewer modules � 10 deg, 20 deg, and 40 deg modules allow you to create arrays that improve sight lines, reduce weight, and lower system costs by requiring fewer modules compared to conventional arrays, Rated for direct-exposure outdoor installations, three-layer stainless steel grille, woofer cone coating, industrial polyurethane exterior coating, and molded input cover, Reduce commissioning time by using 40 deg modules for point-source applications and 10 deg, 20 deg and 40 deg modules for line arrays all with the same transducers for consistent tonal balance, Save time during installation using Bose Professional accessory mounting hardware or use the standard M12 threaded inserts to interface with custom array frames, Streamline the design process by combining with complementary Bose Professional products, such as ArenaMatch Utility zone-fill loudspeakers, PowerMatch amplifiers, and ControlSpace DSP |
| Indoor/Outdoor | Outdoor |
