Bose Professional DesignMax 2-Way Indoor Loudspeaker with 8" Woofer, Black
Image of 3
Key Features
- Instant, room-filling clarity: custom Bose drivers deliver high SPL and balanced coverage for foreground music, paging, and voice announcements without complex DSP.
- Fast, damage-free installation: patented QuickHold U-bracket and Euroblock connectors cut installation time and simplify troubleshooting on site.
- Seamless aesthetic integration: low‑bezel grille and black or white finish blend into commercial interiors for retail, hospitality, or corporate AV deployments.
- Flexible mounting and reliable performance: surface-, wall- or ceiling-mountable 2-way design with an 8" woofer and 1" compression driver for broad frequency response.
- Scalable system compatibility: works with select Bose DSPs and amplifiers to enable advanced loudspeaker EQ and SmartBass processing for enhanced low-end control.
Quick Specifications
- Product Model
- DM8S
- Brand Name
- Bose Professional
- Product Line
- DesignMax
- Product Name
- DesignMax DM8S Surface-Mounted Loudspeaker
Explore the details
Product information
801332-0110
Overview
Deliver clear, impactful audio across commercial spaces with the Bose Professional DesignMax 2-way indoor loudspeaker. Built for foreground music, paging, and integrated security audio, the DM8S pairs an 8" coaxial woofer with a center‑firing 1" compression driver to produce a wide 52 Hz–20 kHz frequency range and powerful output (150W RMS). That means intelligible speech for monitoring and surveillance announcements and full-bodied music for retail or hospitality environments.
Installers save time and reduce risk with the patented QuickHold U-bracket and convenient Euroblock connectors, while the minimum‑bezel grille and removable logo let the speaker blend discreetly into any décor. The DM8S operates at 8 ohms and delivers the SPL needed for foreground applications without requiring onboard DSP—though integration with Bose DSPs and amplifiers unlocks loudspeaker EQ and SmartBass processing when deeper tuning is required. Backed by a 5-year limited warranty, this surface-mounted DesignMax loudspeaker is ideal for AV, security paging, and surveillance monitoring systems where reliability, clarity, and fast deployment matter. Specify the Bose DesignMax DM8S for commercial installations—order now for demo or project quoting.
Features
- Instant, room-filling clarity: custom Bose drivers deliver high SPL and balanced coverage for foreground music, paging, and voice announcements without complex DSP.
- Fast, damage-free installation: patented QuickHold U-bracket and Euroblock connectors cut installation time and simplify troubleshooting on site.
- Seamless aesthetic integration: low‑bezel grille and black or white finish blend into commercial interiors for retail, hospitality, or corporate AV deployments.
- Flexible mounting and reliable performance: surface-, wall- or ceiling-mountable 2-way design with an 8" woofer and 1" compression driver for broad frequency response.
- Scalable system compatibility: works with select Bose DSPs and amplifiers to enable advanced loudspeaker EQ and SmartBass processing for enhanced low-end control.
| General Information | |
|---|---|
| Brand Name | Bose Professional |
| Manufacturer | Bose Corporation |
| Product Line | DesignMax |
| Product Name | DesignMax DM8S Surface-Mounted Loudspeaker |
| Product Type | Speaker |
| Product Model | DM8S |
| Product Series | DM |
| Manufacturer Part Number | 801332-0110 |
| Technical Information | |
| Impedance | 8 ohms |
| Sensitivity | 118dB |
| Speaker Size | 8" |
| Crossover Type | 2-way |
| Audio | |
| RMS Output Power | 150W |
| Maximum Frequency Response | 20 kHz |
| Minimum Frequency Response | 52Hz |
| Physical Characteristics | |
| Size | 8" |
| Color | Black |
| Depth | 9.96" |
| Width | 9.8" |
| Height | 15.6" |
| Weight | 22.71 lb |
| Product Information | |
| Length | 14.64" |
| Diameter | 8" |
| Mount Type | Ceiling Mount, Surface Mount, Wall Mount |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Indoor/Outdoor | Indoor |
| Country of Origin | CN |
| Environmentally Friendly | Yes |
