Bose Professional ArenaMatch AMU105 Utility Outdoor Loudspeaker with 5.25" Woofer, Black
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Image of 2
Key Features
- Deliver clear, intelligible outdoor sound for zone-fill or foreground use, ensuring announcements and music remain audible in stadiums, resorts, and public venues
- Consistent tonal match with ArenaMatch arrays thanks to the EMB2S compression driver—simplifies system design and preserves voice clarity for security paging and monitoring
- Built for harsh environments with IP55 rating, water-resistant woofer coating, three-layer stainless steel grille and industrial exterior for reliable outdoor operation
- Wide 100°×100° coverage and a compact 5.25" woofer provide even dispersion and low-frequency support while remaining visually unobtrusive
- EN 54-24 certification and optional 70/100V transformer inputs make it ideal for voice alarm, public address and integrated security systems
Quick Specifications
- Product Model
- AMU105
- Brand Name
- Bose Professional
- Product Line
- ArenaMatch Utility
- Product Name
- ArenaMatch Utility AMU105 Small-format Foreground/Fill Loudspeaker
Product Information Tabs
Overview
For outdoor venues that demand reliable, intelligible sound, the Bose Professional ArenaMatch AMU105 Utility Outdoor Loudspeaker delivers high-impact zone-fill and foreground coverage in a compact enclosure. This AMU105 model combines a 5.25" Bose LF5 woofer and EMB2S compression driver to reproduce vocals and music with clarity across a 100 Hz–18 kHz bandwidth and up to 118 dB peak SPL—perfect for stadium concourses, resorts, shopping centers, and event spaces.
Engineered for real-world installations, the speaker offers an IP55 weather rating, corrosion-resistant grille and molded input cover for lasting performance in outdoor and semi-exposed environments. The 100°×100° constant-directivity horn provides even coverage whether mounted horizontally or vertically, while EN54-24 certification and 70/100V transformer options simplify integration into voice alarm, security paging and monitoring systems.
Choose the ArenaMatch AMU105 to maintain consistent tonal balance across distributed systems and to support surveillance, public address and emergency notification workflows. Contact us to specify AMU105 for your next stadium, resort or security audio deployment.
Features
- Deliver clear, intelligible outdoor sound for zone-fill or foreground use, ensuring announcements and music remain audible in stadiums, resorts, and public venues
- Consistent tonal match with ArenaMatch arrays thanks to the EMB2S compression driver—simplifies system design and preserves voice clarity for security paging and monitoring
- Built for harsh environments with IP55 rating, water-resistant woofer coating, three-layer stainless steel grille and industrial exterior for reliable outdoor operation
- Wide 100°×100° coverage and a compact 5.25" woofer provide even dispersion and low-frequency support while remaining visually unobtrusive
- EN 54-24 certification and optional 70/100V transformer inputs make it ideal for voice alarm, public address and integrated security systems
| General Information | |
|---|---|
| Brand Name | Bose Professional |
| Manufacturer | Bose Corporation |
| Product Line | ArenaMatch Utility |
| Product Name | ArenaMatch Utility AMU105 Small-format Foreground/Fill Loudspeaker |
| Product Type | Speaker |
| Product Model | AMU105 |
| Product Series | AMU |
| Manufacturer Part Number | 811433-0110 |
| Technical Information | |
| Impedance | 8 ohms |
| Sensitivity | 92dB |
| Speaker Size | 5.25" |
| Crossover Type | 2-way |
| Application/Usage | Alarm, Arena, Brewery, Entertainment Center, Fairground, Fire Alarm, Resort, Shopping Mall, Sports Field, Stadium |
| Audio | |
| RMS Output Power | 150W |
| Number of Speakers | 1 |
| Maximum Frequency Response | 16 kHz |
| Minimum Frequency Response | 100Hz |
| Environmental Conditions | |
| Sound Emission | 118 dB |
| Physical Characteristics | |
| Size | 5.25" |
| Color | Black |
| Depth | 9.02" |
| Width | 12" |
| Height | 6" |
| Weight | 14.33 lb |
| Durability | Dust Resistant, Water Resistant, Weather Resistant |
| Product Information | |
| Length | 11.02" |
| Mount Type | Ceiling Mount, Wall Mount |
| Warranty | |
| Limited Warranty | 2-Year, 5-Year |
| Miscellaneous | |
| Features | Adapt to a variety of configurations, Deploy as zone-fill, Deploy for high-level foreground music, Install outdoors with an IP55 weather rating, Mount easily, Perform in the most demanding applications |
| Indoor/Outdoor | Outdoor |
