RCI 8371 Surface Single MiniMag Electromagnetic Lock with Security Condition Sensor, Outswing Doors, 750 lb, Brushed Anodized Aluminum
Image of 1
Key Features
- Slim 1-7/8" profile keeps narrow outswing openings code-compliant and preserves frame clearance
- Up to 750 lb holding force provides reliable perimeter security for high-traffic doors
- Optional Security Condition Sensor (SCS) / Door Status Sensor enables real-time monitoring and simple integration with access control and surveillance systems
- Integrated surge protection and fail-safe design protect equipment and ensure secure operation during power events
- Surface-mount design with stabilizing four-bolt and keyhole mounting reduces install time and contractor labor
Quick Specifications
- Product Model
- 8371
- Brand Name
- RCI by dormakaba
- Product Line
- MiniMag
- Product Name
- 8371 Surface MiniMag
Frequently Bought Together
RCI 8371 Surface Single MiniMag Electromagnetic Lock with Security Condition Sensor, Outswing Doors, 750 lb, Brushed Anodized Aluminum
$366.91
8 items selected
Total: $729.69
Explore the details
Product information
8371 SCS 28
Overview
Secure narrow outswing doors without bulky hardware. The RCI by dormakaba 8371 Surface MiniMag electromagnetic lock is engineered to deliver dependable access control and perimeter protection where frame clearance and appearance matter. Its slim 1-7/8" profile fits undersized openings while providing up to 750 lb holding force to resist forced entry on high-traffic interior or exterior doors. Designed for easy integration with surveillance and monitoring systems, the MiniMag features field-selectable 12/24V DC power (520mA), integrated surge protection, and a fail-safe configuration to meet typical life-safety and access control requirements.
Installers benefit from a surface-mount form factor, stabilizing four-bolt "drop stop" mounting and keyhole slots that cut installation time and eliminate extra brackets. Optional Security Condition Sensor (SCS) or Door Status Sensor (DSS) simplifies alarm monitoring and system reporting. Backed by RCI by dormakaba quality and a lifetime limited warranty, the 8371 is ideal for schools, healthcare, commercial offices, and retail access projects. Specify the Surface MiniMag for your next access control or security upgrade and improve monitoring and protection with a low-profile electromagnetic lock.
Features
- Slim 1-7/8" profile keeps narrow outswing openings code-compliant and preserves frame clearance
- Up to 750 lb holding force provides reliable perimeter security for high-traffic doors
- Optional Security Condition Sensor (SCS) / Door Status Sensor enables real-time monitoring and simple integration with access control and surveillance systems
- Integrated surge protection and fail-safe design protect equipment and ensure secure operation during power events
- Surface-mount design with stabilizing four-bolt and keyhole mounting reduces install time and contractor labor
| General Information | |
|---|---|
| Brand Name | RCI by dormakaba |
| Manufacturer | dormakaba Holding |
| Product Line | MiniMag |
| Product Name | 8371 Surface MiniMag |
| Product Type | Magnetic Lock |
| Product Model | 8371 |
| Product Series | 8371 |
| Application/Usage | Inswing Door, Outswing Door |
| Country of Origin | CN |
| Manufacturer Part Number | 8371 SCS 28 |
| Technical Information | |
| Door Supported | Hinged |
| Physical Characteristics | |
| Color | Silver |
| Depth | 1.0" |
| Width | 1.9" |
| Height | 9.4" |
| Material | Bronze, Steel |
| Power Description | |
| Input Current | 520mA |
| Input Voltage | 12V DC, 24V DC |
| Product Information | |
| Mount Type | Surface Mount |
| Holding Force | 750lb |
| Warranty | |
| Limited Warranty | Lifetime |
| Miscellaneous | |
| Features | Adjustable Keyhole Mounting, Door Status Sensor (DSS), Fail Safe, Security Condition Sensor (SCS), Surge Protection |
