Planar PT3270Q 32" IPS LCD Touch Screen Monitor with Quad HD Resolution
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Key Features
- Immersive Quad HD clarity (2560 x 1440) for sharper surveillance, monitoring and digital signage visuals
- Responsive 10-point projected-capacitive touch that supports glove, waterproof and behind-glass modes for reliable public use
- IP65 front and anti-glare all-glass surface to reduce reflections and protect against dust and moisture in busy environments
- Single USB-C connectivity for streamlined video, audio and touch over one cable—simplifies installation and maintenance
- VESA 200 x 200 mounting and rugged 32-inch IPS panel for flexible deployments in kiosks, control rooms and security stations
Quick Specifications
- Brand Name
- Planar
- Manufacturer
- Leyard
- Product Line
- Planar
- Product Name
- PT3270Q 32" Touch Screen Monitor
Product Information Tabs
Overview
Deliver consistent, professional touch performance in kiosks, control rooms and security deployments with the Planar PT3270Q 32-inch IPS LCD touchscreen monitor. Built for demanding commercial environments, this Planar LCD touchscreen monitor combines Quad HD 2560 x 1440 resolution and a wide 178° viewing angle to present clearer, more accurate visuals for surveillance, monitoring and digital signage. The 10-point projected-capacitive touch supports glove and waterproof modes and can operate behind cover glass, ensuring dependable multi-touch interaction in retail, industrial and public-facing applications. An IP65-rated front, anti-glare coating and durable all-glass surface keep the display protected from dust, spills and reflections while preserving image quality. Installation is simplified with VESA 200 x 200 compatibility and a single USB-C connection that carries video, audio and touch signals. With 350 nits of brightness and a three-year limited warranty, the PT3270Q is engineered for continuous operation in security, monitoring and enterprise IT settings. Upgrade your touch deployments with a display designed for real-world use—contact your reseller or order the Planar PT3270Q for kiosks, surveillance stations and monitoring hubs today.
Features
- Immersive Quad HD clarity (2560 x 1440) for sharper surveillance, monitoring and digital signage visuals
- Responsive 10-point projected-capacitive touch that supports glove, waterproof and behind-glass modes for reliable public use
- IP65 front and anti-glare all-glass surface to reduce reflections and protect against dust and moisture in busy environments
- Single USB-C connectivity for streamlined video, audio and touch over one cable—simplifies installation and maintenance
- VESA 200 x 200 mounting and rugged 32-inch IPS panel for flexible deployments in kiosks, control rooms and security stations
| General Information | |
|---|---|
| Brand Name | Planar |
| Manufacturer | Leyard |
| Product Line | Planar |
| Product Name | PT3270Q 32" Touch Screen Monitor |
| Product Type | LCD Touchscreen Monitor |
| Product Model | PT3270Q |
| Product Series | PT |
| Manufacturer Part Number | 998-2949-00 |
| Technical Information | |
| Response Time | 14 ms GTG |
| HDCP Supported | Yes |
| Panel Technology | IPS |
| Viewable Screen Size | 31.5" |
| Certifications | |
| Energy Star | No |
| Display & Graphics | |
| Screen Size | 32" |
| Backlight Technology | Edge LED |
| Vertical Viewing Angle | 178° |
| Energy & Performance | |
| Operating Power Consumption | 26W |
| Image | |
| Aspect Ratio | 16:9 |
| Interfaces/Ports | |
| HDMI | Yes |
| DisplayPort | Yes |
| Physical Characteristics | |
| Depth | 2.4" |
| Width | 28.9" |
| Height | 16.9" |
| Weight | 28lb |
| VESA Mount Standard | 200 x 200 |
| VESA Mount Compatible | Yes |
| Touchscreen Information | |
| Touchscreen Type | Projected Capacitive |
| Multi-touch Screen | Yes |
| Video | |
| Contrast Ratio | 1000:1 |
| Brightness (Nit) | 350 |
| Maximum Resolution | 2560 x 1440 |
| Native Contrast Ratio | 41.667361111111113 |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Anti-glare, Anti-reflective |
| Country of Origin | CN |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
