Key Features
- Consolidates cameras, microphones and encoders into a single rack-mount unit to simplify AV system design and reduce equipment racks
- Simultaneous IP and USB streaming enables seamless integration with UC platforms, lecture capture and remote monitoring workflows
- Built-in four-input HD video switcher and 1080p streaming ensure crisp 1080p/30 video (1080p/60 HDMI) for professional conferencing and surveillance feeds
- 9x5 cross-point audio matrix with four EasyMic ports and AEC delivers clear, mixable audio for multi-mic rooms and security monitoring
- Intuitive web-based UI and remote IP camera control speed deployment, maintenance and live-event switching for IT and AV teams
- TAA-compliant, rack-mount form factor with 3-year limited warranty supports government and enterprise procurement and long-term reliability
Quick Specifications
- Product Model
- 999-8230-000
- Brand Name
- Vaddio by Legrand
- Product Line
- AV Bridge MATRIX PRO
- Product Name
- AV Bridge MATRIX PRO Audio/Video Bridge
Explore the details
Product information
999-8230-000
Overview
Streamline conferencing, lecture capture and security monitoring with the Vaddio by Legrand AV Bridge MATRIX PRO video conference interface unit. This all-in-one AV bridge combines a four-input HD video switcher, a 9x5 cross-point audio matrix and simultaneous IP + USB 2.0 streaming so your team can deliver polished 1080p/30 video (1080p/60 HDMI) and clear, mixed audio without a full rack of separate gear. The built-in EasyMic ports with AEC reduce background noise and echo—improving speech intelligibility for meetings, remote instruction and surveillance recordings. IT and AV managers benefit from a web-based configuration interface and remote IP control of up to four cameras, making deployment, monitoring and system updates fast and predictable. With support for H.264 streaming, rack-mount reliability, TAA compliance and a 3-year warranty, the AV Bridge MATRIX PRO is designed for enterprise, education and government environments that require consistent performance and secure integration. Ideal for unified communications, lecture capture, security and monitoring applications—add the AV Bridge MATRIX PRO to your next build or upgrade to simplify operations and elevate AV quality.
Features
- Consolidates cameras, microphones and encoders into a single rack-mount unit to simplify AV system design and reduce equipment racks
- Simultaneous IP and USB streaming enables seamless integration with UC platforms, lecture capture and remote monitoring workflows
- Built-in four-input HD video switcher and 1080p streaming ensure crisp 1080p/30 video (1080p/60 HDMI) for professional conferencing and surveillance feeds
- 9x5 cross-point audio matrix with four EasyMic ports and AEC delivers clear, mixable audio for multi-mic rooms and security monitoring
- Intuitive web-based UI and remote IP camera control speed deployment, maintenance and live-event switching for IT and AV teams
- TAA-compliant, rack-mount form factor with 3-year limited warranty supports government and enterprise procurement and long-term reliability
| General Information | |
|---|---|
| Brand Name | Vaddio by Legrand |
| Manufacturer | Legrand Group |
| Product Line | AV Bridge MATRIX PRO |
| Product Name | AV Bridge MATRIX PRO Audio/Video Bridge |
| Product Type | Audio/Video Bridge |
| Product Model | 999-8230-000 |
| Application/Usage | Audio Encoder, Audio Streaming, Video Encoding, Video Streaming, Video Switcher |
| Country of Origin | US |
| Manufacturer Part Number | 999-8230-000 |
| Technical Information | |
| Video Formats | H.264 / AVC, MJPEG |
| Certifications | |
| TAA Compliant | Yes |
| Certifications | CE, FCC, TAA |
| Interfaces/Ports | |
| HDMI | Yes |
| Network (RJ-45) | Yes |
| Physical Characteristics | |
| Color | Black |
| Depth | 8.00" |
| Dimensions | 28 x 14 x 10" |
| Form Factor | Rack Mount |
| Product Information | |
| Mount Type | Rack Mount |
| Video | |
| Graphics Mode | Full HD |
| Maximum Resolution | 1920 x 1080 |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | AEC, Audio IO, Camera Control, IP Streaming, PIP, Transitions |
| Environmental Certification | TAA |
