Vaddio 999-8240-000 Bridge Mini Audio/Video Encoder for Video Conferencing Applications
Image of 6
Key Features
- Simplifies integration of pro AV into soft codecs and streaming platforms, letting teams join meetings or publish lectures without complex routing
- Dual outputs (USB 3.0 + IP/RTMP) enable simultaneous recording, streaming and VC participation for redundancy and flexible workflows
- 4K HDMI input with onboard scaling ensures pristine source capture while delivering reliable 1080p streams for conferencing and surveillance
- PoE power and half-rack form factor for fast, clean installs in rack rooms, classrooms, huddle spaces and monitoring hubs
- Built-in audio mixer and balanced line I/O simplify DSP and pro-audio integration for consistent levels across security, lecture capture and conferencing
- Standards-based UVC/UAC drivers minimize interoperability issues with PCs, Mac, soft codecs and monitoring systems
Quick Specifications
- Product Model
- 999-8240-000
- Brand Name
- Vaddio by Legrand
- Product Name
- AV Bridge Mini
- Product Type
- Video Encoder
Explore the details
Product information
999-8240-000
Overview
Designed to make professional AV sources available to modern soft codecs and streaming platforms, the Vaddio by Legrand AV Bridge Mini video encoder converts HDMI/4K sources and pro audio into reliable USB 3.0 and IP streams for conferencing, lecture capture, security monitoring and live production. As a compact half-rack video encoder, it bridges cameras, presentation systems and DSPs into Skype for Business, Zoom, WebEx and RTMP-based CDN workflows without complicated signal chains.
The AV Bridge Mini accepts 4K (3840 x 2160) HDMI inputs and scales to deliver crisp 1080p output while offering simultaneous USB 3.0 capture and IP streaming—ideal for organizations that require redundancy between recording and live monitoring. PoE power and a built-in audio mixer with balanced line I/O simplify installation and integration with existing security, surveillance and AV systems. Standards-based UVC/UAC support ensures plug-and-play compatibility with PCs and conferencing appliances.
For IT and AV teams seeking reliable, scalable video capture for conferencing rooms, lecture halls or monitoring centers, the AV Bridge Mini provides a hardened, warranty-backed solution—deploy it for live streams, recording, or real-time surveillance and monitoring applications.
Features
- Simplifies integration of pro AV into soft codecs and streaming platforms, letting teams join meetings or publish lectures without complex routing
- Dual outputs (USB 3.0 + IP/RTMP) enable simultaneous recording, streaming and VC participation for redundancy and flexible workflows
- 4K HDMI input with onboard scaling ensures pristine source capture while delivering reliable 1080p streams for conferencing and surveillance
- PoE power and half-rack form factor for fast, clean installs in rack rooms, classrooms, huddle spaces and monitoring hubs
- Built-in audio mixer and balanced line I/O simplify DSP and pro-audio integration for consistent levels across security, lecture capture and conferencing
- Standards-based UVC/UAC drivers minimize interoperability issues with PCs, Mac, soft codecs and monitoring systems
| General Information | |
|---|---|
| Brand Name | Vaddio by Legrand |
| Manufacturer | Legrand Group |
| Product Name | AV Bridge Mini |
| Product Type | Video Encoder |
| Manufacturer Part Number | 999-8240-000 |
| Technical Information | |
| Application/Usage | Audio Encoder, Video Capturing, Video Encoding, Video Streaming |
| Certifications | |
| TAA Compliant | Yes |
| Interfaces/Ports | |
| HDMI | Yes |
| Network (RJ-45) | Yes |
| Physical Characteristics | |
| Color | Black |
| Dimensions | 18 x 11 x 5" |
| Form Factor | Rack Mount |
| Power Description | |
| Power Source | PoE |
| Product Information | |
| Mount Type | Rack Mount |
| Video | |
| Maximum Resolution | 3840 x 2160 |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Audio IO, IP Streaming |
| Certifications | CE, FCC, TAA |
| Country of Origin | US |
| Environmental Certification | TAA |
