JBL Professional AC18/95 Compact 2-Way 8" Loudspeaker, 90° 50° Coverage, Passive, White
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Key Features
- Compact, low‑profile enclosure for discreet installation close to walls or ceilings—ideal for under‑balcony, column, or wall mounting
- Rotatable 90° x 50° PT waveguide provides uniform coverage and predictable dispersion for consistent audio across listening and monitoring areas
- Powerful, natural voice reproduction from the 8in SFG low-frequency driver and 1in compression driver, supporting 250W RMS (500W program) for clear paging and background music
- FIR tuning delivers optimized frequency and phase response to improve speech intelligibility for security, surveillance, and public address systems
- Pro installation ready: dual Neutrik NL4 plus screw terminal connections and multiple mounting attachment points for fast, secure deployments
Quick Specifications
- Product Model
- AC18/95
- Brand Name
- JBL Professional
- Product Name
- AC18/95 Compact 2-Way Loudspeaker With 1 x 8" LF
- Product Type
- Speaker
Product Information Tabs
Overview
Deliver clear, intelligible audio where it matters most with the JBL Professional AC18/95 compact 2-way loudspeaker. Designed for pro audio, paging, security, and surveillance monitoring, this discreet loudspeaker fits close to walls and ceilings while filling spaces with even coverage thanks to its rotatable 90° x 50° PT waveguide. The combination of an 8in Symmetrical Field Geometry low-frequency transducer and a 1in compression driver produces natural voicing and high SPL—rated at 250W RMS (500W program) with a wide 63 Hz to 19 kHz frequency response and 93 dB sensitivity. FIR tuning fine‑tunes frequency and phase response to boost speech clarity, making the AC18/95 ideal for security monitoring rooms, retail paging, conference spaces, and houses of worship. Built for professional installers, it includes dual Neutrik NL4 connectors, a screw terminal option, and multiple bracket attachment points for quick mounting. Choose the AC18/95 when you need reliable, high‑quality sound for monitoring, surveillance, and public address applications—contact us to specify or order for your next installation.
Features
- Compact, low‑profile enclosure for discreet installation close to walls or ceilings—ideal for under‑balcony, column, or wall mounting
- Rotatable 90° x 50° PT waveguide provides uniform coverage and predictable dispersion for consistent audio across listening and monitoring areas
- Powerful, natural voice reproduction from the 8in SFG low-frequency driver and 1in compression driver, supporting 250W RMS (500W program) for clear paging and background music
- FIR tuning delivers optimized frequency and phase response to improve speech intelligibility for security, surveillance, and public address systems
- Pro installation ready: dual Neutrik NL4 plus screw terminal connections and multiple mounting attachment points for fast, secure deployments
| General Information | |
|---|---|
| Brand Name | JBL Professional |
| Manufacturer | Harman International Industries, Inc |
| Product Name | AC18/95 Compact 2-Way Loudspeaker With 1 x 8" LF |
| Product Type | Speaker |
| Product Model | AC18/95 |
| Manufacturer Part Number | AC18/95-WH |
| Technical Information | |
| Material | Cloth, Foam, Perforated-steel, Plywood |
| Impedance | 8 ohms |
| Sensitivity | 93dB |
| Speaker Size | 8" |
| Crossover Type | 2-way |
| Audio | |
| RMS Output Power | 250W |
| Maximum Frequency Response | 19 kHz |
| Minimum Frequency Response | 63Hz |
| Physical Characteristics | |
| Size | 8" |
| Color | White |
| Depth | 10" |
| Width | 9.4" |
| Height | 18.5" |
| Weight | 28.22 lb |
| Product Information | |
| Mount Type | Ceiling Mount, Freestanding, Wall Mount |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Indoor/Outdoor | Indoor |
