QSC AD-DWL.180 AcousticDesign Series 5.25" 2-Way Outdoor Landscape Loudspeaker System, 180 Degree Coverage, 80W, 110 dB

SKU: AD-DWL180 MPN: AD-DWL.180 QSC

Special Order Item

This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.

Image of QB-ADDWL180
Product images for QSC AD-DWL.180 AcousticDesign Series 5.25" 2-Way Outdoor Landscape Loudspeaker System, 180 Degree Coverage, 80W, 110 dB. 3 image(s) available. Click on image to view full size.

Key Features

  • Focused 180-degree coverage directs audio where you need it most, improving paging clarity and reducing sound bleed for outdoor security and monitoring
  • Rugged, tamper-resistant bollard design with IP55 rating and UV/salt/humidity resistance for reliable, long-life outdoor performance
  • 80W RMS power and up to 110 dB SPL deliver clear, intelligible audio across large landscapes and perimeter areas
  • Permanent direct-to-concrete or in-ground mount options minimize vandalism risk and simplify secure installations for campuses and facilities
  • Built-in Intrinsic Correction voicing via Q-SYS or CXD DSP enables fast tuning and seamless integration with existing surveillance and audio systems

Quick Specifications

Product Model
AD-DWL.180
Brand Name
QSC
Product Line
AcousticDesign
Product Name
AD-DWL.180 5.25-Inch, 2-Way, 180° Coverage
View Full Technical Specifications

Product Information Tabs

Overview

Deliver reliable, focused sound for outdoor paging, perimeter security, and landscape audio with the QSC AD-DWL.180 AcousticDesign landscape speaker. This 5.25" 2-way outdoor loudspeaker is engineered for pro installations where intelligibility and durability matter: 80W RMS power and up to 110 dB SPL ensure announcements and alerts cut through ambient noise, while the 180-degree coverage pattern directs audio precisely across plazas, walkways, and grounds. Built from durable polypropylene/fiberglass with stainless hardware and an IP55 weather rating, the AD-DWL.180 withstands UV, salt mist, humidity and temperature extremes to reduce maintenance and extend lifecycle value. The elevated bollard form and permanent direct-mount base reduce tampering and visual impact; Intrinsic Correction voicing via Q-SYS or CXD DSP simplifies system tuning for consistent voice reproduction. Ideal for security, surveillance, monitoring, campus paging, and landscape audio projects, the QSC AD-DWL.180 combines professional-grade audio performance with installation-friendly features. Contact us to spec this outdoor speaker for your next perimeter protection, public address, or monitoring deployment.

Features

  • Focused 180-degree coverage directs audio where you need it most, improving paging clarity and reducing sound bleed for outdoor security and monitoring
  • Rugged, tamper-resistant bollard design with IP55 rating and UV/salt/humidity resistance for reliable, long-life outdoor performance
  • 80W RMS power and up to 110 dB SPL deliver clear, intelligible audio across large landscapes and perimeter areas
  • Permanent direct-to-concrete or in-ground mount options minimize vandalism risk and simplify secure installations for campuses and facilities
  • Built-in Intrinsic Correction voicing via Q-SYS or CXD DSP enables fast tuning and seamless integration with existing surveillance and audio systems
General Information
Brand Name QSC
Manufacturer QSC Audio
Product Line AcousticDesign
Product Name AD-DWL.180 5.25-Inch, 2-Way, 180° Coverage
Product Type Landscape Speakers
Product Model AD-DWL.180
Product Series AD-DWL
Packaged Quantity 1
Manufacturer Part Number AD-DWL.180
Technical Information
Material Cone
Impedance 16 ohms
Sensitivity 84dB
Speaker Size 5.25"
Crossover Type 2-way
Application/Usage Landscape
Audio
RMS Output Power 80W
Number of Speakers 1
Maximum Frequency Response 25 kHz
Minimum Frequency Response 55Hz
Environmental Conditions
Sound Emission 110 dB
Physical Characteristics
Size 5.31"
Color Green
Depth 6.46"
Width 6.5"
Height 30.2"
Weight 10.36lb
Durability Humidity Resistant, Salt Resistant, Sprayproof, Tamper Resistant, UV Resistant, Weather Resistant
Form Factor Direct Mount
Enclosure Type Sealed
Product Information
Mount Type Direct Mount
Warranty
Limited Warranty 3-Year
Miscellaneous
Features Rugged Design
Indoor/Outdoor Outdoor
Environmentally Friendly Yes
Environmental Certification RoHS
