QSC AD-P6T-BK AcousticDesign 6.5" 2-Way Pendant Mount Loudspeaker, Single, Black
Image of 3
Key Features
- Consistent, professional sound coverage across ceiling, surface and pendant installations for seamless multi-zone AV and paging systems
- DMT waveguide and matched transducers deliver smooth, uniform off-axis response for clear voice intelligibility in security and monitoring environments
- Flexible 70/100V transformer with 16Ω bypass and 60W RMS capability simplifies system design for background music, paging and foreground reinforcement
- Quick-link suspension cables, slip-lock fasteners and snap-fit magnetic grille reduce install time and lower labor costs
- UV-resistant, paintable enclosure with removable logo maintains aesthetics in visible installations and prevents discoloration over time
- Intrinsic Correction voicings via Q-SYS and CXD amplifiers enable fast tuning and consistent performance across distributed sound systems
Quick Specifications
- Product Model
- AD-P6T-BK
- Brand Name
- QSC
- Product Line
- AcousticDesign
- Product Name
- AcousticDesign AD-P6T-BK Speaker
Product Information Tabs
Overview
For installers and AV integrators who need reliable, high-quality pendant audio, the QSC AcousticDesign AD-P6T-BK delivers consistent coverage and clear intelligibility for paging, background music, and security monitoring applications. This QSC pendant mount loudspeaker pairs a 6.5" weather-treated woofer with a 0.75" aluminum dome tweeter on a Directivity Matched Transition (DMT) waveguide to produce coherent off-axis response and wide 135° conical coverage. With 60W RMS handling, a focused 56Hz–20kHz frequency range, and selectable 70/100V taps plus a 16Ω bypass, the AD-P6T-BK adapts to commercial, retail, and surveillance-driven audio systems. Installers benefit from fast hardware (quick-link cables and slip-lock fasteners), a snap-fit magnetic grille with removable logo, and a sealed Euro-block connector for moisture protection. Intrinsic Correction voicings available through Q-SYS and CXD amplifiers speed system voicing and maintain consistent tonal balance across large deployments. Ideal for AV, paging, security and monitoring installations that demand dependable speech clarity and aesthetic neutrality. Specify or order the QSC AD-P6T-BK for your next pro audio, security, or surveillance deployment today.
Features
- Consistent, professional sound coverage across ceiling, surface and pendant installations for seamless multi-zone AV and paging systems
- DMT waveguide and matched transducers deliver smooth, uniform off-axis response for clear voice intelligibility in security and monitoring environments
- Flexible 70/100V transformer with 16Ω bypass and 60W RMS capability simplifies system design for background music, paging and foreground reinforcement
- Quick-link suspension cables, slip-lock fasteners and snap-fit magnetic grille reduce install time and lower labor costs
- UV-resistant, paintable enclosure with removable logo maintains aesthetics in visible installations and prevents discoloration over time
- Intrinsic Correction voicings via Q-SYS and CXD amplifiers enable fast tuning and consistent performance across distributed sound systems
| General Information | |
|---|---|
| Brand Name | QSC |
| Manufacturer | QSC Audio |
| Product Line | AcousticDesign |
| Product Name | AcousticDesign AD-P6T-BK Speaker |
| Product Type | Speaker |
| Product Series | AD-P |
| Manufacturer Part Number | AD-P6T-BK |
| Technical Information | |
| Material | Paper |
| Sensitivity | 88dB |
| Crossover Type | 2-way |
| Audio | |
| RMS Output Power | 60W |
| Maximum Frequency Response | 20 kHz |
| Minimum Frequency Response | 56Hz |
| Physical Characteristics | |
| Depth | 12.7" |
| Width | 11.3" |
| Height | 11.3" |
| Product Information | |
| Length | 11.5" |
| Diameter | 11.3" |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Indoor/Outdoor | Indoor |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
