Potter AFC-50 Analog/Addressable Releasing Fire Alarm Control Panel, 50-Addresses
Image of 1
Key Features
- Centralized addressable releasing control with 50-address capacity for precise event isolation and faster response
- Scalable power and notification support (5A base PSU, expandable NACs) to accommodate growing site needs without major rework
- Built-in Ethernet/IP communicator and IP reporting for remote monitoring, system integration and streamlined maintenance
- Programmable NACs and Quadrasync strobe synchronization for compliant, synchronized notification across multiple device brands
- Fast-response I/Os and 4,000-event history buffer that simplify troubleshooting, compliance documentation and incident review
Quick Specifications
- Product Model
- AFC-50
- Brand Name
- Potter Electric Signal, LLC
- Product Name
- Fire Alarm Control Panel
- Product Type
- Fire Alarm Control Panel
Frequently Bought Together
Potter AFC-50 Analog/Addressable Releasing Fire Alarm Control Panel, 50-Addresses
$797.20
4 items selected
Total: $4,632.63
Explore the details
Product information
AFC-50
Overview
Protect people and property with a compact, fully featured releasing fire alarm control solution. The Potter Electric Signal AFC-50 analog/addressable releasing fire alarm control panel delivers reliable addressable detection and releasing control ideal for small-to-medium commercial sites, healthcare facilities and critical infrastructure. With native support for 50 addresses and a 5A power supply (expandable through PSN-1000 series), the AFC-50 balances immediate mission-critical protection with straightforward scalability. Two regulated NACs (3A each) and flexible I/O circuits let you configure door holders, notification appliances and abort interfaces to match your security and life-safety strategy. Built-in Ethernet and IP communication enable remote monitoring, event reporting and integration with building security or surveillance systems, while the 4,000-event history and NFPA-72 smoke sensitivity tests simplify maintenance and compliance. Quadrasync strobe synchronization supports Gentex, System Sensor, Wheelock and more for coordinated evacuations. For integrators and facility managers seeking dependable monitoring, precise fault isolation and simple expansion, the AFC-50 is a practical, standards-minded choice. Contact your sales representative to configure the AFC-50 for your application or request a quote.
Features
- Centralized addressable releasing control with 50-address capacity for precise event isolation and faster response
- Scalable power and notification support (5A base PSU, expandable NACs) to accommodate growing site needs without major rework
- Built-in Ethernet/IP communicator and IP reporting for remote monitoring, system integration and streamlined maintenance
- Programmable NACs and Quadrasync strobe synchronization for compliant, synchronized notification across multiple device brands
- Fast-response I/Os and 4,000-event history buffer that simplify troubleshooting, compliance documentation and incident review
| General Information | |
|---|---|
| Brand Name | Potter Electric Signal, LLC |
| Manufacturer | Potter Electric Signal, LLC |
| Product Name | Fire Alarm Control Panel |
| Product Type | Fire Alarm Control Panel |
| Product Model | AFC-50 |
| Product Series | AFC |
| Country of Origin | US |
| Manufacturer Part Number | AFC-50 |
| Technical Information | |
| Panel Control Type | Addressable |
| Number of Events Log | 4000 |
| Connectivity Technology | Wired |
| Number of Zones Supported | 50 |
| Display & Graphics | |
| Display Type | Non-Touchscreen |
| Network & Communication | |
| Ethernet | Yes |
| Physical Characteristics | |
| Color | Red |
| Depth | 3.90" |
| Width | 16.00" |
| Height | 17.00" |
| Power Description | |
| Input Voltage | 120V AC, 230V AC |
| Product Information | |
| Display Screen Type | LCD (Liquid Crystal Display) |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | PFC-6030 |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Features | 2 Input/Output (I/O) Circuits for system flexibility rated at 1 Amp each, 2 NACS, Regulated, Rated at 3 Amps each, expandable to 188, 4,000 Event History Buffer, 5 Amp Power Supply, Expandable to 310 amps, 50 addresses available on this analog addressable system, 99 software zones, Additional system capacity achieved via multi-point SLC modules, Built in IP Communicator, Dedicated Alarm, Supervisory and Trouble Relays, E-Mail System Status, Reports and Event Information, Ethernet Port for Programming and Network Connectivity, NFPA 72 Compliant Smoke Sensitivity Test Built-In, Optional two line DACT with UD-2000 that can report General, Zone or Point Information, Strobe Synchronization and System Wide Sync for Gentex, AMSECO, Cooper Wheelock and System Sensor strobes, System Operates as Class A or Class B for SLC, P-Link and NACs |
