JBL Professional AM5212/00 12" 2-Way Loudspeaker System, Black
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Image of 3
Key Features
- Reliable, punchy low-end and clear HF for intelligible speech and music in venues, reducing the need for extra cabinets
- Wide 100°x100° rotatable coverage for flexible vertical or horizontal installs and consistent audience experience
- 300W RMS power handling and 111dB sensitivity deliver room-filling performance with headroom for live events
- Bi-amp/passive with FIR tuning optimizes frequency and phase response for best-in-class clarity and arrayability
- Rugged plywood/steel construction and 5-year limited warranty for long-term deployment in houses of worship, clubs, auditoriums, and integrated security/monitoring systems
Quick Specifications
- Product Model
- AM5212/00
- Brand Name
- JBL Professional
- Product Line
- Professional
- Product Name
- AM5212/00 2-Way Loudspeaker System with 1 x 12" LF
Product Information Tabs
Overview
Designed for demanding live-sound and installed AV environments, the JBL Professional AM5212/00 12-inch 2-way loudspeaker delivers reliable, high-impact audio that keeps audiences engaged and intelligible announcements crystal clear. As a JBL Professional pro speaker, it combines a 12-inch Differential Drive low-frequency driver with a 1.5-inch compression HF driver and a large PT waveguide to provide consistent 100°x100° coverage and controlled off-axis response. With 300W RMS power handling, 43Hz–20kHz frequency response and 111dB sensitivity, the AM5212/00 offers the headroom and clarity needed for performing arts, clubs, houses of worship, and sports venues. The rotatable waveguide and bi-amp/passive switching simplify installation while FIR tuning ensures optimized frequency and phase alignment for better sound quality and array performance. Built from durable plywood and steel, this cabinet withstands demanding tour and fixed-install conditions, and integrates easily with AV, security audio, and monitoring systems for centralized control and surveillance audio applications. Specify the AM5212/00 when you need professional, consistent coverage and dependable performance—contact us to discuss system design or order for your next installation.
Features
- Reliable, punchy low-end and clear HF for intelligible speech and music in venues, reducing the need for extra cabinets
- Wide 100°x100° rotatable coverage for flexible vertical or horizontal installs and consistent audience experience
- 300W RMS power handling and 111dB sensitivity deliver room-filling performance with headroom for live events
- Bi-amp/passive with FIR tuning optimizes frequency and phase response for best-in-class clarity and arrayability
- Rugged plywood/steel construction and 5-year limited warranty for long-term deployment in houses of worship, clubs, auditoriums, and integrated security/monitoring systems
| General Information | |
|---|---|
| Brand Name | JBL Professional |
| Manufacturer | Harman International Industries, Inc |
| Product Line | Professional |
| Product Name | AM5212/00 2-Way Loudspeaker System with 1 x 12" LF |
| Product Type | Speaker |
| Product Model | AM5212/00 |
| Manufacturer Part Number | AM5212/00 |
| Technical Information | |
| Material | Plywood, Steel |
| Impedance | 8 ohms |
| Sensitivity | 111dB |
| Speaker Size | 12" |
| Crossover Type | 2-way |
| Application/Usage | Auditoriums, Dance Clubs, Live Clubs, Performing Arts Facilities, Sports Facilities, Theatrical Sound Design, Themed Entertainment Venues, Worship Facilities |
| Audio | |
| RMS Output Power | 300W |
| Maximum Frequency Response | 20 kHz |
| Minimum Frequency Response | 43Hz |
| Physical Characteristics | |
| Size | 11.81" |
| Color | Black |
| Depth | 18.03" |
| Width | 14.6" |
| Height | 28.1" |
| Weight | 44.53lb |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Country of Origin | MX |
