JBL Professional AM5212/26 12" 2-Way Loudspeaker System, Black
Image of 2
Key Features
- Consistent, wide coverage: 120° x 60° waveguide delivers uniform sound across venues for clearer speech, music and paging
- Flexible installation: rotatable waveguide and fifteen M10 rigging points let you mount vertically or horizontally for arrays, wall or flown installs
- Punchy low end with clarity: 12" Differential Drive LF and 2408H-1 HF compression driver provide tight bass and articulate highs for reliable monitoring and surveillance audio
- Durable, pro-grade construction: multi-ply birch cabinet with DuraFlex finish and 14-gauge grille protects drivers in high-traffic or themed entertainment environments
- Optimized performance options: Bi-amp/passive switching with FIR tuning for improved frequency/phase response and consistent coverage in distributed sound systems
Quick Specifications
- Product Model
- AM5212/26
- Brand Name
- JBL Professional
- Product Name
- AM5212/26 2-Way Loudspeaker System with 1 x 12" LF
- Product Type
- Speaker
Product Information Tabs
Overview
Deliver consistent, high-impact coverage for live venues, worship spaces and integrated security/paging systems with the JBL Professional AM5212/26 12" 2-Way Loudspeaker System. Designed as a versatile pro speaker, this AE Series cabinet combines a 12" Differential Drive low-frequency driver with a 2408H-1 compression high-frequency driver to produce full, detailed sound from 43 Hz to 18 kHz while handling 300W RMS. The large, rotatable Progressive Transition waveguide ensures 120° x 60° pattern control so spoken word and program material stay intelligible across auditoriums, live clubs and sports facilities — critical for paging, surveillance monitoring and public-address applications. Heavily braced birch construction, JBL’s rugged DuraFlex finish and an acoustically lined 14-gauge steel grille deliver tour-ready durability and a polished appearance. Installers benefit from fifteen M10 threaded points and predictable off-axis response that simplifies array design and system tuning. Whether you need reliable FOH coverage, distributed paging for security, or integrated sound for themed entertainment, the AM5212/26 offers pro-grade performance and long-term reliability. Contact your JBL Professional dealer to spec and deploy this loudspeaker in your next project.
Features
- Consistent, wide coverage: 120° x 60° waveguide delivers uniform sound across venues for clearer speech, music and paging
- Flexible installation: rotatable waveguide and fifteen M10 rigging points let you mount vertically or horizontally for arrays, wall or flown installs
- Punchy low end with clarity: 12" Differential Drive LF and 2408H-1 HF compression driver provide tight bass and articulate highs for reliable monitoring and surveillance audio
- Durable, pro-grade construction: multi-ply birch cabinet with DuraFlex finish and 14-gauge grille protects drivers in high-traffic or themed entertainment environments
- Optimized performance options: Bi-amp/passive switching with FIR tuning for improved frequency/phase response and consistent coverage in distributed sound systems
| General Information | |
|---|---|
| Brand Name | JBL Professional |
| Manufacturer | Harman International Industries, Inc |
| Product Name | AM5212/26 2-Way Loudspeaker System with 1 x 12" LF |
| Product Type | Speaker |
| Product Model | AM5212/26 |
| Manufacturer Part Number | AM521226 |
| Technical Information | |
| Material | Birch Plywood, Foam, Perforated-steel |
| Impedance | 8 ohms |
| Sensitivity | 96dB |
| Speaker Size | 12" |
| Crossover Type | 2-way |
| Application/Usage | Auditoriums, Dance Clubs, Live Clubs, Performing Arts Facilities, Sports Facilities, Theatrical Sound Design, Themed Entertainment Venues, Worship Facilities |
| Audio | |
| RMS Output Power | 300W |
| Maximum Frequency Response | 18 kHz |
| Minimum Frequency Response | 43Hz |
| Physical Characteristics | |
| Size | 12" |
| Color | Black |
| Depth | 18.1" |
| Width | 14.6" |
| Height | 28.1" |
| Weight | 44.53lb |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Country of Origin | MX |
