JBL Professional AM5215/26-WH Speaker, Two-Way Full Range Loudspeaker, White

SKU: AM521526-WH MPN: AM5215/26-WH JBL Professional

Special Order Item

This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.

Image of JF-AM521526W
Product images for JBL Professional AM5215/26-WH Speaker, Two-Way Full Range Loudspeaker, White. 2 image(s) available. Click on image to view full size.

Key Features

  • Delivers clear, punchy coverage for venues and installations, ensuring announcements and music are intelligible across large spaces
  • Rotatable PT Progressive Transition waveguide with 120° x 60° coverage lets you optimize dispersion for vertical or horizontal mounting
  • High-output 15-inch Differential Drive woofer and 350W RMS power provide low-end impact and headroom for reliable performance
  • Rugged birch plywood cabinet with DuraFlex finish and M10 rigging points simplifies long-term installation and suspending for permanent AV setups
  • Low distortion, high sensitivity design supports security paging, monitoring and surveillance audio applications where clarity and reliability matter

Quick Specifications

Product Model
AM5215/26
Brand Name
JBL Professional
Product Name
AM5215/26 2-Way Loudspeaker System with 1 x 15" LF
Product Type
Speaker
View Full Technical Specifications

Product Information Tabs

Overview

For professional installations that demand intelligible, reliable sound, the JBL Professional AM5215/26-WH two-way full-range loudspeaker delivers consistent coverage and pro-grade performance. This JBL Professional speaker pairs a 15-inch Differential Drive low-frequency driver with a 1.5-inch compression driver and a rotatable PT waveguide to provide broad 120° x 60° dispersion and a clean 41 Hz to 18 kHz frequency range. Rated at 350W RMS with 98 dB sensitivity, the AM5215/26-WH offers the headroom and efficiency required for commercial PA, retail music, houses of worship, and security paging or surveillance monitoring systems.

Installers benefit from a lightweight, rugged birch-plywood enclosure with DuraFlex finish, NL4 and barrier strip inputs, and M10 threaded rigging for flexible mounting. The controlled off-axis response and high-slope crossover simplify arraying and reduce comb-filtering in multi-speaker deployments. Backed by a 5-year limited warranty, this speaker is a dependable choice for integrators specifying pro audio for AV, security, and monitoring projects. Specify the AM5215/26-WH for clear, powerful coverage in your next installation — contact us for quoting or add to your system design.

Features

  • Delivers clear, punchy coverage for venues and installations, ensuring announcements and music are intelligible across large spaces
  • Rotatable PT Progressive Transition waveguide with 120° x 60° coverage lets you optimize dispersion for vertical or horizontal mounting
  • High-output 15-inch Differential Drive woofer and 350W RMS power provide low-end impact and headroom for reliable performance
  • Rugged birch plywood cabinet with DuraFlex finish and M10 rigging points simplifies long-term installation and suspending for permanent AV setups
  • Low distortion, high sensitivity design supports security paging, monitoring and surveillance audio applications where clarity and reliability matter
General Information
Brand Name JBL Professional
Manufacturer Harman International Industries, Inc
Product Name AM5215/26 2-Way Loudspeaker System with 1 x 15" LF
Product Type Speaker
Product Model AM5215/26
Manufacturer Part Number AM5215/26-WH
Technical Information
Material Birch Plywood, Perforated-steel
Impedance 8 ohms
Sensitivity 98dB
Crossover Type 2-way
Audio
RMS Output Power 350W
Maximum Frequency Response 18 kHz
Minimum Frequency Response 41Hz
Environmental Conditions
Sound Emission 98 dB
Physical Characteristics
Size 14.96"
Color White
Depth 19.84"
Width 16.6"
Height 30.8"
Weight 55.12lb
Warranty
Limited Warranty 5-Year
Miscellaneous
Features 1.5" Compression Driver, 120 deg x 60 deg Coverage, 15" Differential Drive Woofer, 43 Hz to 18 kHz Frequency Response, DuraFlex Finish, M10 Threaded Attachments for Rigging, Medium Power, Light Weight, Full-Range, NL4 speakON and Barrier Strip Inputs, Progressive Transition Waveguide, Rotatable Horn for V/H Deployment
Country of Origin MX
