AMX AMX-VTT0001W DXLink 4K60 HDMI Wall Plate Transmitter, White
Image of 6
Key Features
- Simplify installations with single‑cable AV: transmits 4K60 video, audio and USB over one shielded Cat6A/Cat7 run to reduce cabling and labor.
- Preserve critical image fidelity for monitoring and surveillance with HDMI 2.0 4K60 4:4:4 and HDR support for accurate color and detail.
- Enable USB peripherals (cameras, touch panels, storage) remotely via built‑in USB 2.0 host—ideal for conferencing and security systems.
- Flexible placement and power: install in a single‑gang wall box and power locally or remotely from DXLink power sources for versatile deployments.
- Long‑reach reliability: supports twisted‑pair transport up to 40 m (230 ft) over Cat6A shielded cable for control rooms and distributed displays.
- Control integration: RS‑232 pass‑through and compact gang‑box form factor streamline integration into AV, security, and monitoring environments.
Quick Specifications
- Product Model
- AMX-VTT0001W
- Brand Name
- AMX by Harman
- Product Line
- DXLink
- Product Name
- DXLink 4K60 HDMI Wallplate Transmitter
Explore the details
Product information
AMX-VTT0001W
Overview
Engineered for professional AV, conferencing and security environments, the AMX by Harman DXLink 4K60 HDMI Wallplate Transmitter delivers pristine 4K60 4:4:4 HDMI 2.0 video and HDR with minimal cabling. This wallplate transmitter sends audio, video and USB 2.0 data over a single shielded Cat6A/Cat7 twisted pair—making it easy to connect guest laptops, conferencing cameras or surveillance peripherals to a remote DXLink receiver near displays or recording systems.
Designed for control rooms, meeting spaces and surveillance monitoring stations, the DXLink wallplate preserves color fidelity and frame rate for critical viewing while supporting bi‑directional RS‑232 control. Installers benefit from standard single‑gang mounting and flexible power options (local or remote from DXLink power sources), enabling tidy, scalable deployments across classrooms, boardrooms and security operations centers. With reliable transport up to 40 m (230 ft) over Cat6A and seamless USB peripheral support, it reduces clutter and simplifies system architecture. Add the AMX DXLink 4K60 HDMI Wallplate Transmitter to your AV or security solution to streamline connectivity—contact sales or order now for meeting rooms, surveillance hubs and monitoring applications.
Features
- Simplify installations with single‑cable AV: transmits 4K60 video, audio and USB over one shielded Cat6A/Cat7 run to reduce cabling and labor.
- Preserve critical image fidelity for monitoring and surveillance with HDMI 2.0 4K60 4:4:4 and HDR support for accurate color and detail.
- Enable USB peripherals (cameras, touch panels, storage) remotely via built‑in USB 2.0 host—ideal for conferencing and security systems.
- Flexible placement and power: install in a single‑gang wall box and power locally or remotely from DXLink power sources for versatile deployments.
- Long‑reach reliability: supports twisted‑pair transport up to 40 m (230 ft) over Cat6A shielded cable for control rooms and distributed displays.
- Control integration: RS‑232 pass‑through and compact gang‑box form factor streamline integration into AV, security, and monitoring environments.
| General Information | |
|---|---|
| Brand Name | AMX by Harman |
| Manufacturer | Harman International Industries, Inc |
| Product Line | DXLink |
| Product Name | DXLink 4K60 HDMI Wallplate Transmitter |
| Product Type | Video Extender Transmitter |
| Manufacturer Part Number | AMX-VTT0001W |
| Technical Information | |
| Cable Type | Category 6, Category 6a, Category 7 |
| Application/Usage | Classroom, Display, Meeting Room, Notebook, Video Conferencing Camera |
| Media Type Supported | Twisted Pair |
| Connectivity Technology | Wired |
| Maximum Operating Distance | 230 ft |
| Display & Graphics | |
| Maximum Video Resolution | 4096 x 2160 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Number of USB Ports | 1 |
| Number of HDMI Inputs | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Physical Characteristics | |
| Color | White |
| Depth | 2.01" |
| Width | 1.78" |
| Height | 4.23" |
| Form Factor | Gang Box Mount, Wall Mountable, Wall Plate |
| Product Information | |
| Mount Type | Gang Box Mount, Wall Mountable, Wall Plate |
| Video | |
| Graphics Modes | 4K |
